Axis Ex Connection 8-port PoE++ Rail Switch
The Axis Ex Connection Rail 8-port PoE++ (02747-001) is a specialized power distribution and connectivity solution engineered for hazardous area installations requiring ATEX and IECEx certification. This robust switch delivers up to 60W per port across eight PoE++ ports, enabling deployment of high-performance explosion-protected IP cameras, sensors, and network devices in classified environments. The rail-mounted cylindrical design integrates seamlessly into industrial control panels and hazardous location installations.
Key Features
- 8x PoE++ ports rated at 60W each (IEEE 802.3at/bt) with maximum 480W total power budget
- 2x additional 10/100/1000Base-T data ports for uplink connectivity
- 4x SFP ports supporting 100/1000X fiber connectivity
- ATEX II 2 G Ex d IIC and II 2 D Ex tb IIIC certification for Group II gas and dust environments
- IECEx certified for international hazardous area compliance
- IP66-rated seawater-resistant aluminum alloy housing with copper-free construction
- Operating temperature range -40°C to +50°C with 10-100% RH tolerance
- Terminal connectors with 14x M25x1.5 cable entries for robust industrial integration
Technical Specifications
Power & Connectivity: Input voltage 100–240V AC; eight isolated PoE++ ports with IEEE 802.3at Type 2 Class 4 rating. Two Gigabit data ports and four SFP slots provide flexible uplink options for network expansion and redundancy.
Hazardous Area Rating: ATEX TÜV Certificate 10 ATEX 7969 X and IECEx-TUR-16.0025X certifications ensure compliance in explosive gas (Group IIC, T5 temperature class) and combustible dust (IIIC, T95°C) environments. Flameproof enclosure design (Ex d) with pressurization capability (Ex p).
Environmental Protection: IP66 rating provides complete dust and water ingress protection. Copper-free aluminum alloy with RAL7035 epoxy coating resists corrosion in harsh industrial and marine settings.
Dimensions & Weight: 410mm diameter, 281mm height, 31kg weight—optimized for DIN rail mounting in compact panel spaces.
Compliance: EMC certified to EN 55035, EN 55032 Class A, and full EN 61000 immunity suite. RoHS and REACH compliant with conflict mineral screening. PVC-free materials throughout.
Applications
- Offshore oil & gas platform surveillance and monitoring networks
- Chemical plant and refinery hazardous zone camera deployments
- Mining operations requiring Group II or Group III equipment certification
- Grain storage and dust-prone industrial environments
- Explosive atmosphere paint spraying and coating facilities
Eden PhillipsPerspective based on aggregated IP Security Depot and affiliated engineering team experience.
This switch addresses a critical gap in hazardous area IP surveillance: delivering sufficient power (60W per port) to explosion-protected cameras while maintaining full ATEX/IECEx compliance. The dual certification approach (gas and dust groups) maximizes deployment flexibility across diverse industries. The modular port structure—eight PoE++ plus dual data plus four SFP—enables both camera power distribution and redundant network paths through single uplink.
The flameproof enclosure design with M25 entries integrates directly into existing hazardous area control panels without requiring external breakout cabinets. Five-year warranty and PVC-free, RoHS-compliant construction reflect Axis' commitment to long-term reliability and environmental responsibility in demanding applications.
