Altronix 6030 Programmable Timer Relay Module
The Altronix 6030 is a compact, field-proven programmable timer relay engineered for security and alarm system integrations requiring precise timed control of sirens, dialers, notification devices, and supervisory signaling. Operating from selectable 6VDC or 12VDC input, the module delivers a single SPDT relay contact rated 8A/120VAC or 28VDC, with adjustable timing from 1 second to 60 minutes and repeat-cycle (pulse/flasher) capability. The 3mA standby draw and board-level form factor (3" × 2.5" × 0.75") make it ideal for retrofit integration into crowded panel layouts and battery-backed systems where idle power consumption matters.
Key Features
- Programmable Timer Range: 1 second to 60 minutes in adjustable increments. Covers everything from rapid pulse sequences (door buzzers, warning flashers) to extended hold-down periods (siren cutoff delay, message playback).
- Single SPDT Relay Output: 8A/120VAC or 28VDC relay contacts. Sufficient for most alarm notification devices; low-impedance switching eliminates interaction with sensitive control circuits.
- Repeat Mode (Pulse/Flasher): Cyclic on/off operation for sounder notification patterns and visual alarm indicators. Reduces nuisance calls while maintaining occupant alertness.
- Guard Tour Supervisory Timer: Built-in timing logic for guard-patrol acknowledgment circuits. Flags missed check-ins automatically without external programming.
- Dual Input Voltage Option: Selectable 6VDC or 12VDC supply accommodates both legacy 6V backup batteries and standard 12V alarm panel power. No rewiring required when system voltage changes.
- Minimal Standby Draw: 3mA idle current; 75mA when relay energized. On 24/7 battery-backed systems, extends runtime by reducing quiescent load on backup supplies.
- Compact Board Form Factor: 3" × 2.5" × 0.75" footprint fits into existing enclosures and DIN-rail cabinets without major reconfiguration.
- Industrial Operating Range: -25°C to 55°C (-13°F to 131°F). Rated for unheated cabinets, outdoor kiosks, and temperature-variable environments without derating.
The 6030 is a field-installable timing and relay control module that integrates directly into 6V or 12V alarm systems, access-control platforms, and emergency notification architectures. Its programmable delay and pulse-mode capabilities eliminate the need for separate external timers or relay cards in many retrofit scenarios. The SPDT contact design (normally open, normally closed, common) provides flexibility for both energize-to-start and energize-to-stop logic, allowing integrators to sequence siren cutoff, dialer initiation, or guard-patrol acknowledgment without custom wiring harnesses.
Guard-tour supervision is a critical function in staffed facilities (retail, education, hospitality). The 6030's timer logic can be configured to expect a periodic signal from a mobile guard unit; if that signal does not arrive within the programmed interval, the relay triggers an alert to a central station or local keypad. This adds a layer of accountability to rounds-based security protocols without requiring a dedicated microcontroller or external supervision module.
Power consumption is engineered for battery-backup circuits: 3mA standby ensures that a 24/7 armed system draws minimal quiescent current from the UPS. Relay energization (75mA) is brief and predictable, making it compatible with sealed-lead-acid and nickel-cadmium batteries used in legacy panel backup supplies. The 8A contact rating at 120VAC handles standard siren and bell loads; the 28VDC option accommodates low-voltage sounder and strobe modules common in distributed alarm networks.
The module carries a lifetime limited warranty and is constructed to Altronix's standard industrial-grade reliability. It integrates with any 6V or 12V alarm control panel and requires no external power supply, microprocessor, or software license — making it a drop-in replacement for legacy timer modules and a cost-effective alternative to panel-native timing functions that consume precious memory and processor cycles in older systems.
Marty AllisonPerspective based on aggregated IP Security Depot and affiliated engineering team experience.
We've deployed the Altronix 6030 across hundreds of retrofit alarm system upgrades, and it remains one of the most reliable, no-nonsense timer modules in the field. What sets it apart is simplicity and predictability — no microprocessor, no firmware updates, no surprise behavior when power dips or the RTC battery expires. In our experience, the 6030 outlasts the panel it's mounted in. The guard-tour supervision feature is underutilized by integrators who don't understand it; we've seen it catch missed guard checks that other systems simply logged and ignored. The repeat-mode (pulse) capability is crucial for multi-tone siren sequencing and visual-alarm patterns that modern fire codes require. One practical note: the 1-second minimum timer is tight — on some legacy control panels, timing granularity at sub-second intervals can cause relay chatter, so we recommend confirming minimum pulse width with the host panel before field deployment.
Technical Highlights:
- Programmable Range (1 second to 60 minutes): Covers rapid pulse sequences for door hardware feedback and extended delays for dialer hold-off. The full range means you buy one SKU instead of three different delay modules. Field-adjustable potentiometer eliminates the need for software configuration or panel reprogramming.
- SPDT Relay Contact (8A/120VAC or 28VDC): Single output with common, normally open, and normally closed terminals lets integrators choose energize-to-start (siren activation) or energize-to-stop (cutoff) logic without rewiring. The 120VAC rating covers old-school electric bells; the 28VDC path handles modern low-voltage notification devices.
- Guard Tour Supervisory Timing: Built-in state machine waits for a periodic signal (check-in from a guard's keypad or mobile unit). If the signal does not arrive within the timer window, the relay triggers an alert. This removes the burden of manual supervision check-ins and flags no-show guards immediately instead of waiting for shift report.
- 3mA Standby Draw: On a 24-hour armed system with a 4Ah backup battery, 3mA contributes only ~15% of battery capacity per day. Compare this to modern networked panels (50mA+ idle), and the 6030's power efficiency becomes a genuine cost advantage on systems with long backup runtime requirements.
- Selectable 6VDC/12VDC Input: Legacy alarm systems ran 6V; modern panels standardized on 12V. A single 6030 board handles both without component swaps. No field modifications, no SKU confusion in the warehouse.
Deployment Considerations:
- Timing granularity: The 1-second minimum is enforced; sub-second pulse widths may cause relay chatter on some legacy panels. Test with the host panel before mass deployment to confirm acceptable pulse width.
- Guard-tour mode requires a momentary-closure input signal from the patrolling guard's keypad or mobile device. Ensure the control panel can provide that signal; some older systems cannot. Verify the signal timing (pulse duration vs. interval) against the module's supervisor window before installation.
- Relay contact rating (8A/120VAC) is adequate for standard sirenand bell loads but marginal for high-current sounders or multiple devices on the same contact. Use a separate relay or contactor for heavy-load notification circuits.
- The board-level form factor requires mounting inside an enclosure or control panel. There is no DIN-rail bracket or wall-mount case included; budget for integration labor or a mounting plate fabrication.
- Repeat-mode (pulse) operation draws 75mA per cycle. On battery-backed systems with short runtime budgets, confirm that the duty cycle does not exceed UPS capacity before extended alarm events.
The 6030 is a fit for legacy system retrofits, multi-building alarm networks where centralized timing is not feasible, and installations requiring guard-patrol accountability without a dedicated supervisory platform. It's not a replacement for modern VMS-integrated timing (which offers GUI programmability and remote override), but for panel-level, field-adjustable timing and relay switching, it remains the industry workhorse. For alarm integrators supporting installed base systems, the 6030 is a consumable that should always be on the truck. See the full Altronix catalog for compatible power supplies and enclosures.
