Vertiv APS EBC with 6 Vrla Battery Strings - AS7EBC6CCUBXLKB

Vertiv AS7EBC6CCUBXLKB Vertiv APS EBC With 6 Vrla Battery Strings

Overview

The Vertiv AS7EBC6CCUBXLKB is a 14-bay External Battery Cabinet (EBC) specifically designed to extend the runtime of Vertiv Liebert APS UPS systems. This unit houses up to six Valve Regulated Lead-Acid (VRLA) battery strings, providing crucial backup power duration for sensitive IT equipment, network closets, or edge computing deployments during utility outages. Its purpose is to bridge the gap between a power failure and generator startup, or to allow for graceful shutdown of protected loads.

Compatibility

This EBC model, AS7EBC6CCUBXLKB, is engineered for direct integration with the Vertiv Liebert APS UPS platform. It is designed to accommodate six VRLA battery strings. Note that separate battery strings (e.g., AL7EBC6HHUBXLKB for Lithium-Ion) are required and sold independently. The unit also supports the optional 10 Amp Charger Module (APSCHRGRMOD) for use with third-party battery cabinets, and requires specific EBC cables (APSEBCCBL1M, APSEBCCBL3M, APSEBCCBL5M) for connection, also sold separately.

Installation Notes

Installation requires connecting the EBC to the Liebert APS UPS using appropriate EBC cables. Ensure the UPS is powered off and disconnected from utility power before making any connections. The internal battery strings must be correctly installed and wired according to the UPS manufacturer's guidelines. The EBC must be placed on a level surface and have adequate ventilation. Consult the Liebert APS UPS installation manual for detailed wiring, configuration, and safety procedures. The charger module (APSCHRGRMOD) is optional and intended for specific scenarios, not standard operation with the Liebert APS UPS.
