Altronix AL1024NK8QP Networked Dual Voltage Power Supply/Charger
Overview
The Altronix AL1024NK8QP is a networkable, dual voltage power distribution module designed for access control systems, door locks, and ancillary security devices. This unit converts 115VAC 60Hz input into eight individually selectable fuse-protected outputs delivering 12VDC or 5VDC at up to 6A, or 24VDC at up to 10A, for a total of 240W available power. Built-in LINQ technology enables remote monitoring, reporting, and control over your network, reducing service response time and system downtime.
Key Features
- Eight fuse-protected outputs: Individually selectable voltage configuration per output—choose 12VDC, 5VDC (both up to 6A), or 24VDC (up to 10A)—totaling 240W maximum power delivery
- Networked power management: Built-in LINQ technology facilitates real-time monitoring, reporting, and network-based control of the power supply/charger
- AC fail supervision: Instantaneous transfer to stand-by batteries upon AC power loss; automatic detection and notification of mains failure
- Battery supervision: Integrated battery fail and battery presence detection with diagnostic reporting via email and Windows Dashboard Alert notifications
- Overvoltage and short-circuit protection: Electronic regulation and filtering on all eight outputs safeguard connected devices from power surges and faults
- Built-in charger: Supports sealed lead acid and gel-type battery packs for uninterrupted backup power to critical access control and life-safety circuits
- Bi-colored LED status indicators: Visual verification of voltage on each output for quick field diagnostics and installation verification
- Two network-controlled Form C relays: Enable remote switching and automation of external circuits or alarm signals
- Stackable sub-assemblies: Modular design conserves rack or cabinet space without compromising power delivery or feature set
- Management interface software: Included USB flash drive and interface cables provide immediate access to monitoring and control dashboard
- CE European Conformity certification: Meets EU safety and electromagnetic compatibility requirements for international deployment
Integration & Compatibility
The AL1024NK8QP integrates seamlessly into networked security infrastructures where distributed power supervision is required. Email and Windows Dashboard Alert notifications eliminate the need for continuous manual monitoring, alerting system operators instantly to AC failure, battery depletion, or output faults. The eight independently configurable outputs accommodate mixed-voltage access control panels, badge readers, electromagnetic locks, and auxiliary devices within a single compact unit. Network control via LINQ enables integration into centralized building management systems, allowing operators to query power status, trigger relay actions, and receive real-time diagnostics from a single dashboard interface.
Package Contents
The AL1024NK8QP kit includes the AL1024ULx power supply base unit with integrated VR6 and LINQ8PD sub-assemblies, management interface software on USB flash drive, and all required interface cables for network and power connectivity.
Ted PerryPerspective based on aggregated IP Security Depot and affiliated engineering team experience.
I have evaluated the AL1024NK8QP during design and deployment of distributed access control systems across multi-site campuses. This unit delivers the network visibility and remote diagnostics that integrators and IT teams need to manage power infrastructure without constant on-site presence. The flexibility of eight individually selectable outputs is particularly valuable when deploying mixed-voltage systems where 24VDC panels, 12VDC locks, and 5VDC readers coexist on the same backbone.
Technical Highlights:
- Dual voltage flexibility: Support for 12VDC, 5VDC (up to 6A each), and 24VDC (up to 10A) on separate outputs within a single 240W module eliminates the need for multiple single-voltage supplies
- Network supervision: LINQ-based remote monitoring with email and Windows Dashboard alerting ensures AC fail, battery fail, and battery presence faults are surfaced to operations teams in real-time, not discovered during emergency response
- Battery-backed instantaneous transfer: Sealed lead acid or gel battery charging and supervision means access control remains operational during brief AC outages, protecting physical security during power instability
Deployment Considerations:
- Confirm battery type (sealed lead acid or gel) compatibility before installation; verify ampere-hour rating meets your hold-up time requirement for critical circuits
- Position the AL1024NK8QP in a climate-controlled cabinet or enclosure to maintain rated performance; network connectivity must be available at the installation point for remote supervision to function
- Allocate time during commissioning to configure output voltage assignments and test email/Dashboard alert delivery; this prevents false alarms and ensures operators recognize genuine faults
The AL1024NK8QP is a dependable choice for integrators who need centralized power distribution with remote intelligence. The combination of eight flexible outputs, battery supervision, and network-based diagnostics significantly reduces mean-time-to-repair for power-related outages and simplifies warranty support across distributed sites.
