Panduit UTP28X1OR Patch Cord

Overview

The Panduit UTP28X1OR is a 1-foot Cat 6A UTP patch cord designed for high-speed data center applications. Its compact 28 AWG solid conductor construction simplifies cable management in dense environments, supporting 10GBASE-T Ethernet and critical data center functions like server virtualization and backbone aggregation. The CM/LSZH rating ensures compliance with flammability standards for plenum and riser spaces.

Compatibility

This patch cord is engineered to exceed ANSI/TIA-568.2-D Category 6A and ISO 11801 Class EA performance requirements up to 500 MHz. It supports IEEE 802.3af/at and 802.3bt types 3 and 4 Power over Ethernet (PoE) applications, making it suitable for powering network devices. The integrated RapidID barcodes facilitate easy port mapping with compatible software.

Installation Notes

Features a patented tangle-free latch that prevents snags and simplifies moves, adds, and changes. The 0.185-inch (4.7mm) diameter cable offers improved airflow and reduced bundle size compared to thicker Cat 6A cables. 100% performance tested for wire map, NEXT, and return loss.
