Frame Rate:
60fps
IP Video Input:
8-ch;Up to 12 MP resolution
Incoming Bandwidth:
80 Mbps
Outgoing Bandwidth:
256 Mbps
Video Outputs:
4K/60Hz, 1080p/60Hz, multiple resolutions
VGA Output:
1920×1080@60Hz, 1280×1024@60Hz, 1280×720@60Hz, 1024×768@60Hz
CVBS Output:
1-ch BNC, 75Ω, PAL/NTSC
Audio Output:
1-ch, RCA (Linear, 1 KΩ)
Two-Way Audio:
1-ch, RCA (2.0 Vp-p, 1 KΩ, using the audio input)
Video Output Mode:
HDMI/VGA independent output
Dual-Stream Recording:
Support
Decoding Format:
H.265/H.265+/H.264/H.264+/MPEG4
Decoding Capability:
2-ch@12MP 20fps, 4-ch@8MP 25fps, 8-ch@4MP 30fps, 16-ch@1080
Synchronous Playback:
8-ch
Recording Resolution:
12 MP
Stream Type:
Video, Video & Audio
Audio Compression:
G.711ulaw/G.711alaw/G.722/G.726
Network Protocol:
TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
Remote Connection:
64
Network Interface:
1, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
Connectivity:
Wired
Standard:
IEEE 802.3 af/at
SATA:
2 SATA interfaces
Capacity:
Up to 10 TB capacity for each HDD
Alarm In/Out:
4/1
USB Interface:
Front panel: 1 × USB 2.0; Rear panel: 1 × USB 3.0
Power Type:
100 to 240 VAC, 50 to 60 Hz
Consumption:
≤ 15 W (without HDD and PoE off)
Working Temperature:
-10 to +55º C (+14 to +131º F)
Working Humidity:
10 to 90 %
Dimension (W × D × H:
385 × 315 × 52 mm (15.2" × 12.4" × 2.0")
Weight:
≤ 3 kg (6.6 lb.)
FCC:
Part 15 Subpart B, ANSI C63.4-2014
CE:
EN 55032:2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4
Housing Color:
White
