APC by Schneider Electric SRYLPD5 Backplate Kit
Overview
The APC by Schneider Electric SRYLPD5 is a specialized backplate kit designed to expand power output capabilities for specific APC Smart-UPS Modular Ultra systems. It provides three NEMA L6-30R outlets, enabling you to connect high-draw equipment directly from your UPS. This is critical for dense server rack deployments where managing power distribution efficiently is paramount. The SRYLPD5 model specifically addresses the need for more robust outlet configurations beyond the standard offerings on some modular UPS units.
Compatibility
This backplate is engineered for direct integration with APC Smart-UPS Modular Ultra systems, specifically those identified by the SRYL series and compatible with the 2022-1622 chassis. It is not a universal power distribution unit and requires a compatible APC UPS chassis for installation and operation. Verify your UPS model number against the 2022-1622 specification to ensure proper fit.
Installation Notes
Installation of the SRYLPD5 backplate requires opening the UPS chassis. Ensure the UPS is powered off and disconnected from the mains supply before proceeding. The backplate typically mounts internally, replacing or augmenting an existing power distribution module. Refer to the APC Smart-UPS Modular Ultra installation guide for detailed, step-by-step instructions and safety precautions. Proper seating of the backplate and secure connection of its internal wiring harness are essential for reliable operation.
What's in the Box
- 1x APC SRYLPD5 Backplate Kit
- 3x NEMA L6-30R Outlets
- Mounting hardware
