sku:
03238-001
Form Factor:
Indoor station
Display Size:
7 inch
Audio Support:
Full-duplex two-way audio with echo cancellation
Power Type:
PoE (IEEE PoE)
Connectivity:
SIP, Axis IP intercom systems
OS Platform:
Axis 2N OS
Color:
White
Compatible With:
Axis IP intercoms, SIP-based VoIP systems, AXIS TI5201, AXIS TI5601, AXIS TI5602
Display Type:
Capacitive touch screen
Environment Rating:
Indoor
Warranty:
5-Year Warranty
SIP:
Yes
Height:
157 mm
Width:
193 mm
Depth/length:
50 mm
Weight Of Sales Unit (without Box:
555g
Alarm Inputs/outputs:
0/1
Built-in Microphone:
Yes
Operating Temperature:
0-50 °C
PoE Class:
3
Varifocal Lens:
Off
Resolution:
1024x600; Up to 1280x720
Control Technology:
Capacitive touch panel
Features:
Receive incoming calls, start outgoing calls, view video from connected network intercoms and cameras, send HTTP commands, unlock doors
Anechoic Chamber:
84 dBC @ 1m 1 kHz Line out for hearing loop, 600 mV RMS
Video Compression:
H.264 (MPEG-4 Part 10/AVC) Motion JPEG
Frame Rate:
Up to 30 fps
Network Protocols:
IPv4, HTTP, HTTPS , SIP 2.0, SIPS, SSL/TLS , RTP, SRTP, RTSP, DHCP, NTP, TCP, IGMP, UDP, DNS, Syslog, FTP, SMTP, RTCP, ICMP, DHCPv4
VoIP:
Support for Session Initiation Protocol (SIP) for integration with Voice over IP (VoIP) systems, peer to peer or integrated with SIP/PBX.
Product Markings:
CSA, UL/cUL, CE, VCCI, RCM
Supply Chain:
TAA compliant
Australia/New Zealand:
RCM AS/NZS CISPR 32 Class B
EMC Canada:
ICES(B)/NMB(B)
EMC Japan:
VCCI Class B
EMC USA:
FCC Part 15 Subpart B Class B
Safety:
CAN/CSA C22.2 No. 62368-1 ed. 3, IEC/EN/UL 62368-1 ed. 3
Network Security:
IEEE 802.1X (EAP-TLS, PEAP-MSCHAPv2) , HTTPS , TLS v1.2 , X.509 Certificate PKI
Documentation:
2N Hardening Guide Axis Security Development Model
Casing:
Tempered glass surface Plastic casing
Wall Installation (recessed:
AXIS TI5201 Recessed Mount
Wall Installation (surface:
AXIS TI5601 Wall Mount
Desk Installation:
AXIS TI5602 Desk Stand
Connectors Network:
RJ45 10BASE-T/100BASE-T PoE
Connectors Doorbell Input:
Switching contact (button/relay), normally open
Operating Conditions Humidity:
10–90% RH (non-condensing)
Operating Conditions Altitude:
0 to 2000 m (0 to 6500 ft)
Storage Conditions Temperature:
-20 °C to 70 °C (-4 °F to 158 °F)
Dimensions:
For the overall product dimensions, see the dimension drawing in this datasheet.
Box Content:
Answering unit, installation guide, certificate of ownership, 2.5 mm hexagon key wrench, terminal block connectors for power and doorbell
Optional Accessories:
For optional accessories, go to axis.com/products/axis- i5304#accessories
System Tools:
AXIS Site Designer, Product selector, accessory selector Available at axis.com
Languages:
English, German, French, Spanish, Italian, Japanese, Dutch, Czech
Part Numbers:
Available at axis.com/products/axis-i5304#part- numbers
Substance Control:
PVC free and BFR/CFR free RoHS in accordance with EU RoHS Directive 2011/65/ EU and 2015/863, and standard EN IEC 63000:2018 REACH in accordance with (EC) No 1907/2006. For SCIP UUID, see echa.europa.eu
Materials:
Screened for conflict minerals in accordance with OECD guidelines To read more about sustainability at Axis, go to axis. com/about-axis/sustainability
Environmental Responsibility:
axis.com/environmental-responsibility Axis Communications is a signatory of the UN Global Compact, read more at unglobalcompact.org
