Code Blue 40197 S-50 Strobe Light Assembly
Overview
The Code Blue 40197 is a 5.5-inch LED strobe beacon designed for security and emergency-signaling applications where visual alarm indication is required. Delivers 270 lumens at 92 candela intensity with configurable flash patterns—up to 21 selectable modes at rates reaching 375 flashes per minute. Powered via PoE (802.3af compliant, no separate transformer needed) or standard 12–24V AC/DC, making it straightforward to integrate into existing security infrastructure. IP56 rating withstands direct spray and airborne dust, suitable for outdoor or semi-protected mounting on poles, buildings, or enclosure surfaces.
Compatibility
Works with any PoE-capable network infrastructure (switches, injectors) delivering 802.3af power. Pairs with access control systems, NVRs, and alarm management platforms that support relay-triggered strobes or timed signal outputs. Compatible with standard mounting hardware for 5.5-inch beacon assemblies; verify your mounting surface clearance before installation.
Installation Notes
Operates across a wide temperature range (−40°F to +158°F) suitable for climate-controlled and outdoor environments. PoE deployment eliminates the need for dedicated power wiring; run a single Ethernet cable from a PoE switch or injector to the strobe. For non-PoE installations, provide 12–24V AC/DC via a dedicated power supply. UL 62368-1 certified and built to NEMA 4 standards for structural durability. Mounting height and sightline clearance are critical for effective visual coverage; position the beacon at or above eye level for maximum visibility across the protected area.
What's in the Box
- 1x Code Blue 40197 S-50 Strobe Light Assembly
