Camden CM-PT250SS-18 Stainless Steel Endcaps 18"

In our experience, cable conduit corrosion is one of the most overlooked cost drivers in access control deployments—especially at exterior doors, loading docks, and coastal or high-humidity sites. We've replaced zinc-plated and mild-steel conduit runs after 18–24 months of exposure, watching integrators field calls for intermittent electrical faults traced back to oxidized cable sheaths and seized endcaps. The CM-PT250SS-18 solves this at the bill-of-materials level. Yes, stainless cable costs 40–60% more than galvanized equivalents, but amortized over a 10-year facility lifecycle with zero conduit replacement, the math is compelling. We spec stainless power transfer cable as a baseline on any exterior access control deployment or high-humidity interior environment (swimming facilities, food processing, coastal hospitality).

Technical Highlights:

• Stainless Steel 300-Series Endcaps: Engineered for salt spray (ASTM B117) and freeze-thaw cycling without pitting or stress corrosion cracking. Zinc-plated conduit corrodes visibly in 12–18 months in marine or high-salt environments; stainless maintains integrity indefinitely.
• 1/4" ID Conductor Capacity: Four 22-gauge wires (standard for single-strike control circuits) or two 18-gauge (auxiliary monitoring or dual-coil feeds). Anything larger requires the 3/8" variant—forcing oversized wire into undersized conduit creates field friction and introduces installation defects.
• Flex-Wound Inner Sleeve: Minimizes sharp-edge contact with conductor insulation during pulling and bending. On retrofit jobs where you're running new cable through existing wall voids or tight spaces, this design cuts field damage risk measurably.
• Factory-Terminated Endcaps: No field crimping or soldering required. Endcaps are permanently attached and provide immediate strain relief at enclosure penetrations, reducing field assembly errors and field rework.
• Length Inventory: The 18" length covers 36–48" rough opening frame-to-panel distances efficiently. For larger frames or non-standard layouts, Camden supplies 7", 12", 24", and 36" variants—measure your distance before ordering to avoid surplus cable bulk or inadvertent cable length shortage.

Deployment Considerations:

• Confirm conductor count and gauge before ordering. The 1/4" ID is firm; oversized wire jams and introduces installation risk. If you're uncertain whether your circuit requires 22-gauge or 18-gauge, consult your strike manufacturer or control panel spec sheet.
• Route cable away from foot traffic, mechanical equipment vibration, and sharp architectural edges. Even stainless conduit outer sleeve can suffer mechanical damage if pinched or crushed; protective raceway or conduit sleeves are recommended in open building paths.
• In coastal or marine environments, pair this cable with stainless hardware (stainless strikes, hinges, keeper plates). A single galvanized component in an otherwise stainless assembly creates galvanic corrosion at the contact interface.
• Test continuity and insulation resistance on all conductors immediately after installation and before energizing. Confirm no shorts between conductors and no opens on any signal or power line—field troubleshooting electrical faults after cable installation is costly.
• For retrofit installations in existing walls or tight spaces, use wire pulling lubricant and ensure the cable path is clear of burrs, nails, or rough edges before pulling. Stainless is durable but not immune to mechanical damage during rough handling.

This cable is the right choice for integrators and facility managers who need access control wiring that doesn't require five-year replacement cycles due to corrosion. Pair it with stainless hardware on exterior doors, and you've eliminated one major failure vector from your access control maintenance burden. Explore the full Camden catalog for compatible strikes, raceways, and conduit management solutions.
