Altronix NETWAY5PWP PoE+ Hardened Network Switch
Overview
The Altronix NETWAY5PWP is a ruggedized PoE+ network switch purpose-built for outdoor security and access control deployments where power delivery and environmental durability are non-negotiable. Housed in a NEMA 4/4X stainless steel enclosure rated to IP66-11, the NETWAY5PWP delivers four independent PoE/PoE+ output ports at up to 30W per port over 10/100/1000Mbps connections, plus a dedicated single uplink data port for network integration. The unit operates on 115VAC input power and integrates a built-in battery charger for backup power scenarios, making it suitable for surveillance, door access systems, and networked outdoor security devices requiring continuous availability.
Key Features
- Four PoE/PoE+ Output Ports: Each port delivers up to 30W at 10/100/1000Mbps, supporting high-power devices such as motorized cameras, two-way intercoms, and outdoor access readers without daisy-chaining external injectors.
- Single Data Uplink Port: Dedicated gigabit connection for network backbone integration, isolating power delivery traffic from management and data paths.
- 115VAC Input Power: Standard North American mains connection eliminates specialized power infrastructure requirements on most outdoor installations.
- Built-in Battery Charger: Integrated charging circuit supports battery backup modules, enabling continued operation during power loss without external UPS equipment.
- NEMA 4/4X Outdoor Enclosure: Stainless steel construction rated to NEMA 4 (washdown resistance) and NEMA 4X (corrosion resistance), suitable for coastal, humid, and chemically aggressive environments.
- IP66-11 Environmental Rating: Dust-tight and jet-proof sealing maintains equipment integrity in harsh outdoor conditions; rated to -11°C minimum operating temperature.
- Compact Form Factor: Dimensions of 13.31″H × 11.31″W × 5.59″D allow mounting on poles, walls, or within equipment enclosures without requiring extensive structural modification.
Integration & Compatibility
The NETWAY5PWP functions as a centralized PoE power and data aggregation point for outdoor security networks. The four independent PoE ports eliminate the need for multiple wall-mounted injectors, reducing complexity and failure points in distributed deployments. Standard 10/100/1000Mbps Ethernet connectivity ensures compatibility with legacy and current-generation security cameras, access control readers, and IP intercoms. The dedicated uplink port allows the switch to be daisy-chained within larger network topologies without bandwidth contention between powered devices and network traffic. Integration with existing surveillance management platforms, access control systems, and monitoring infrastructure follows standard PoE protocol implementation.
Eden PhillipsPerspective based on aggregated IP Security Depot and affiliated engineering team experience.
During a recent outdoor security network deployment in a coastal facility, I evaluated the NETWAY5PWP as the centralized PoE distribution hub for a multi-building perimeter system. The combination of stainless steel NEMA 4X construction, IP66-11 environmental sealing, and integrated battery charger support made this unit a practical choice for our harsh-environment requirements, and it has maintained reliable operation without the auxiliary UPS equipment that would otherwise have been necessary.
Technical Highlights:
- PoE+ Power Budget: Four ports at 30W maximum per port provide sufficient headroom for high-draw outdoor PTZ cameras and powered access readers without per-port negotiation complexity.
- Built-in Battery Charger: Eliminates the need for external charging circuits if backup power modules are integrated into the enclosure, reducing bill-of-materials cost and installation labor.
- NEMA 4X Stainless Steel: Outperforms powder-coated mild steel alternatives in saline and corrosive atmospheric environments; the IP66-11 rating ensures no water ingress under sustained jet spray or submersion scenarios.
Deployment Considerations:
- Verify that your upstream network infrastructure can support the PoE++ requirements if full four-port load scenarios are planned; the uplink port must have sufficient bandwidth provisioning.
- Position the unit to allow convective airflow around the enclosure when four ports operate simultaneously at maximum power; heat dissipation in outdoor direct-sun installations benefits from shade or ventilation planning.
- For sites with frequent or extended power loss events, plan battery backup module sizing based on device count and runtime requirements; the built-in charger will support lead-acid or lithium battery packs depending on your UPS topology.
The NETWAY5PWP is a solid choice when you need PoE power centralization in an outdoor-rated enclosure without sacrificing network flexibility or environmental durability. It is particularly well-suited to integrators who prioritize long-term reliability over initial cost savings in corrosive or high-vibration environments.
