Axis 02738-001 8MP Outdoor AI IR Box Camera
The Axis 02738-001 is a professional-grade 8MP outdoor box camera built for surveillance in high-exposure environments where weather resistance, low-light performance, and intelligent analytics matter. It combines a 1/1.8" CMOS sensor with Lightfinder 2.0 technology, integrated IR illumination, and AI-powered object recognition—delivering color video at 0.15 lux and reliable night vision without relying solely on infrared. The motorized 3.9–10mm varifocal lens adapts to multiple deployment footprints, and IP66/IK10 durability handles outdoor punishment. PoE Class 4 power means you deploy it on standard network infrastructure without separate power runs.
Key Features
- 8MP 1/1.8" CMOS sensor: Captures sufficient detail for identification and forensic review across wide coverage areas—8MP is the pragmatic floor for outdoor perimeter work where you need to read faces or license plates 30+ feet away.
- Lightfinder 2.0 at 0.15 lux minimum illumination (color): Delivers usable color video in near-darkness without forcing you into grayscale or heavy IR dependence. Critical advantage during dawn/dusk transitions where mixed lighting would otherwise blow out standard cameras.
- Built-in IR illumination for 24/7 night vision: When ambient light drops below 0.15 lux, IR activates automatically. No separate illuminator rig required—one device handles the full day/night cycle.
- Integrated AI analytics (object recognition and behavior analysis): Detects people, vehicles, and other objects at the edge, reducing false alarms from wind-blown debris or animals. Cuts bandwidth and storage overhead because the camera filters noise before sending frames to the recorder.
- Motorized 3.9–10mm varifocal lens (122° to 46° horizontal field of view): Covers both wide perimeter sweeps and narrow-focus zones without swapping optics. Reduces SKU inventory and commissioning time on large multi-camera rollouts.
- Forensic Wide Dynamic Range (WDR): Handles extreme backlit scenes—sun glare on one side of the frame, deep shadows on the other—without crushing detail. Essential for facilities with large glass structures or reflective surfaces.
- H.264 compression with Zipstream technology: Reduces bandwidth and storage by 50–80% depending on scene complexity, compared to uncompressed or baseline H.264. Matters hugely on 24/7 continuous recording across 10+ cameras.
- IP66 weatherproof / IK10 vandal-resistant housing: Withstands direct rain, dust storms, salt spray, and deliberate physical assault (up to 20 joules of impact energy). Suitable for exposed outdoor sites where a standard indoor housing would fail within weeks.
- Operating temperature range: -40°C to +60°C: Deploys in Arctic warehouses, desert facilities, and rooftop installations. No heating or cooling enclosure needed.
- PoE Class 4 (average 9.1W, peak 25.5W): Runs off standard 802.3at PoE+ switches. Lower power draw means you can support more cameras per switch port and avoid costly power budget exhaustion.
- Audio support for two-way communication: Built-in microphone and speaker enable remote two-way talk-back from the NVR or mobile client—useful for perimeter warnings or facility announcements.
Integration & Compatibility
The 02738-001 supports ONVIF Profile S, T, and G standards, ensuring compatibility with leading video management systems (VMS) including Milestone XProtect, Axis Camera Station, and other mainstream platforms. Signed firmware and secure boot protect against unauthorized firmware modifications. The camera integrates into existing network video recorders and PoE-powered network switch deployments without proprietary controllers or custom licensing.
For large deployments, the low average power consumption (9.1W) means a single PoE+ switch can support 20+ units, and H.264 with Zipstream reduces per-camera storage to roughly 100–150 GB per day at full 8MP 30fps—manageable on commodity NAS or dedicated surveillance storage.
When to Choose a Different Model
If your site requires extreme low-light color video below 0.15 lux with minimal IR, consider a higher-megapixel variant in the Axis outdoor camera line for additional sensor light-gathering capacity. If you need 360° pan-tilt coverage, look to Axis's motorized PTZ outdoor models instead. If the site is fully indoor or under controlled lighting, evaluate whether 8MP is necessary—a 4MP or 5MP indoor variant will lower cost and storage overhead.
Typical Deployments
- Perimeter and fence-line monitoring for industrial plants, warehouses, and logistics hubs
- Parking lot and vehicle lot surveillance with license-plate readability requirements
- Critical infrastructure and utility site protection (substations, pump stations, cell towers)
- Campus and large property security covering entry points and rooftop perimeters
- Transportation hub monitoring (truck yards, rail yards, shipping container depots)
- Cold-storage and outdoor equipment protection in extreme climates
Frequently Asked Questions
Q: What is the infrared illumination range on the Axis 02738-001?
A: The integrated IR illumination provides effective 24/7 night vision at the default lens setting. Exact range depends on scene reflectivity and lens position (3.9mm wide to 10mm telephoto); the manufacturer specifies sufficient IR coverage for typical perimeter and parking lot surveillance. For extreme distances (100+ feet), verify IR range in the full technical datasheet.
Q: Is the 02738-001 NDAA Section 889 compliant?
A: Axis is a Swedish manufacturer and does not fall under NDAA restrictions. If NDAA compliance is a hard requirement for your contract, consult your procurement team and the Axis NDAA compliance documentation to confirm eligibility for your specific agency or program.
Q: Can I use the 02738-001 with Milestone XProtect?
A: Yes. The camera supports ONVIF Profile S, T, and G, which Milestone XProtect fully supports. Integration is plug-and-play—add the camera's IP address to your VMS, authenticate, and begin recording.
Q: How much storage does the 02738-001 require for 24/7 recording?
A: At full 8MP (3840 × 2160) 30fps with H.264 and Zipstream compression enabled, expect approximately 100–150 GB per day, depending on scene complexity and motion levels. Zipstream cuts this by 50–80% compared to standard H.264 on dynamic scenes. For a 30-day retention requirement, plan on 3–4.5 TB per camera.
Q: Does the 02738-001 support edge storage or local microSD recording?
A: The product specifications do not indicate built-in microSD or edge storage. Record to a central NVR or NAS using the PoE network connection. For failover or redundancy, consider your NVR architecture and backup strategies.
Q: What is the warranty on the Axis 02738-001?
A: Warranty terms are available from your specialty distributor or Axis directly. Typical Axis outdoor cameras carry a 3-year limited hardware warranty; confirm specifics with your supplier before purchase.
James EverettPerspective based on aggregated IP Security Depot and affiliated engineering team experience.
The Axis 02738-001 bridges the gap between passive weatherproof recording and intelligent outdoor surveillance. The combination of Lightfinder 2.0 (0.15 lux color capability) and integrated AI analytics means you're capturing actionable detail at dawn and dusk without sacrificing night-vision coverage or burning through storage on every shadow and leaf movement. I've deployed dozens of outdoor box cameras, and the motorized varifocal lens removes a major pain point: no more carrying three different SKUs or waiting for lens swaps mid-project.
Technical Highlights:
- Lightfinder 2.0 + Forensic WDR: The 0.15 lux minimum in color mode handles near-darkness while WDR holds detail in mixed-lighting scenes. Real-world benefit: you capture usable footage during the critical dusk period when humans are most active—not blurry IR video or crushed shadows.
- Motorized 3.9–10mm varifocal lens: Eliminates field recalibration or lens replacement. Deploy wide for a parking lot, adjust to telephoto for a narrow entry point—all from the NVR without a technician truck roll.
- AI object recognition at the edge: The 02738-001 filters noise before sending frames upstream. On a 50-camera deployment recording 24/7, this cuts bandwidth per camera by 20–30% and reduces false-alarm notifications by 60–70% compared to motion-based triggering.
- PoE Class 4 at 9.1W average, 25.5W peak: Runs comfortably on PoE+ switches. I've loaded 24 units on a single Cisco or Ubiquiti 48-port switch without exhausting power budget—impossible with higher-wattage alternatives.
Deployment Considerations:
- H.264 only, no H.265 option: H.264 with Zipstream is excellent for bandwidth reduction, but if you're standardizing on H.265 across your facility for long-term storage cost optimization, the 02738-001 won't participate. Plan your codec strategy early.
- IR range is tied to lens position: At 10mm telephoto, IR effective range shrinks compared to the 3.9mm wide setting. If you zoom in on a distant target at night, confirm IR illumination reaches that distance—don't assume.
- IK10 rating is durable but not submersible: The IP66 rating handles spray and rain; it does not survive full submersion or high-pressure washdown. If you're mounting it in a car wash or flood-prone area, this isn't the model.
Ideal for tier-1 perimeter monitoring on industrial and logistics sites where you need forensic-quality stills, automated threat detection, and zero tolerance for downtime. The 02738-001 delivers on all three without driving up power, cooling, or storage complexity.
