APC by Schneider Electric AR2500 NetShelter SV 42U 600mm Wide x 1200mm Deep Rack Enclosure

Overview

The APC by Schneider Electric AR2500 is a 42U free-standing open-frame rack enclosure built to house mixed-use IT and security infrastructure in data centers, server rooms, and wiring closets. At 600mm wide and 1200mm deep, it accommodates the full depth of modern 1U-4U servers, patch panels, NVRs, and networking gear without the cable-management compromises you get from shallower cabinets. The 1200mm depth is the spec that matters most here — it means you can mount front-to-back without leaving equipment hanging off the rear rails or fighting cable bend radius on dense fiber runs.

Constructed from steel and finished in black, the AR2500 meets rack enclosure standards EIA-310E, UL 2416, and UL 60950-1 — the certifications that enterprise facility teams and data center operators require for compliance sign-off and insurance purposes. The 19-inch mounting width is industry-standard, so virtually every rackmountable device in your BOM will drop straight in.

Key Features

• 42U Capacity: 42 rack units accommodates a full head-end stack — multiple NVRs, a managed PoE switch, a UPS, patch panels, and a KVM — without requiring a second cabinet. That matters when floor space costs money or when your equipment room has a fixed footprint.
• 1200mm Depth: Greater than 36 inches of usable depth means full-depth 2U and 4U servers mount flush on both front and rear rails. No overhangs, no improvised rail extensions. This depth is specifically suited to network video recorders and enterprise storage appliances with long chassis.
• 600mm Width: The 600mm (roughly 24-inch) form factor is the standard data center column width. It fits standard hot-aisle/cold-aisle layouts and pairs correctly with APC's PDU and cable management accessories without leaving dead space on the sides.
• 19-Inch Mounting Standard: EIA-310E-compliant 19-inch mounting rail spacing means universal compatibility with rackmount equipment from any vendor — no adapter brackets, no proprietary workarounds.
• Steel Construction: The all-steel chassis handles the static and dynamic load of fully populated 42U builds. For a mixed-use rack with UPS, servers, and switching gear, structural rigidity matters more than it does in a lightly loaded AV rack.
• Free-Standing Form Factor: No wall anchoring required, which simplifies installation in raised-floor environments and allows repositioning during buildouts. Pair with the appropriate rack accessories — side panels, top panels, or blanking panels — to control airflow once the rack is populated.
• UL 2416 and UL 60950-1 Certifications: These listings satisfy the code compliance requirements most frequently cited by AHJs and enterprise IT governance teams. If your project requires certified enclosures, the AR2500 clears both without additional documentation.

Integration and Compatibility

The AR2500 integrates with APC by Schneider Electric's broader NetShelter SV ecosystem — side panels, roof sections, blanking panels, and PDUs mount directly without modification. The standard EIA-310E rail pattern also accepts third-party rackmount equipment from virtually any vendor. For physical security head-end deployments, this rack pairs well with managed PoE switches, NVRs, and access control servers that require a structured, compliant enclosure. The 42U height and 1200mm depth give integrators enough room to plan cable runs, maintain service access, and comply with minimum bend-radius requirements on Cat6A and fiber.

Frequently Asked Questions

Q: What is the rack unit capacity of the AR2500?

A: The AR2500 provides 42U of rackmount space, sufficient for a fully populated mixed-use IT or physical security head-end.

Q: What are the external dimensions of the AR2500?

A: The AR2500 is 600mm wide and 1200mm deep. Overall height falls in the greater-than-6-foot to 7-foot range. Confirm exact height with the manufacturer datasheet before ordering for low-ceiling installations.

Q: What certifications does the AR2500 carry?

A: The AR2500 is listed to UL 2416 and UL 60950-1 and meets EIA-310E rack standard dimensions.

Q: Is the AR2500 compatible with standard 19-inch rackmount equipment?

A: Yes. The 19-inch EIA-310E mounting rail spacing is universal — any standard 1U through 4U rackmount device will install without adapter brackets.

Q: Does the AR2500 require wall anchoring?

A: No. It is a free-standing enclosure. Wall or floor anchoring may still be required by local seismic codes depending on your jurisdiction — verify with your facilities team.

Q: What material is the AR2500 enclosure made from?

A: The chassis is steel, finished in black. Steel construction provides the structural rigidity needed for fully populated 42U builds with servers, UPS units, and networking gear.

Karl Wilson

The AR2500's 1200mm depth is the spec I look at first when spec'ing this enclosure for physical security head-ends. Most security integrators default to 800mm cabinets, then discover their 2U NVRs and full-depth servers are fighting cable management at the rear — the AR2500 eliminates that entirely with an extra 400mm of clearance that lets you dress Cat6A runs properly without sacrificing service access.

Technical Highlights:

• 42U Height: Enough vertical space to stack a full NVR array, managed PoE switches, access control servers, and a line-interactive UPS in a single enclosure — reducing the rack count and simplifying power distribution planning.
• EIA-310E / 19-Inch Rail Standard: Universal mounting compatibility means you're not locked into a proprietary accessory ecosystem. Any vendor's 1U-4U gear drops in without adapter brackets, which matters when you're integrating multi-vendor security hardware.
• UL 2416 + UL 60950-1 Listings: Both certifications are regularly cited in enterprise IT security procurement requirements and AHJ inspections — having them pre-listed on the AR2500 removes a documentation burden from the project closeout package.

Deployment Considerations:

• At 600mm wide and 1200mm deep, verify your equipment room aisle width before delivery — 1200mm-deep cabinets require more front-clearance than standard 800mm units, particularly in tight IDF closets.
• The free-standing design simplifies installation on raised floors, but check local seismic zone requirements before skipping floor anchor hardware — some jurisdictions mandate anchoring for cabinets above a certain height or weight when fully populated.

For a mixed-use physical security head-end — NVRs, PoE switching, access control, and a UPS in one enclosure — the AR2500 is correctly specified. It is less suited to shallow-depth deployments (patch-panel-only or wall-mount scenarios) where a 4-post open-frame or a 600mm-deep cabinet would reduce the footprint without sacrificing usable U-space.
