Typical applications:
Entrances and exits in retail environments such as stores and shopping malls as well as public buildings such as museums or libraries.
Mounting height:
250 cm to 600 cm (98 in to 236 in)
Counting-area coverage:
Maximum size of counting area when mounted at: 250cm(98in): 199x46cm(78x18in) 300cm(118in): 306x100cm(120x39in) 400cm(157in): 400x208cm(157x82in) 500cm(197in): 400x225cm(157x89in) 600cm(236in): 400x225cm(157x89in)
Image sensor:
1/2.9” progressive scan RGB CMOS
Lens:
Fixed iris 2.8 mm, F2.2
Minimum illumination:
5 lux
Shutter speed:
1/28000 s to 2 s with 50 Hz 1/33500 s to 2 s with 60 Hz
SOC) Model:
ARTPEC-6
Memory:
1024 MB RAM, 512 MB Flash
Video compression:
H.264 (MPEG-4 Part 10/AVC) Baseline, Main and High Profiles Motion JPEG
Resolution:
1920x1080 HDTV 1080p to 160x90
Frame rate:
30/25 fps (60/50 Hz)
Video streaming:
Multiple, individually configurable streams in H.264 and Motion JPEG Axis Zipstream technology in H.264 Controllable frame rate and bandwidth VBR/MBR H.264
Security:
IP address filtering, HTTPSa encryption, IEEE 802.1Xa network access control, user access log, centralized certificate management
Network protocols:
IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTP/2, HTTPSa, TLSa, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP®, SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS
Network protocols (continued:
NTP, NTS, RTSP, RTP, SRTP/RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, DHCPv4/v6, SSH, LLDP, CDP, MQTT v3.1.1, Secure syslog (RFC 3164/5424, UDP/TCP/TLS), Link-Local address (ZeroConf)
Application Programming Interface:
Open API for software integration, including VAPIX® and AXIS Camera Application Platform; specifications at axis.com ONVIF® Profile G and ONVIF® Profile S
Event conditions:
Analytics, external input, edge storage events, virtual inputs through API MQTT subscribe
Event actions:
Record: network share Upload of images or video clips: FTP, SFTP, HTTP, HTTPS, network share and email Pre- and post-alarm video or image buffering for recording or upload Notification: email, HTTP, HTTPS, TCP and SNMP trap Overlay text MQTT publish
Data streaming:
Event data
Edge security (Software:
Signed firmware, brute force delay protection, digest authentication and OAuth 2.0 RFC6749 OpenID Authorization Code Flow for centralized ADFS account management, password protection, AES-XTS-Plain64 256bit SD card encryption
Edge security (Hardware:
Secure boot
Network security:
IEEE 802.1X (EAP-TLS, PEAP-MSCHAPv2)a, IEEE 802.1AE (MACsec PSK/EAP-TLS), IEEE 802.1AR, HTTPS/HSTSa, TLS v1.2/v1.3a, Network Time Security (NTS), X.509 Certificate PKI, host-based firewall
Casing:
Aluminum casing and plastic faceplate Colors: white NCS S 1002-B, black NCS S 9000-N
Sustainability:
PVC free
Power:
Power over Ethernet (PoE) IEEE 802.3af/802.3at Type 1 Class 3 Typical 4.4 W, max 6 W
Connectors:
RJ45 10BASE-T/100BASE-TX PoE
Storage:
Recording to network-attached storage (NAS)
Operating conditions:
0 °C to 50 °C (32 °F to 122 °F) Start-up temperature: 0 °C (32 °F) Humidity 10–85% RH (non-condensing)
Storage conditions:
-40 °C to 65 °C (-40 °F to 149 °F) Humidity 5-95% RH (non-condensing)
Approvals (EMC:
EN 55032 Class A, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-3(A)/NMB-3(A), VCCI Class A, RCM AS/NZS CISPR 32 Class A, KC KN32 Class A, KC KN35
Approvals (Safety:
IEC/EN/UL 62368-1, IS 13252
Approvals (Environment:
Environment IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-78, IEC/EN 60529 IP40
Approvals (Network:
NIST SP500-267, IPv6 USGv6
Dimensions:
168 x 78 x 30 mm (6.61 x 3.07 x 1.18 in)
Weight:
450 g (1 lb)
Included accessories:
Installation guide, Windows® decoder 1-user license
Optional accessories:
AXIS TP8201 Recessed Mount, AXIS TP8101 Pendant Kit, AXIS T91B21 Stand, AXIS T91B53 Telescopic Ceiling Mount, AXIS T91E61 Wall Mount
Video Management Software:
AXIS Camera Station
Languages:
English
