IP Camera Accessories | Mounts, Enclosures, Lenses, IR & Power

Deployment Considerations

Environmental protection and weather resistance
Mounting stability and load support
Power and voltage compatibility
Cable management and termination quality
Compliance with local safety standards

Sub categories

Showing Results for Accessories

Compare

Out of stock
Hanwha

SKU: AM07-011319A

Hanwha AM07-011319A Case Plate Mount Assembly

Case plate mount assembly for Hanwha 9080VQ series surveillance
- Precision-engineered mount secures 9080VQ equipment in commercial/industrial sites
- Field-ready assembly designed for professional security integrator installations
- White housing, PoE-compatible mounting component for dependable camera support
Special Order · Ships in 2-3 weeks

$157.99

Add to Cart
The item has been added
Compare

Out of stock
Hanwha

SKU: AM07-011835A

Hanwha AM07-011835A Case Body Assembly

OEM case body assembly for XNO-6120R surveillance cameras
- IP67-rated white housing withstands harsh outdoor conditions year-round
- IK10 impact protection resists vandalism and physical damage
- Direct replacement part engineered to original Hanwha specifications
Special Order · Ships in 2-3 weeks

$47.99

Add to Cart
The item has been added
Compare

Out of stock
Hanwha

SKU: AM07-011945A

Hanwha AM07-011945A Top Cover Assembly

OEM top cover assembly for PNM9030V Wisenet cameras
- Weatherproof housing seals moisture and dust from camera internals
- Genuine Hanwha replacement part engineered for PNM9030V compatibility
- White housing maintains environmental protection in outdoor deployments
Special Order · Ships in 2-3 weeks

$103.99

Add to Cart
The item has been added
Compare

Out of stock
Hanwha

SKU: AM07-012538G

Hanwha AM07-012538G Case Top Assembly

OEM case top assembly for XNV-6081R-HW-HC environmental protection
- Genuine Hanwha replacement designed for XNV-6081R-HW-HC network cameras
- White case top assembly with environmental sealing and structural support
- OEM construction maintains proper fit and housing integrity in deployments
Special Order · Ships in 2-3 weeks

$73.99

Add to Cart
The item has been added
Compare

Out of stock
Hanwha

SKU: AM07-012870B

Hanwha AM07-012870B Case Top Assembly

OEM case top assembly for QND-8080R network video recorder
- Genuine Hanwha OEM component engineered for QND-8080R NVR compatibility
- Direct replacement part for system maintenance and field repairs
- White housing assembly weighs 2.5 lb for standard installation
Special Order · Ships in 2-3 weeks

$10.99

Add to Cart
The item has been added
Compare

Out of stock
Hanwha

SKU: AM07-012950F

Hanwha AM07-012950F Dome Cover Top Assembly

OEM dome cover top assembly for Hanwha QND-6011 series cameras
- White engineered polymer top cover—direct fit replacement, no modifications
- Genuine OEM component for QND-6011 dome camera housing maintenance and repair
- Lightweight 1 lb assembly for routine maintenance or complete camera rebuilds
Special Order · Ships in 2-3 weeks

$39.99

Add to Cart
The item has been added
Compare

Out of stock
Hanwha

SKU: AM07-012970B

Hanwha AM07-012970B Case Assembly for QNO-7082R

OEM case assembly for QNO-7082R replacement and repair
- IP67-rated housing with IK10 impact protection for field durability
- Genuine Hanwha component maintains system compatibility and coverage
- Lightweight 1 lb assembly supports quick swap-out maintenance
Special Order · Ships in 2-3 weeks

$38.99

Add to Cart
The item has been added
Compare

Out of stock
Hanwha

SKU: AM07-012974B

Hanwha AM07-012974B Rear Assembly for QNO7082R

OEM rear assembly for Hanwha QNO7082R cameras
- Genuine Hanwha replacement part maintains compatibility with QNO7082R
- Short-form rear assembly design for camera repair and system maintenance
- PoE (802.3af) powered component ready for professional security installations
Special Order · Ships in 2-3 weeks

$87.99

Add to Cart
The item has been added
Compare

Out of stock
Hanwha

SKU: AM07-013323B

Hanwha AM07-013323B Case Top Assembly

OEM case top assembly for Hanwha PNM-9084QZ network camera
- Genuine replacement housing with exact fit for PNM-9084QZ platform
- White weatherproof enclosure maintains camera protection and durability
- Lightweight 1 lb component for straightforward maintenance and installation
Special Order · Ships in 2-3 weeks

$96.99

Add to Cart
The item has been added
Compare

Out of stock
Hanwha

SKU: AM07-013686A

Hanwha AM07-013686A Case Bottom Assembly for PNM-9084RQZ

OEM case bottom assembly for PNM-9084RQZ with IP66/IK10 vandal protection
- IP66/IK10 rated housing resists dust, water, and impact in outdoor deployments
- Supports full 360° pan, 30–80° tilt, and 90° rotate with 30m IR capability
- NEMA4X compliant for corrosive environments down to -40°C operating range
Special Order · Ships in 2-3 weeks

$160.99

Add to Cart
The item has been added
Compare

Out of stock
Hanwha

SKU: AM07-014073A

Hanwha AM07-014073A Case Top Cap Assembly

OEM case top cap for Hanwha 9080VQ outdoor enclosures
- Genuine Hanwha replacement maintains weatherproof sealing for outdoor
- Direct fit for 9080VQ subsystems without modification or adapters
- White sealed housing protects against moisture, dust, and temperature
Special Order · Ships in 2-3 weeks

$69.99

Add to Cart
The item has been added
Compare

Out of stock
Hanwha

SKU: AM07-014438D

Hanwha AM07-014438D Dome Cover Assembly

OEM dome cover assembly with COAT2 coating for Hanwha cameras
- COAT2 specialized coating resists scratches and environmental contaminants
- Direct-fit replacement component for Hanwha dome camera systems
- Optical dome assembly maintains clarity across varied environmental conditions
Special Order · Ships in 2-3 weeks

$93.99

Add to Cart
The item has been added
Compare

Out of stock
Hanwha

SKU: AM07-014563A

Hanwha AM07-014563A Dome Cover Assembly

OEM dome cover for Hanwha XNP-XX00R series cameras
- Direct replacement assembly—no configuration or setup required
- Optical dome maintains clarity while protecting lens from dust and debris
- Compatible with XNP-XX00R network cameras; eliminates third-party fit risk
Special Order · Ships in 2-3 weeks

$170.99

Add to Cart
The item has been added
Compare

Out of stock
Hanwha

SKU: AM07-015080J

Hanwha AM07-015080J Case Top Assembly

Genuine OEM case top assembly for Hanwha QNV-8080R NVR systems
- Direct replacement part maintains thermal management and structural integrity
- Compatible exclusively with QNV-8080R NVR equipment for exact fit
- Authentic Hanwha component for professional integrators and maintenance work
Special Order · Ships in 2-3 weeks

$88.99

Add to Cart
The item has been added
Compare

Out of stock
Hanwha

SKU: AM07-015435B

Hanwha AM07-015435B Assembly Case Top

Genuine OEM assembly case top for Hanwha surveillance systems
- White case assembly top designed for Hanwha equipment enclosure protection
- Direct OEM replacement part engineered to original specifications
- PoE-compatible (802.3af) for integrated surveillance deployments
Special Order · Ships in 2-3 weeks

$209.99

Add to Cart
The item has been added
Compare

Out of stock
Hanwha

SKU: AM07-015454A

Hanwha AM07-015454A Assembly Front QNO-7012R

OEM assembly front for Hanwha QNO-7012R WiseNet surveillance
- Direct replacement component engineered for QNO-7012R compatibility
- 4MP resolution with IR and PoE (802.3af) power integration
- Genuine Hanwha part for system maintenance, repair, or expansion
Special Order · Ships in 2-3 weeks

$32.99

Add to Cart
The item has been added

What to Look For When Buying

The six decisions that matter most before you spec.

Match Bracket to Camera + Surface

A dome camera mounted on a textured wall needs a wall-mount adapter with a gasket; mounted on a pole it needs a pole-mount arm; mounted on an eave it may need a pendant. Third-party brackets exist but brand-specific brackets include proper camera cable routing and weather gasketing. Buying a $40 generic bracket to save on a $80 Axis bracket usually costs more in installation time.

Enclosure NEMA Rating

NEMA 3R = light rain; NEMA 4 = splash + driving rain; NEMA 4X = above + corrosion resistance (coastal, industrial); NEMA 6 = temporary submersion. For weather-exposed camera enclosures, NEMA 4X is the commercial standard. For mission-critical outdoor gear, pair NEMA 4X enclosure + IP67 camera + IK10 vandal rating.

C/CS-Mount Lens Selection

Box cameras use interchangeable C-mount (17.526mm flange) or CS-mount (12.5mm flange). Lens focal length + sensor size determines field of view: a 4mm lens on a 1/3" sensor gives ~60° horizontal FOV. Our DORI guide covers lens selection by scene distance. F-stop matters for low-light; P-iris for auto-exposure.

IR Illuminator Wavelength

850nm IR is more efficient but produces a faint visible red glow (deterrent or accidental giveaway, depending on use case). 940nm is truly covert but requires ~2x the power for the same effective range, and many cameras have lower sensitivity at 940nm. Match illuminator wavelength to camera IR-cut filter spec, or image washout results.

Power Supply Sizing & Distance

12VDC cameras at 100ft from a power supply drop significant voltage over 18-gauge wire — a camera rated for 12V may see 10.5V at the camera end under load, triggering brownout resets. For long runs, use a higher-voltage power supply (24VAC or 48VDC) and step down at the camera. UL-listed surveillance power supplies (Altronix) publish voltage-drop tables.

Cable Jacket Rating

Indoor Cat6 is rated CM (communications); plenum-rated CMP is required for above-drop-ceiling runs per NFPA 70. Outdoor/direct-burial Ethernet is a different product (CMX, direct-burial gel-filled). Mixing jacket ratings causes code violations and fire inspector rejections. Always spec by run environment, not lowest-cost SKU.

Technology Stack

The specs and acronyms that actually affect outdoor performance.

NEMA vs IP Rating Systems

NEMA is the US enclosure standard (NEMA 1-13); IP is the international standard (IP00-IP68). Rough crosswalk: NEMA 4 ≈ IP66, NEMA 4X ≈ IP66 + corrosion, NEMA 6 ≈ IP67. Some spec sheets list both; when only one is given, the crosswalk is approximate. For coastal, industrial, and food-processing environments, specify NEMA 4X or IP66 + stainless steel.

C-Mount vs CS-Mount Lenses

C-mount: 17.526mm flange focal distance. CS-mount: 12.5mm flange. CS cameras accept both lens types (C lenses need a 5mm adapter ring); C cameras accept only C lenses. Most modern box cameras are CS-mount for lens flexibility. Lens thread is 1-inch × 32 TPI on both.

F-Stop / Iris

F-stop = focal length ÷ aperture diameter. Lower F-stop (wider aperture) means more light, better low-light performance, shallower depth of field. F1.4 is very low-light capable; F1.8 is common commercial spec. P-iris (precise iris) lenses auto-adjust aperture based on scene lighting — reduces over-exposure during day, improves low-light at night.

850nm vs 940nm IR

IR illuminators at 850nm are more energy-efficient and the sensitivity of most camera IR-cut filters peaks here — but 850nm produces a faint visible red glow from the LEDs. 940nm is invisible to human eye but requires ~2x the power or shorter effective range. Many covert-deployment cameras are re-tuned for 940nm sensitivity.

UL-Listed Power Supplies

Underwriters Laboratories listed power supplies meet safety standards for overcurrent, overvoltage, and enclosure isolation. UL 294 specifies additional requirements for access control; UL 603 for security burglary; UL 1310 for Class 2 power. Insurance and code requirements increasingly specify UL-listed supplies — particularly in commercial and institutional installations.

Plenum vs Riser vs PVC Cable

Plenum-rated (CMP) cable uses low-smoke FEP jacket for use above suspended ceilings where smoke spreads through return-air plenums. Riser (CMR) is for vertical shaft runs between floors. PVC (CM) is for open office runs only. Using CM in plenum spaces violates NFPA 70 — costly inspector rejection if caught.

Typical Deployment Scenarios

New Construction Retrofit

Cat6A plenum cable pulled to camera locations with proper service loops, 2-gang electrical boxes at each dome location with weatherproof backbox, Cat6A patch panel at the IDF, UL-listed power supplies for any 12V/24V camera, labeled and tested before cameras are mounted.

Coastal / Corrosive Environment

NEMA 4X stainless-steel enclosures for outdoor cameras, 316-grade stainless brackets, silicone dielectric grease on every connector, hot-dipped galvanized or powder-coated steel poles. Budget 15-25% more on accessories vs. standard outdoor — and plan for 3-5 year inspection cycles rather than 10.

Box-Camera LPR Application

Box camera with 50-150mm telephoto lens, dedicated 850nm IR illuminator at same height as camera, pole-mount bracket with junction box, UL power supply for camera + illuminator. LPR-specific enclosures with anti-reflective glass to avoid nighttime IR bloom. Typical deployment: dedicated lane camera, not general-purpose surveillance.

Parking Garage Retrofit

Existing analog coax cable replaced via NVT Phybridge or similar PoE-over-coax, vandal-resistant dome enclosures at ground level, low-profile bullet cameras on ceiling, LED-plus-IR-compatible illuminators to handle harsh fluorescent lighting. Enclosures rated for vehicle-exhaust environment.

Frequently Asked Questions

Do I need the OEM bracket for my camera, or will a generic bracket work?

For most commercial installations, specify the OEM bracket. Brand-specific brackets include proper cable routing, gasketed weather seals, and mounting-hole patterns matched to the camera — which matters more than the cost savings of a generic bracket. Generic brackets are acceptable for indoor standard-dome cameras on flat surfaces; for outdoor, vandal-rated, or pendant applications, use OEM.

What NEMA rating do I need for outdoor camera enclosures?

NEMA 4 for most weather-exposed deployments (driving rain, snow). NEMA 4X for coastal, industrial, or food-processing environments (adds corrosion resistance — typically stainless steel or fiberglass construction). NEMA 6 for temporary submersion or flood-prone areas. The IP-rating equivalent is IP66 for NEMA 4, IP66 + corrosion for NEMA 4X, IP67 for NEMA 6.

How do I choose the right lens focal length for a box camera?

Work backward from the scene. Identify the farthest point you need identification-grade coverage, use our DORI guide to calculate required pixels-per-foot at that distance, and match lens focal length + sensor size to deliver that PPF. A 4mm lens on a 1/3" sensor covers ~60° horizontal FOV; a 12mm lens on the same sensor covers ~20°. Wide FOV = shorter identification distance.

What's the difference between 850nm and 940nm IR illuminators?

850nm is more energy-efficient — you get more effective range per watt — but produces a faint visible red glow from the LEDs. 940nm is truly invisible to the human eye but requires about 2x the power for equivalent range, and many cameras have lower sensor sensitivity at 940nm. For deterrent visibility or cost-efficient long-range, 850nm; for covert applications, 940nm.

Can I power an IP camera with a generic 12V wall-wart?

Not for a commercial deployment. Generic wall-warts are unregulated, not UL-listed for security applications, and typically don't include surge protection. Use a UL-listed surveillance power supply (Altronix AL series, UL 294 or UL 603) with battery backup where required. PoE is preferred when possible — single cable, centralized power management, UPS-backed.

What cable jacket rating do I need for in-ceiling runs?

Plenum-rated (CMP) cable is required for any run through a return-air plenum space above suspended ceilings (most commercial buildings). Riser (CMR) for vertical shafts between floors. PVC (CM) for open office spaces only. Using non-plenum cable in a plenum space is a fire-code violation under NFPA 70 and will be rejected by inspectors. Budget plenum cable for any building where you're not 100% sure of the return-air path.
