IP Camera Accessories | Mounts, Enclosures, Lenses, IR & Power

Deployment Considerations

Environmental protection and weather resistance
Mounting stability and load support
Power and voltage compatibility
Cable management and termination quality
Compliance with local safety standards

Sub categories

Showing Results for Accessories

Compare

Out of stock
Hanwha

SKU: EP02-003399A

Hanwha EP02-003399A Cable Assembly 1830mm

Pre-assembled 1830mm cable for Hanwha Vision camera-to-NVR links
- HL-002S and HL-004 connectors integrated; ready to install without field assembly
- 1830mm length (72 inches) spans mid-range camera and component spacing
- White cable assembly designed for Hanwha Vision surveillance system compatibility
Special Order · Ships in 2-3 weeks

$16.99

Add to Cart
The item has been added
Compare

Out of stock
Hanwha

SKU: EP02-004111A

Hanwha EP02-004111A QND-7030R 3-Pin Alarm Cable

3-pin alarm cable for Hanwha QND-7030R surveillance integration
- 3-pin connector hardwired for external alarm inputs and outputs
- Direct integration with Hanwha QND-7030R network cameras and NVRs
- Professional-grade assembly for door sensors, motion detectors, relays
Special Order · Ships in 2-3 weeks

$174.99

Add to Cart
The item has been added
Compare

Out of stock
Hanwha

SKU: EP02-004278A

Hanwha EP02-004278A Replacement Cable XNP-6120

Genuine OEM cable for Hanwha XNP-6120H/HW outdoor PTZ cameras
- Compatible with XNP-6120H and XNP-6120HW mini PTZ camera models
- Outdoor-rated construction for reliable PTZ camera connectivity
- Authentic Hanwha replacement for system maintenance and repairs
Special Order · Ships in 2-3 weeks

$28.99

Add to Cart
The item has been added
Compare

Out of stock
Hanwha

SKU: EP02-004312D

Hanwha EP02-004312D Cable Assembly HCD-6070RA

HCD cable assembly for Hanwha Vision surveillance system integration
- HCD connector configuration for Hanwha Vision camera and recorder links
- IP66 and IK10 rated for outdoor professional security installations
- Replacement component for system expansion and equipment integration
Special Order · Ships in 2-3 weeks

$29.99

Add to Cart
The item has been added
Compare

Out of stock
Hanwha

SKU: EP02-004330B

Hanwha EP02-004330B XNB-6001 Remote Head Harness

8-meter remote head harness for Hanwha XNB-6001 modular cameras
- 8-meter cable length supports flexible remote head positioning in compact spaces
- 6-pin to 8-pin RJ12 connector integrates with XNB-6001 camera modules
- Compatible with interchangeable lens options from 2.8–12mm varifocal range
Special Order · Ships in 2-3 weeks

$60.84 $44.99 Save $15.85

Add to Cart
The item has been added
Compare

Out of stock
Hanwha

SKU: EP02-004412A

Hanwha EP02-004412A QNE-7080RV Camera Cable Assembly

Dedicated cable assembly for QNE-7080RV with PoE and 12VDC support
- 640mm aluminum-housed cable connects QNE-7080RV camera to network and power
- Supports both PoE and 12VDC input for flexible power configuration options
- Aluminum construction withstands outdoor and industrial surveillance environments
Special Order · Ships in 2-3 weeks

$7.99

Add to Cart
The item has been added
Compare

Out of stock
Hanwha

SKU: EP02-004421A

Hanwha EP02-004421A SATA Power Harness 200mm

SATA power harness for QRN-410S/QRN-810S NVRs, 200mm cable
- Integrated SATA and power connectors for direct mainboard-to-storage linking
- 200mm length routes cleanly inside NVR chassis with minimal strain
- Supports up to 6TB HDD per NVR for extended video storage capacity
Special Order · Ships in 2-3 weeks

$7.99

Add to Cart
The item has been added
Compare

Out of stock
Hanwha

SKU: EP02-004583A

Hanwha EP02-004583A QNO-8080R Camera Cable

15-pin cable for QNO-8080R motorized varifocal lens systems
- 450mm length with AWG28 wire for signal and power to IR cameras
- 15-pin male connector engineered for direct QNO-8080R compatibility
- Supports motorized lens control in compact surveillance installations
Special Order · Ships in 2-3 weeks

$13.99

Add to Cart
The item has been added
Compare

Out of stock
Hanwha

SKU: EP02-004589A

Hanwha EP02-004589A Microphone Cable Assembly

7-pin microphone cable assembly for QNV-6072R and QNV-6082R cameras
- 7-pin connector with aluminum housing and EMI shielding for audio input
- Direct compatibility with Hanwha QNV-6072R and QNV-6082R network cameras
- PoE (802.3af) powered microphone input for synchronized audio-video capture
Special Order · Ships in 2-3 weeks

$12.99

Add to Cart
The item has been added
Compare

Out of stock
Hanwha

SKU: EP02-004796A

Hanwha EP02-004796A XNF-9010RV Camera Harness

Direct-connect harness for XNF-9010RV with shielded 11-pin RJ45
- 590mm shielded cable eliminates adapters for faster pole and wall installs
- 11-pin RJ45 connector with EMI-resistant design for outdoor deployments
- Supports PoE++ and 12VDC power delivery to camera
Special Order · Ships in 2-3 weeks

$21.99

Add to Cart
The item has been added
Compare

Out of stock
Hanwha

SKU: EP06-003018B

Hanwha EP06-003018B Power Adapter

OEM power adapter for Hanwha PD-9501GR/AC surveillance systems
- Genuine Hanwha component engineered for PD-9501GR/AC compatibility
- PoE (802.3af) power delivery for surveillance equipment installations
- White housing, 2 lb unit designed for professional security deployments
Special Order · Ships in 2-3 weeks

$302.99

Add to Cart
The item has been added
Compare

Out of stock
Hanwha

SKU: EP06-003594D

Hanwha EP06-003594D Power Adapter

Genuine OEM power adapter for Hanwha FSP060-DIBAN2 surveillance systems
- Stable regulated DC output designed for continuous 24/7 surveillance operation
- PoE (802.3af) compatible with Hanwha security camera installations
- Replacement or spare unit maintains full manufacturer coverage on compatible devices
Special Order · Ships in 2-3 weeks

$86.99

Add to Cart
The item has been added
Compare

Out of stock
Hanwha

SKU: EP06-004403A

Hanwha EP06-004403A Power Adapter 1.67A

1.67A compact adapter for Hanwha IP cameras worldwide
- 1.67A output supports Hanwha network cameras and encoders
- Worldwide voltage compatibility for multi-region deployments
- Compact industrial-grade design rated for outdoor installations
Special Order · Ships in 2-3 weeks

$113.99

Add to Cart
The item has been added
Compare

Out of stock
Hanwha

SKU: EP06-004404A

Hanwha EP06-004404A Power Adapter 5A

5A power adapter for Hanwha FSP060 systems, worldwide rated
- 5A rated current for reliable power distribution across deployments
- Direct compatibility with Hanwha FSP060 power supply systems
- Worldwide geographic rating supports global surveillance installations
Special Order · Ships in 2-3 weeks

$81.99

Add to Cart
The item has been added
Compare

Out of stock
Hanwha

SKU: EP06-005620A

Hanwha EP06-005620A Power Supply Adapter

Dedicated power adapter for Hanwha PSE109GBRO surveillance systems
- Stable regulated output engineered for 24/7 professional security operations
- PoE (802.3af) support for network device integration in surveillance deployments
- Integrator-grade construction built for retail, corporate, and enterprise installations
Special Order · Ships in 2-3 weeks

$601.99

Add to Cart
The item has been added
Compare

Out of stock
Hanwha

SKU: EP06-005890A

Hanwha EP06-005890A 12V 52A AC-DC Power Supply

625W 12V/52A rack-mount AC-DC supply for multi-camera surveillance
- 625W continuous output at 12V DC, 52A capacity for simultaneous camera loads
- AC-DC conversion with regulated voltage for NVRs and networked security devices
- Industrial-grade rack-mount design for enterprise surveillance deployments
Special Order · Ships in 2-3 weeks

$117.15 $110.99 Save $6.16

Add to Cart
The item has been added

What to Look For When Buying

The six decisions that matter most before you spec.

Match Bracket to Camera + Surface

A dome camera mounted on a textured wall needs a wall-mount adapter with a gasket; mounted on a pole it needs a pole-mount arm; mounted on an eave it may need a pendant. Third-party brackets exist but brand-specific brackets include proper camera cable routing and weather gasketing. Buying a $40 generic bracket to save on a $80 Axis bracket usually costs more in installation time.

Enclosure NEMA Rating

NEMA 3R = light rain; NEMA 4 = splash + driving rain; NEMA 4X = above + corrosion resistance (coastal, industrial); NEMA 6 = temporary submersion. For weather-exposed camera enclosures, NEMA 4X is the commercial standard. For mission-critical outdoor gear, pair NEMA 4X enclosure + IP67 camera + IK10 vandal rating.

C/CS-Mount Lens Selection

Box cameras use interchangeable C-mount (17.526mm flange) or CS-mount (12.5mm flange). Lens focal length + sensor size determines field of view: a 4mm lens on a 1/3" sensor gives ~60° horizontal FOV. Our DORI guide covers lens selection by scene distance. F-stop matters for low-light; P-iris for auto-exposure.

IR Illuminator Wavelength

850nm IR is more efficient but produces a faint visible red glow (deterrent or accidental giveaway, depending on use case). 940nm is truly covert but requires ~2x the power for the same effective range, and many cameras have lower sensitivity at 940nm. Match illuminator wavelength to camera IR-cut filter spec, or image washout results.

Power Supply Sizing & Distance

12VDC cameras at 100ft from a power supply drop significant voltage over 18-gauge wire — a camera rated for 12V may see 10.5V at the camera end under load, triggering brownout resets. For long runs, use a higher-voltage power supply (24VAC or 48VDC) and step down at the camera. UL-listed surveillance power supplies (Altronix) publish voltage-drop tables.

Cable Jacket Rating

Indoor Cat6 is rated CM (communications); plenum-rated CMP is required for above-drop-ceiling runs per NFPA 70. Outdoor/direct-burial Ethernet is a different product (CMX, direct-burial gel-filled). Mixing jacket ratings causes code violations and fire inspector rejections. Always spec by run environment, not lowest-cost SKU.

Technology Stack

The specs and acronyms that actually affect outdoor performance.

NEMA vs IP Rating Systems

NEMA is the US enclosure standard (NEMA 1-13); IP is the international standard (IP00-IP68). Rough crosswalk: NEMA 4 ≈ IP66, NEMA 4X ≈ IP66 + corrosion, NEMA 6 ≈ IP67. Some spec sheets list both; when only one is given, the crosswalk is approximate. For coastal, industrial, and food-processing environments, specify NEMA 4X or IP66 + stainless steel.

C-Mount vs CS-Mount Lenses

C-mount: 17.526mm flange focal distance. CS-mount: 12.5mm flange. CS cameras accept both lens types (C lenses need a 5mm adapter ring); C cameras accept only C lenses. Most modern box cameras are CS-mount for lens flexibility. Lens thread is 1-inch × 32 TPI on both.

F-Stop / Iris

F-stop = focal length ÷ aperture diameter. Lower F-stop (wider aperture) means more light, better low-light performance, shallower depth of field. F1.4 is very low-light capable; F1.8 is common commercial spec. P-iris (precise iris) lenses auto-adjust aperture based on scene lighting — reduces over-exposure during day, improves low-light at night.

850nm vs 940nm IR

IR illuminators at 850nm are more energy-efficient and the sensitivity of most camera IR-cut filters peaks here — but 850nm produces a faint visible red glow from the LEDs. 940nm is invisible to human eye but requires ~2x the power or shorter effective range. Many covert-deployment cameras are re-tuned for 940nm sensitivity.

UL-Listed Power Supplies

Underwriters Laboratories listed power supplies meet safety standards for overcurrent, overvoltage, and enclosure isolation. UL 294 specifies additional requirements for access control; UL 603 for security burglary; UL 1310 for Class 2 power. Insurance and code requirements increasingly specify UL-listed supplies — particularly in commercial and institutional installations.

Plenum vs Riser vs PVC Cable

Plenum-rated (CMP) cable uses low-smoke FEP jacket for use above suspended ceilings where smoke spreads through return-air plenums. Riser (CMR) is for vertical shaft runs between floors. PVC (CM) is for open office runs only. Using CM in plenum spaces violates NFPA 70 — costly inspector rejection if caught.

Typical Deployment Scenarios

New Construction Retrofit

Cat6A plenum cable pulled to camera locations with proper service loops, 2-gang electrical boxes at each dome location with weatherproof backbox, Cat6A patch panel at the IDF, UL-listed power supplies for any 12V/24V camera, labeled and tested before cameras are mounted.

Coastal / Corrosive Environment

NEMA 4X stainless-steel enclosures for outdoor cameras, 316-grade stainless brackets, silicone dielectric grease on every connector, hot-dipped galvanized or powder-coated steel poles. Budget 15-25% more on accessories vs. standard outdoor — and plan for 3-5 year inspection cycles rather than 10.

Box-Camera LPR Application

Box camera with 50-150mm telephoto lens, dedicated 850nm IR illuminator at same height as camera, pole-mount bracket with junction box, UL power supply for camera + illuminator. LPR-specific enclosures with anti-reflective glass to avoid nighttime IR bloom. Typical deployment: dedicated lane camera, not general-purpose surveillance.

Parking Garage Retrofit

Existing analog coax cable replaced via NVT Phybridge or similar PoE-over-coax, vandal-resistant dome enclosures at ground level, low-profile bullet cameras on ceiling, LED-plus-IR-compatible illuminators to handle harsh fluorescent lighting. Enclosures rated for vehicle-exhaust environment.

Frequently Asked Questions

Do I need the OEM bracket for my camera, or will a generic bracket work?

For most commercial installations, specify the OEM bracket. Brand-specific brackets include proper cable routing, gasketed weather seals, and mounting-hole patterns matched to the camera — which matters more than the cost savings of a generic bracket. Generic brackets are acceptable for indoor standard-dome cameras on flat surfaces; for outdoor, vandal-rated, or pendant applications, use OEM.

What NEMA rating do I need for outdoor camera enclosures?

NEMA 4 for most weather-exposed deployments (driving rain, snow). NEMA 4X for coastal, industrial, or food-processing environments (adds corrosion resistance — typically stainless steel or fiberglass construction). NEMA 6 for temporary submersion or flood-prone areas. The IP-rating equivalent is IP66 for NEMA 4, IP66 + corrosion for NEMA 4X, IP67 for NEMA 6.

How do I choose the right lens focal length for a box camera?

Work backward from the scene. Identify the farthest point you need identification-grade coverage, use our DORI guide to calculate required pixels-per-foot at that distance, and match lens focal length + sensor size to deliver that PPF. A 4mm lens on a 1/3" sensor covers ~60° horizontal FOV; a 12mm lens on the same sensor covers ~20°. Wide FOV = shorter identification distance.

What's the difference between 850nm and 940nm IR illuminators?

850nm is more energy-efficient — you get more effective range per watt — but produces a faint visible red glow from the LEDs. 940nm is truly invisible to the human eye but requires about 2x the power for equivalent range, and many cameras have lower sensor sensitivity at 940nm. For deterrent visibility or cost-efficient long-range, 850nm; for covert applications, 940nm.

Can I power an IP camera with a generic 12V wall-wart?

Not for a commercial deployment. Generic wall-warts are unregulated, not UL-listed for security applications, and typically don't include surge protection. Use a UL-listed surveillance power supply (Altronix AL series, UL 294 or UL 603) with battery backup where required. PoE is preferred when possible — single cable, centralized power management, UPS-backed.

What cable jacket rating do I need for in-ceiling runs?

Plenum-rated (CMP) cable is required for any run through a return-air plenum space above suspended ceilings (most commercial buildings). Riser (CMR) for vertical shafts between floors. PVC (CM) for open office spaces only. Using non-plenum cable in a plenum space is a fire-code violation under NFPA 70 and will be rejected by inspectors. Budget plenum cable for any building where you're not 100% sure of the return-air path.
