APC by Schneider Electric SRYLPD3 Modular Backplate Kit
Overview
The APC SRYLPD3 is a modular backplate designed to expand the output capacity of compatible APC Smart-UPS systems. It provides three NEMA L5-30R outlets, each rated for 30A at 120V, enabling you to connect multiple high-draw devices within a rack-mounted IT environment. This backplate is crucial for ensuring reliable power distribution to critical equipment, especially in data centers or server rooms where uptime is paramount. The SRYLPD3 model specifically addresses the need for multiple 30A connections from a single UPS module.
Compatibility
This backplate is engineered for use with APC's Smart-UPS Modular Ultra series. Specifically, it is designed to integrate with the following UPS models: APC Smart-UPS Modular Ultra 10kW (SRUX10K) and APC Smart-UPS Modular Ultra 15kW (SRUX15K). Ensure your UPS system is one of these specific models before purchasing to guarantee proper fit and function.
Installation Notes
Installation requires direct integration into the UPS module chassis. Ensure the UPS system is powered down and disconnected from the mains supply before attempting installation. The backplate connects internally to the UPS power distribution bus. Proper torque and secure connections are essential for safe operation and to prevent overheating. Refer to the APC installation guide for detailed procedures.
What's in the Box
- 1x APC SRYLPD3 Backplate Kit
- 1x Installation Guide
