Vivotek AI-104-010 External Infrared LED Illuminator
The Vivotek AI-104-010 is a purpose-built external infrared LED illuminator designed to extend night vision capabilities of security cameras in low-light and darkness conditions. Operating at 850nm wavelength with a concentrated 10-degree beam angle, this unit delivers focused infrared illumination up to 100 meters—making it essential for perimeter security, parking areas, and long-range surveillance applications requiring reliable nighttime visibility without visible light spillover.
Key Features
- 850nm infrared wavelength with 100-meter illumination range
- Tight 10-degree beam angle for precision, concentrated coverage
- Dual power connectivity: 24VAC or 12-24VDC input
- 24W nominal power consumption for efficient operation
- IP66 weatherproof enclosure—sealed against dust and water ingress
- IK10 impact rating—withstands physical stress and vandalism attempts
- Extended operating temperature range: -40°C to 50°C
- Lightweight 0.85 kg design for straightforward installation
Technical Specifications
Optical Performance: The 850nm infrared spectrum is invisible to the human eye, eliminating light pollution while providing excellent contrast and clarity on compatible IR-sensitive camera sensors. The tight 10-degree beam angle concentrates output for long-range applications, reducing wasted illumination and power consumption in focused surveillance scenarios.
Environmental Durability: IP66 rating ensures complete protection against powerful water jets and dust accumulation, critical for outdoor mounting in harsh weather conditions. IK10 impact resistance (20 joules) protects against intentional or accidental physical damage common in exposed perimeter installations.
Power Flexibility: Dual input support (24VAC or 12-24VDC) provides integration compatibility with most professional surveillance power supplies and infrastructure. 24W nominal consumption allows efficient operation without oversizing power delivery systems.
Applications
- Perimeter security and boundary surveillance
- Parking lot and vehicle monitoring
- Long-range outdoor coverage (50–100 meters)
- Loading dock and facility entry surveillance
- Gate and access point monitoring
- Complement to fixed-lens or varifocal surveillance cameras
Ted PerryPerspective based on aggregated IP Security Depot and affiliated engineering team experience.
The AI-104-010 fills a critical role in surveillance deployments where ambient lighting is insufficient or unavailable. Its 850nm wavelength strikes an optimal balance between range and sensor sensitivity—longer wavelengths (950nm+) offer marginally greater range but reduced clarity, while shorter wavelengths provide sharper images at cost of reduced distance. The 10-degree beam is ideally suited for fixed, long-distance monitoring rather than wide-area coverage; for broader illumination, multiple units or wider-angle IR lights are recommended.
The IP66/IK10 combination ensures this is a true outdoor-rated component capable of surviving seasonal extremes and intentional tampering. Integrators should pair this with 850nm-capable sensors (most modern IR-capable cameras support this wavelength) and verify power supply capacity before deployment.
