Frame Rate:
30fps
IP Video Input:
16-ch;Up to 12 MP resolution
Incoming Bandwidth:
160 Mbps
Outgoing Bandwidth:
256 Mbps
Video Outputs:
4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 1920 × 1080/60Hz
VGA Output:
1920 × 1080/60Hz
Video Output Mode:
HDMI/VGA independent output
Audio Input:
1-ch, RCA (2.0 Vp-p, 1 KΩ)
Audio Output:
1-ch, RCA (Linear, 1 KΩ)
Two-Way Audio:
1-ch, RCA (2.0 Vp-p, 1 KΩ, using the audio input)
Decoding Format:
H.265+/H.265/H.264+/H.264/MPEG4
Recording Resolution:
12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA /4CIF/DCIF/ 2CIF/CIF/QCIF
Synchronous Playback:
16-ch
Decoding Capability:
2-ch@12 MP (20 fps)/4-ch@8 MP (25 fps)/8-ch@4 MP (30 fps)/16-ch@1080p (30 fps)
Dual-Stream Recording:
Support
Stream Type:
Video, Video & Audio
Audio Compression:
G.711ulaw/G.711alaw/G.722/G.726
Network Protocol:
TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
Remote Connection:
128
Network Interface:
1, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
Connectivity:
Wired
Standard:
IEEE 802.3 af/at
SATA:
2 SATA interfaces
Capacity:
Up to 10 TB capacity for each HDD
USB Interface:
Front panel: 1 × USB 2.0; Rear panel: 1 × USB 3.0
Alarm In/Out:
4/1
Power Type:
100 to 240 VAC, 50 to 60 Hz
Consumption:
≤15 W (without enabling PoE)
Working Temperature:
-10 °C to 55 °C (14 °F to 131 °F)
Working Humidity:
10 to 90 %
Dimension (W × D × H:
385 × 315× 52 mm (15.2" × 12.4" × 2.0")
Weight:
≤ 3 kg (6.6 lb)
CE:
EN 55032:2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4
Obtained Certification:
CE, CB, UKCA, IC
Housing Color:
White
