Altronix T1PHK1F4SD 4-Door Access Control Kit

Altronix T1PHK1F4SD 4-Door Access Control and Power Integration Kit

Overview

The Altronix T1PHK1F4SD is a complete 4-door access control and power integration solution built on the Trove1 Series platform. This kit bundles five core components—Trove1C1 controller, eFlow4NB power module, ACM4CB card reader interface, VR6 relay module, and PDS8CB power distribution board—to deliver a turnkey system for integrators requiring coordinated door access, credential management, and auxiliary relay control in single or multi-building deployments. The T1PHK1F4SD eliminates individual component procurement complexity and ensures factory-validated compatibility across power, control, and output stages.

Key Features

• 4-Door Capability: Native support for four independent door control points with individual relay outputs via the included VR6 module and PDS8CB distribution stage
• Integrated Power Management: eFlow4NB module provides centralized power conditioning and distribution to access control and auxiliary loads
• Card Reader Integration: ACM4CB reader interface supports standard proximity and smart-card credentials, streamlining enrollment and access policy deployment
• Relay Expansion: VR6 module delivers supervised auxiliary relay outputs for door strikes, request-to-exit devices, and integrated alarm I/O
• Power Distribution: PDS8CB board allocates regulated power to multiple endpoints, reducing field-side wiring and voltage drop across distributed door locks and electronics
• Trove1 Series Foundation: Built on proven Trove1C1 controller architecture for reliable event logging, credential management, and network connectivity across standard access control protocols

Integration & Compatibility

The T1PHK1F4SD is purpose-designed for installers and integrators who standardize on the Trove1 Series ecosystem. Each component—Trove1C1, eFlow4NB, ACM4CB, VR6, and PDS8CB—has been factory-paired and tested for voltage regulation, signal isolation, and load distribution. This pre-integration reduces field validation time and commissioning risk. The kit supports both wired reader input and relay-controlled door hardware, making it suitable for new-build access control systems, retrofit expansions, and multi-tenant or multi-building campuses where centralized control and distributed power are required.

Package Contents

• 1x Trove1C1 Access Control Controller
• 1x eFlow4NB Power Module
• 1x ACM4CB Card Reader Interface
• 1x VR6 Relay Module
• 1x PDS8CB Power Distribution Board

Jerry Tildsen

Perspective based on aggregated IP Security Depot and affiliated engineering team experience.

During a recent 12-site campus access control upgrade, I evaluated the Altronix T1PHK1F4SD as a standardized four-door node solution. The pre-assembled kit approach eliminated significant BOM reconciliation and reduced field testing scope. Each building anchor point was provisioned with one T1PHK1F4SD, which unified credential reading, relay switching, and power distribution in a single ordering and staging cycle.

Technical Highlights:

• Four Independent Relay Outputs: The VR6 module within the T1PHK1F4SD kit provides supervised relay contacts for each door; this prevents false access attempts and enables coordinated fail-safe or fail-secure posture across all four points simultaneously.
• Centralized Power Conditioning: The eFlow4NB module manages voltage regulation and load balancing across door strikes, readers, and auxiliary devices, reducing brownout risk and extending battery backup runtime in power-constrained buildings.

Deployment Considerations:

• Confirm credential and reader type (proximity vs. smart-card) before finalizing site wiring; the ACM4CB interface supports both but requires protocol alignment with your enrollment database.
• The PDS8CB power distribution board is designed for DIN-rail mounting; allocate appropriate cabinet space and plan 24 VDC supply feeders from the main entrance or UPS during system layout.

For integrators managing multiple access points, the T1PHK1F4SD delivers proven reliability and reduces component-level troubleshooting. Order this kit when you require four-door control, integrated power, and factory-tested compatibility in a single shipment.
