Main Input Voltage:
208V
Main Output Voltage:
208V
Kw Rating:
4200W
Rated Power In Va:
6000VA
Input Connection Type:
NEMA L6-30P (30A)
Output Connection Type:
(2) NEMA L6-20R (1) NEMA L6-30R
Number Of Rack Unit:
8U
Cable Length:
10 ft (3.05 m)
Number Of Cables:
1
Battery Type:
Lead-Acid battery
Included Battery Modules:
3
Battery Slots Empty:
0
Typical Recharge Time:
4 h
Additional Information:
Configurable for 208 or 240 nominal output voltage
Battery Charge Power (Watts:
458 W rated
Battery Life:
3…5 year(s)
Replacement Battery:
SYBT2
Extendable Run Time:
1
Product Web Sub-Family:
2kVA power increments
Number Of Power Module:
4
Number Preinstalled Power Module:
3
Number Of Power Module Free Slots:
1
Number Of Power Module Filled Slots:
3
Color:
Black
Dimensions:
14.02 in (35.6 cm)
Weight:
294.63 lb(US) (133.64 kg)
Mounting Location:
Front
Mounting Preference:
Lower
Mounting Mode:
Rack-mounted
Two Post Mountable:
0
Input Frequency:
50/60 Hz +/- 5 Hz auto-sensing
Number Of Input Connectors:
1 Hard Wire 3-wire (2PH + G)
Efficiency At Full Load:
89% full load
Input Power Factor At Full Load:
0.98
Max Configurable Power (Watts:
4200W
Harmonic Distortion:
Less than 5 % at full load
Output Frequency (Sync To Mains:
57...63 Hz for 60 Hz nominal sync to mains 60 Hz not synced
Crest Factor:
Up to 5 : 1
UPS Topology:
Double Conversion Online
Waveform Type:
Sine wave
Bypass Type:
Internal Bypass (Automatic and Manual)
Maximum Configurable Power In Va:
6000VA
Relative Humidity:
0…95%
Operating Altitude:
0...10000 ft
Ambient Air Temperature For Storage:
5…113 °F (-15…45 °C)
Storage Relative Humidity:
0…95%
Storage Altitude:
0…50000 ft (0.00…15240.00 m)
Acoustic Level:
60 dBA
Heat Dissipation:
1771 Btu/h
Free Slots:
1
Control Panel:
Multi-function LCD status and control console
