Middle Atlantic 827PCC-BLK Poly CPT FL 2-GANG

Middle Atlantic 827PCC-BLK Poly CPT FL 2-GANG

Overview

The Middle Atlantic 827PCC-BLK is a 2-gang black plastic floor box designed for concrete installations, featuring a carpet flange to seamlessly integrate into finished flooring. This unit provides a concealed and protected housing for low-voltage cabling and connectors, ideal for AV, data, or power distribution in commercial and institutional environments where aesthetics and cable management are critical. It specifically addresses the need for a clean, recessed termination point that protects connections from foot traffic and debris. The 827PCC-BLK model is TAA compliant, ensuring suitability for government and certain educational projects.

Compatibility

This floor box is designed for use with concrete poured floors. It accepts standard 2-gang electrical and AV faceplates, allowing for a wide range of connector and device installations. While not specific to any single AV or network brand, its 2-gang form factor makes it compatible with common faceplates used for RJ45, HDMI, USB, and power outlets from various manufacturers. It is intended for use within the Middle Atlantic OmniBox series for concrete floor applications.

Installation Notes

Installation requires embedding the box into wet concrete during floor construction. The integrated carpet flange is designed to be set flush with the carpet surface after installation, providing a clean finish. Ensure proper concrete curing and sealing around the box to maintain its integrity and prevent moisture ingress. The box's dimensions are 5.75 inches wide, 8.88 inches deep, and 1 inch high. It is TAA compliant.
