Hikvision DS-7608NI-I2/8P-2TB 8-Channel 4K NVR

Hikvision DS-7608NI-I2/8P-2TB 8-Channel 4K NVR with 2TB Storage

The Hikvision DS-7608NI-I2/8P-2TB is a professional-grade 8-channel network video recorder engineered for enterprise security deployments. This compact 1U appliance combines high-resolution 12MP (4K) recording capability with advanced H.265+ compression technology, delivering exceptional image quality while minimizing storage and bandwidth overhead. The integrated 8-port PoE switch streamlines camera deployment by consolidating power and data delivery over a single Ethernet connection, reducing installation complexity and costs.

Key Features

• 4K Recording Capacity: Support for 8 IP cameras at up to 12MP resolution for superior forensic detail and zoom capability
• H.265+ Video Compression: Industry-leading codec reduces storage consumption and bandwidth requirements by up to 70% versus H.264
• Integrated 8-Port PoE Switch: Delivers power and network connectivity to PoE cameras via single Ethernet cables, simplifying installation
• Dual SATA Storage: Supports two HDDs up to 10TB each for extended recording retention
• Flexible Output Options: HDMI and VGA outputs enable 4K display support (up to 3840×2160/60Hz)
• Dual-Stream Recording: Simultaneous high and low-bitrate streams optimize bandwidth and storage efficiency
• 8-Channel Synchronous Playback: Review all camera feeds simultaneously during forensic investigation
• Dual Remote Access: 64 concurrent remote connections via RTSP, HTTP, and HTTPS protocols

Technical Specifications

• Video Input: 8 channels at up to 12MP; 80 Mbps incoming bandwidth
• Video Output: HDMI (4K up to 60Hz) and VGA with independent operation; 256 Mbps outgoing bandwidth
• Recording Formats: H.265+, H.265, H.264+, H.264, and MPEG4 support
• Recording Resolutions: 12MP, 8MP, 6MP, 5MP, 4MP, 1080p, 720p, and legacy CIF formats
• Audio: 1-channel RCA input/output; G.711, G.722, and G.726 compression
• Network: 1 GbE RJ-45 interface; TCP/IP, IPv4/IPv6, DHCP, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, UPnP, HTTP/HTTPS
• Alarm I/O: 4 alarm inputs, 1 alarm output
• USB Ports: 1× USB 2.0 (front), 1× USB 3.0 (rear)
• Power: 100–240 VAC, 50–60 Hz; ≤15W without HDD and PoE disabled; ≤120W maximum with PoE active
• Operating Conditions: -10 to +55°C; 10–90% humidity
• Dimensions: 385 × 315 × 52 mm (1U form factor); 3 kg

Applications

• Enterprise surveillance and access control integration
• Retail and commercial facility monitoring
• Critical infrastructure and perimeter security
• Multi-site deployments requiring centralized management
• Forensic-grade video evidence collection and archival

Ted Perry

Perspective based on aggregated IP Security Depot and affiliated engineering team experience.

The DS-7608NI-I2/8P-2TB addresses key operational requirements for mid-scale security infrastructure. H.265+ compression delivers measurable TCO reduction—up to 70% storage savings directly translates to lower HDD replacement cycles and reduced power consumption for cooling and operation. The integrated PoE switch eliminates auxiliary power infrastructure, a significant labor and material advantage during new installations or system expansions.

Dual-stream recording enables adaptive bitrate delivery: high-quality streams for live monitoring and forensic investigation, low-bandwidth streams for bandwidth-constrained remote access. Synchronous 8-channel playback streamlines incident analysis by eliminating manual timeline correlation across individual camera feeds. The 256 Mbps outgoing bandwidth and 64 concurrent remote connections support enterprise-scale distributed access without dedicated WAN provisioning.

The compact 1U form factor and dual 10TB HDD capacity provide approximately 8–16 weeks of continuous 8-channel 12MP recording (storage duration varies with compression and frame rate settings). IEEE 802.3af/at PoE compliance ensures compatibility with standard enterprise switch infrastructure.
