Axis Q1952-E 19mm Thermal Bullet IP Camera

Axis Q1952-E 19mm Thermal Bullet IP Camera

The Axis Q1952-E is a high-performance thermal bullet camera designed for perimeter security, long-range detection, and wide-area surveillance applications. Equipped with an uncooled microbolometer thermal sensor and 19mm focal length, this camera delivers reliable thermal imaging in complete darkness and challenging weather conditions where traditional cameras fail. Built for outdoor deployment with IP66 rating and -40 to 60°C operating temperature range, the Q1952-E provides persistent detection capabilities for critical infrastructure protection and 24/7 monitoring.

Key Features

• Uncooled microbolometer thermal sensor with NETD <25 mK @25°C, F1.0 for superior thermal sensitivity
• 800x600 upscaled thermal resolution for effective long-distance surveillance
• 30fps video capture ensuring smooth motion detection and tracking
• H.264 compression with Zipstream technology for optimized bandwidth management
• PoE Class 3 power delivery for simplified installation with single cable connectivity
• IP66-rated ruggedized housing for outdoor durability and harsh environment reliability
• Pre-installed analytics including Motion Guard, Fence Guard, and Loitering Guard for automated threat detection
• Support for third-party AI-based analytics for human and vehicle classification
• Audio support and audio detection for comprehensive situational awareness
• Single alarm input/output for integration with external security systems

Technical Highlights

The Q1952-E's 19mm lens provides optimal balance between field-of-view and detection range for perimeter applications. Its uncooled thermal sensor eliminates the need for cryogenic cooling, reducing operational costs and maintenance requirements while maintaining exceptional thermal sensitivity. The camera operates effectively across extreme temperature ranges, making it suitable for deployment in arctic and desert environments. H.264 compression with Zipstream reduces storage and bandwidth demands by up to 50% compared to standard compression, critical for large-scale deployments.

The integrated analytics platform minimizes false alarms through intelligent detection algorithms. Motion Guard identifies movement within user-defined zones, Fence Guard protects perimeter boundaries with intrusion detection, and Loitering Guard flags unauthorized personnel lingering in restricted areas. Integration with Axis Perimeter Defender and third-party analytics platforms enables sophisticated threat classification and response automation.

Applications

Ideal for perimeter security, critical infrastructure protection, border surveillance, airport security, seaport monitoring, industrial facility protection, and any scenario requiring uncompromised 24/7 detection capability. The thermal imaging technology eliminates dependency on visible light, providing superior performance in fog, rain, snow, and complete darkness.

Karl Wilson

The Q1952-E represents Axis's mature thermal camera technology optimized for fixed perimeter monitoring rather than pan-tilt-zoom applications. The 800x600 upscaled resolution is standard for uncooled thermal sensors at this price point; expectations for pixel-level detail should be calibrated accordingly. The NETD specification of <25 mK ensures detection of humans and vehicles at meaningful distances.

PoE Class 3 power delivery (95W maximum) accommodates the thermal sensor and processing requirements without requiring external power supplies. IP66 rating and stated outdoor durability make this appropriate for rooftop and external wall mounting, though installations should include weatherproof conduit and strain relief for PoE connections. The combination of native analytics plus third-party AI support provides flexibility as threat classification requirements evolve.

Organizations should budget for integration testing with their chosen analytics platform and training on thermal image interpretation, as thermal feeds require different monitoring protocols than visible-light cameras.
