Viking ADA Compact VoIP Emergency Phone Blue - E-1600-BL-IP

Viking Electronics E-1600-BL-IP ADA Compact VoIP Emergency Phone Blue

Overview

The Viking Electronics E-1600-BL-IP is a compact, ADA-compliant VoIP emergency phone finished in blue fine-texture powder paint — built for applications where code compliance, weather resistance, and simple PoE deployment all have to coexist. At 5.0 x 5.0 x 2.25 inches, it fits flush or surface-mounts on elevator lobbies, parking structures, stairwells, and campus call-station locations without requiring a dedicated electrical circuit. Power comes from the same Cat5e/6 run as the SIP registration — no electrician, no conduit, no separate power supply. Browse the full Viking Electronics emergency communication line for panel phones, handset models, and door entry options.

Key Features

• ADA Compliance: Meets ADA requirements for emergency communication devices — relevant anywhere accessible egress routes require compliant call stations, including public buildings, universities, and transit facilities.
• IP66 Ingress Protection: Fully sealed against dust and direct water jets — this unit survives parking deck rain exposure and exterior wall installations without a protective housing. If you need submersion-grade protection, that requires IP67 or higher; IP66 handles everything short of that.
• PoE Class 1 (under 4W): Draws less than 4 watts from any 802.3af-capable switch port. With a Class 1 draw, a standard 15.4W port budget can host three or four endpoints before the port is stressed — minimal impact on PoE switch planning. No local power supply or UPS tap required at the device.
• 95 dB SPL @ 1m Speaker Output: Loud enough to cut through ambient noise in mechanical rooms, loading docks, and open parking structures — environments where a 70 dB handset phone would be inaudible. Hands-free operation means no handset to vandalize or freeze in place.
• Operating Range -40°F to 140°F: Rated for the full spread from Minnesota winters to Arizona rooftop installations. Most commercial-grade SIP phones are rated to 32°F at the low end; this unit goes 72 degrees further, which matters for unheated stairwells and exterior kiosks.
• SIP 2.0 / RFC3261 Protocol: Registers natively with any standards-compliant SIP call manager — Cisco UCM, FreePBX, 3CX, Avaya, and hosted SIP trunks. No proprietary gateway or license required. The single RJ45 (10/100 Base-T) connection handles both voice and configuration.
• Wideband Audio (G.722) Support: G.722 codec delivers HD-voice clarity at 7 kHz bandwidth versus the 3.4 kHz ceiling of G.711 — useful when the dispatcher needs to clearly understand a caller in a noisy environment on the first attempt. G.711u and G.711a are also supported for legacy codec compatibility.
• Gel-Filled Butt Connectors (x3): The three included gel-filled butt connectors are rated for outdoor burial and moisture-exposed terminations — a detail that matters in installations where the home-run cable enters from a wet wall cavity.
• 2-Amp Relay Contacts: Onboard dry-contact relay supports door strike, strobe light, or auxiliary alarm integration without an external relay module — one fewer device in the wiring closet.

Integration and Compatibility

The E-1600-BL-IP (often searched as E 1600 BL IP) connects via a single RJ45 port and registers to any SIP 2.0 RFC3261-compliant call manager. Codec negotiation covers G.711u, G.711a, and G.722. The 2-amp relay contacts support integration with access control door hardware or alerting devices. For multi-device deployments, pair with a managed PoE switch that supports 802.3af to centralize power and simplify cabinet layout. Regulatory compliance covers CE, FCC Part 15, and Canada ICES-003 Class A — suitable for US and Canadian deployments without re-certification. Humidity tolerance extends to 95% non-condensing in standard configuration and up to 100% in the EWP-rated variant (E-1600-BL-IPEWP); confirm which variant your application requires before ordering. Refer to the VoIP emergency phone category for additional mounting configurations and handset variants.

Frequently Asked Questions

Q: Does the E-1600-BL-IP require a separate power supply?

A: No. It draws under 4W via standard 802.3af PoE (Class 1) from the same RJ45 cable used for the network connection. No local power wiring is needed at the device.

Q: Is the E-1600-BL-IP compatible with third-party SIP call managers like Cisco, 3CX, or FreePBX?

A: Yes. It registers to any SIP 2.0 RFC3261-compliant system. No proprietary gateway or additional licensing is required.

Q: What is the ingress protection rating, and can it be installed outdoors?

A: The E-1600-BL-IP is rated IP66 — sealed against dust and direct water jets. It is suitable for exterior wall installations and covered parking structures. It is not rated for submersion; applications requiring immersion protection need IP67 or higher.

Q: What is the operating temperature range?

A: -40°F to 140°F (-40°C to 60°C), making it suitable for unheated stairwells, exterior kiosks, and rooftop equipment rooms in most North American climates.

Q: Does the unit support wideband (HD) audio?

A: Yes. The E-1600-BL-IP supports G.722 (wideband), G.711u, and G.711a codecs. G.722 delivers HD voice at 7 kHz bandwidth when both endpoints support it.

Q: What mounting options are available?

A: The unit supports both flush mount and surface mount configurations at 5.0 x 5.0 x 2.25 inches. Mounting hardware selection should be confirmed against your wall construction type.

James Everett

The E-1600-BL-IP draws under 4W at PoE Class 1 — that spec alone eliminates a surprising number of site-survey headaches. On projects where the electrical budget is tight or conduit routing to a remote call station is cost-prohibitive, this unit's single-cable SIP deployment is the reason it ends up on the BOM.

Technical Highlights:

• 95 dB SPL @ 1m: Loud enough for open parking structures and mechanical rooms without an external amplifier — most hands-free SIP phones top out around 85 dB, so the 10 dB headroom here is meaningful in high-ambient environments.
• G.722 Wideband Codec: HD voice at 7 kHz versus the 3.4 kHz ceiling of G.711 — when a dispatcher needs to understand a panicked caller in a noisy stairwell on the first exchange, codec bandwidth is not a trivial spec.
• -40°F to 140°F Operating Range: Most SIP endpoints are rated to 32°F. This unit goes 72 degrees colder — relevant for unheated parking structures, loading dock call stations, and exterior campus emergency posts in cold-weather climates.

Deployment Considerations:

• The three gel-filled butt connectors ship in the box and are rated for wet/buried terminations — use them on any home-run that enters from an exterior wall cavity or conduit with moisture ingress risk.
• The standard variant (E-1600-BL-IP) is rated to 95% non-condensing humidity; if the installation point sees condensation cycles or is fully exposed to weather, specify the EWP variant (E-1600-BL-IPEWP, rated to 100% humidity) instead — they are not interchangeable after install.

This unit fits best on ADA-required emergency call station deployments in parking structures, elevator lobbies, and campus pedestrian paths where a weatherproof, single-cable SIP endpoint with a loud speaker and onboard relay is the complete solution.
