Vertiv APS EBC with 3 Vrla Battery Strings - AS7EBC3CCUBXLKB

Vertiv AS7EBC3CCUBXLKB Extended Battery Cabinet

Overview

The Vertiv AS7EBC3CCUBXLKB is an external battery cabinet designed to expand the runtime of compatible Vertiv Liebert APS UPS systems. This unit specifically houses three VRLA (Valve Regulated Lead Acid) battery strings, providing a significant increase in backup power duration for mission-critical applications where continuous operation is paramount. It's intended for deployments requiring extended autonomy beyond the UPS's internal battery capacity.

Compatibility

This Extended Battery Cabinet (EBC) is designed for use with the Vertiv Liebert APS UPS line. Specifically, it is compatible with models designated for VRLA battery configurations, such as AS7EBC1CCUBXLKB through AS7EBC7CCUBXLKB. It also supports the use of an optional 10 Amp charger module (APSCHRGRMOD) for third-party battery cabinets if needed, and requires specific EBC cables (APSEBCCBL1M, APSEBCCBL3M, APSEBCCBL5M) for connection to the UPS, sold separately.

Installation Notes

Ensure proper ventilation around the battery cabinet to prevent heat buildup, which can shorten battery life. The cabinet requires a stable, level surface. Connection to the UPS requires appropriate EBC cables, which must be sourced separately. Consult the Liebert APS UPS documentation for specific connection diagrams and power requirements. The internal battery strings are factory-installed but require final connection and commissioning by qualified personnel.
