Altronix RB7 Ultra-Sensitive Relay Module
The Altronix RB7 is a single-output relay module engineered for low-voltage DC control switching in security and access control systems. Operating from a selectable 7–12VDC or 24VDC input, the RB7 delivers switchable 120VAC or 28VDC output at up to 1A, making it the workhorse for triggering solenoid locks, alarm sirens, and auxiliary loads in compact control panels. The ultra-sensitive design minimizes input current draw, reducing strain on source circuits and simplifying integration with logic controllers and sensor outputs.
Key Features
- Ultra-Sensitive Design: Minimal input current requirement ensures compatibility with low-power logic outputs and sensor circuits without need for intermediate buffers.
- Dual Input Voltage Selection: 7–12VDC or 24VDC switchable configuration. Choose the voltage rail that matches your existing power architecture — no need for separate modules.
- Dual Output Voltage: 120VAC or 28VDC switchable output. Handle both AC line devices (sirens, strobes) and DC electromagnetic loads (solenoids, relays) from a single module.
- 1A Maximum Output Current: Sufficient for standard solenoid locks, alarm solenoids, and relay coils without external amplification for typical access control deployments.
- Single Relay Output: Straightforward control logic — direct wiring to alarm inputs, access control boards, or sensor-triggered switching logic with no conditional complexity.
- Compact Panel-Mount Form Factor: Horizontal DIN-rail mounting fits standard 19" equipment racks and wall-mounted control enclosures. Minimal footprint preserves panel real estate.
- Lifetime Limited Warranty: Altronix backing on a proven component design reduces procurement risk in long-term access control and alarm deployments.
The RB7 bridges the gap between low-voltage sensor and logic circuits (7–12V or 24V DC) and the higher-power line-voltage or secondary 28VDC devices that security systems demand. In door access control, the RB7 accepts a 24VDC signal from an access controller and switches power to a magnetic lock solenoid or door strike. In alarm systems, it accepts sensor input from a motion detector or door contact and energizes a siren or strobe relay without needing a dedicated relay bank. The selectable input voltage means you can standardize on a single module across 12V battery-backup installations and 24V hardwired power supplies — a logistics win for integrators managing mixed deployments.
Output switching between 120VAC and 28VDC is field-selectable via terminal connection, not a jumper or firmware setting. This design choice avoids installation errors that occur when integrators forget to reprogram settings before deployment. A technician can verify the correct output mode visually at the terminal block during final inspection. The 1A maximum output current is sufficient for industry-standard solenoid locks (typically 0.4–0.7A) and alarm solenoids, but exceeding this limit will trip the internal protection — know your load profile before specification.
Compatibility is straightforward: ONVIF-compliant access control systems, hardwired motion sensors, and legacy 24VDC alarm panels all present voltage outputs that drive the RB7. The module does not require network connectivity or firmware updates — it is purely analog switching hardware. This makes it immune to software obsolescence and simplifies compliance in high-security environments where air-gapped control logic is mandated. Pair the RB7 with a 24VDC power supply (Altronix AL1012 or similar) in a control enclosure, and you have a drop-in relay function for any legacy system that needs DC-to-AC or DC-to-DC switching without software overhead.
The Altronix RB7 is designed for environments where simplicity and reliability trump feature density. If your system needs a straightforward one-shot relay function, input voltage flexibility, and output voltage selection without edge analytics or cloud connectivity, this module delivers. It pairs naturally with Altronix power supplies, timers, and access control modules in integrated security enclosures. For access control integrators maintaining multi-site installations across mixed voltage architectures, the dual-input voltage support reduces spare-parts inventory and accelerates technician familiarity. The lifetime warranty reflects Altronix confidence in the design — a relay module should not fail in normal operation, and Altronix stands behind that expectation.
