Discontinued — No Longer Available New
This model has been discontinued by Axis. Shop current Axis products → or see the recommended alternatives below.
The Axis XP40-Q1942 network camera addresses the unique challenges of monitoring hazardous environments prone to extreme temperatures and explosive materials. This robust thermal camera delivers reliable performance in frigid conditions as low as -50°C (-58°F), making it ideal for chemical plants, oil refineries, or other industrial settings. Its UL certification ensures compliance with stringent safety regulations for areas with flammable materials or gases. Unlike traditional cameras, the XP40-Q1942 utilizes advanced thermal imaging technology to provide clear visibility even in complete darkness, smoke, or fog, enhancing security and situational awareness.
Key Features:
-
Thermal Imaging Excellence: The Axis XP40-Q1942 utilizes advanced thermal imaging technology, allowing you to detect heat signatures and temperature variations even in complete darkness. This feature is ideal for identifying potential safety hazards or security threats in low-light conditions.
-
UL Certified Explosion Protection: This camera is UL certified for explosion protection, making it suitable for hazardous environments like chemical plants, oil refineries, or industrial sites where explosive gases or dust may be present. It ensures safety without compromising surveillance capabilities.
-
19mm Lens for Precision: The 19mm lens provides a narrow field of view, allowing for precise thermal imaging and detection at longer distances.
-
High Frame Rate (8.3fps): With a high frame rate of 8.3 frames per second, this camera provides smooth and real-time thermal imaging, ensuring you capture every critical event with clarity.
Compatibility:
The Axis XP40-Q1942 -50C UL Explosion-Protected Thermal Network Camera, 01142-001, is compatible with various Axis network video management systems (VMS) and network video recorders (NVRs), ensuring seamless integration into your existing surveillance infrastructure.
Specifications:
- Camera Type: Thermal Network Camera
- Sensor Type: Uncooled Microbolometer
- Resolution: VGA (640x480)
- Minimum Illumination: 0 lux
- Night Vision: Not applicable (thermal imaging)
- Lens: 19mm, fixed
- Frame Rate: 8.3 fps
- Audio: No
- Storage: MicroSD card slot (optional)
- Power Supply: 110V UL certified
- Connectivity: RJ45 Ethernet port
- Environmental Resistance: IP66, NEMA 4X (dustproof, water-resistant)
- Operating Temperature: -50°C to +55°C (-58°F to 131°F)
- Housing Material: Stainless steel (SAE 316L)
- Software Features: Analytics (motion detection, temperature change, etc.)
- Integration: ONVIF compliant
- Mobile and Remote Access: Supported through web browser and mobile app
Package Contents:
- Axis XP40-Q1942 camera
- Mounting bracket
- Power cable
- User manual
- Warranty card
Summary:
The Axis XP40-Q1942 stands out as a reliable and feature-rich solution for thermal surveillance in hazardous environments. Its combination of thermal imaging, explosion-proof design, and extreme temperature operation makes it an ideal choice for businesses and organizations requiring exceptional security and visibility in challenging conditions, where traditional cameras wouldn't suffice.
