Form Factor:
PTZ
Resolution:
15MP
Lens Type:
10x optical zoom
IR Low Light:
Day/Night
Features:
WDR
Video Compression:
H.264
Audio Support:
Two-way
PoE Power:
PoE+ (802.3at)
IP Rating:
IP52
Type:
PTZ
Product Type:
PTZ
Night Vision:
IR
Housing Color:
White
Environment Rating:
Outdoor
Wdr:
WDR
Ir Lowlight:
Day/Night
Compression:
H.265; H.264; Zipstream
Onvif:
Yes
Audio:
Audio input
Lens Focal Length:
Varifocal 4.7-47 mm (10x optical zoom)
Color:
0.09luxat30IREF1.6 Videostreaming
Application:
Programming Interface
Environment:
Power
Image Sensor:
CMOS
Lightfinder:
Lightfinder 2.0
Wide Dynamic Range:
Forensic WDR
Min Illumination/ Light Sensitivity (b/w:
0.01 lux
Signed OS:
Yes
Secure Boot:
Yes
Local Storage (memory Card Slot:
Yes
Operating Temperature:
0 to 40 °C
Max Frames Per Second:
25/30
Day And Night Functionality:
Yes
Horizontal Field Of View:
61.8-6.7 °
Vertical Field Of View:
36.3-3.8 °
Pan Range:
360 with autoflip
Tilt Range:
0 to -180
Guard Tour:
limited guard tour
Digital Zoom:
12
Zipstream:
Yes
H.264:
Baseline, High, Main
H.265:
Yes
PoE Class:
4
Variants:
AXIS M5000-G EU AXIS M5000-G JP AXIS M5000-G US
Minimum Illumination B/W:
0.01 lux at 30 IRE F1.6; 0.01 lux at 50 IRE F1.6 Overview cameras:; 0.03 lux at 30 IRE F2.0; 0.03 lux at 50 IRE F2.0
Shutter Speed:
PTZ camera: 1/66500 s to 2 s Overview cameras: 1/50000 s to 2 s
Model:
ARTPEC-7
Frame Rate:
PTZ camera: Up to 25/30 fps with power line frequency 50/60 Hz Overview cameras: Up to 12 fps with power line frequency 50/60 Hz
Streaming Modes:
unicast and multicast
Video Streaming:
Multiple, individually configurable streams in H.264, H.265 and Motion JPEG Axis Zipstream technology in H.264 and H.265 Controllable frame rate and bandwidth VBR/ABR/MBR H.264/H.265 Low latency mode Video streaming indicator
Image Settings Scene Profiles:
indoor, forensic
Signal-to-noise Ratio:
>55 dB
Security:
IP address filtering, HTTPS encryption, IEEE 802.1x (EAP-TLS) network access control, user access log, centralized certificate management
Network Protocols:
IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPS , HTTP/ 2, TLS , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP , SNMP v1/v2c/v3 (MIB- II), DNS/DNSv6, DDNS, NTP, PTP, NTS, RTSP, RTCP, RTP, SRTP/RTSPS, TCP, UDP, IGMPv1/v2/v3, DHCPv
Video Management Systems:
Compatible with AXIS Camera Station Edge, AXIS Camera Station Pro, AXIS Camera Station 5, and video management software from Axis’ partners available at axis.com/vms .
Onscreen Controls:
Focus recall area Video streaming indicator Privacy masks Day/night shift
Event Conditions Device Status:
above operating temperature, above or below operating temperature, below operating temperature, IP address removed, network lost, new IP address, storage failure, system ready, within operating temperature
Event Conditions Edge Storage:
recording ongoing, storage disruption, storage health issues detected
Event Conditions I/O:
manual trigger, virtual input MQTT subscribe
Event Conditions PTZ:
PTZ malfunctioning, PTZ movement, PTZ preset position reached, PTZ ready
Scheduled And Recurring:
scheduled event
Event Conditions Video:
average bitrate degradation, day-night mode, live stream open
Event Actions Guard Tours:
Run while the rule is active, start MQTT publish
Event Actions Notification:
email, HTTP, HTTPS, TCP and SNMP trap
Event Actions Record Video:
SD card and network share
Upload Of Images Or Video Clips:
FTP, SFTP, HTTP, HTTPS, network share and email Day-night mode, overlay text, preset positions, WDR mode
Data Streaming:
Event data
Built-in Installation Aids:
Pixel counter
Included:
AXIS Loitering Guard, AXIS Video Motion Detection, audio detection, shock detection, advanced gatekeeper Support for AXIS Camera Application Platform enabling installation of third-party applications, see axis.com/ acap
EMC Japan:
VCCI Class A
EMC USA:
FCC Part 15 Subpart B Class A
EMC Canada:
ICES-3(A)/NMB-3(A)
Safety:
CAN/CSA C22.2 No. 62368-1, IEC/EN/UL 62368-1
Wireless:
EN 62311, EN 300220-2, EN 301489-1, EN 301489-3, MIC, FCC Part 15 Subpart C, RSS-210
Cybersecurity:
ETSI EN 303 645, BSI IT Security Label, FIPS-140, EN 18031-1
Documentation:
AXIS OS Hardening Guide Axis Vulnerability Management Policy Axis Security Development Model AXIS OS Software Bill of Material (SBOM) To download documents, go to axis.com/support/ cybersecurity/resources To read more about Axis cybersecurity suppor
Casing:
IP51-rated Repaintable plastic casing, polycarbonate (PC) dome
Sustainability:
PVC free, BFR/CFR free
Connectors:
RJ45 10BASE-T/100BASE-TX/1000BASE-T PoE DC input terminal block
Operating Conditions:
0 °C to 40 °C (32 °F to 104 °F) Humidity 10–85% RH (non-condensing)
Dimensions Height:
138 mm (5.4 in), ø 247 mm (9.7 in)
Weight:
1.95 kg (4.3 lb)
Optional Accessories:
AXIS TM5601 Conduit Back Box AXIS TM5801 Black Dome For more accessories, see axis.com
Languages:
English, German, French, Spanish, Italian, Russian, Simplified Chinese, Japanese, Korean, Portuguese, Polish, Traditional Chinese, Dutch, Czech, Swedish, Finnish, Turkish, Thai, Vietnamese
Power Requirement:
30W PoE 802.3at or 24V
Ingress Protection:
IP52
Shipping Weight:
5.450 lb
Mounting Type:
Surface mount or Axis PTZ standard mount
Country of Origin:
Thailand
UNSPSC:
46171610
