Type:
Dome
Sensor Type:
1/3" Progressive Scan CMOS
Max. Resolution:
2688 × 1520
Min. Illumination:
0.009 Lux color / 0 Lux IR
Shutter Time:
1/3 s to 1/100,000 s
Day & Night:
IR cut filter
Angle Adjustment:
Pan: -30° to 30°, tilt: 0° to 75°, rotate: 0° to 360°
Lens Type:
Fixed focal lens, 2.8 mm, 4 mm, and 6 mm optional
Focal Length & FOV:
2.8mm (98.5° H), 4mm (78.8° H), 6mm (49.1° H)
Lens Mount:
M12
Aperture:
F1.6
DORI:
2.8mm: 54.6m D / 6mm: 128m D
Supplement Light Type:
IR
Supplement Light Range:
Up to 15 m
Main Stream:
2688×1520 @ 25fps
Sub-Stream:
640×480 @ 25fps
Third Stream:
1920×1080 @ 1fps
Video Compression:
Main stream: H.265+/H.265/H.264+/H.264, +more
Video Bit Rate:
32 Kbps to 8 Mbps
H.264 Type:
Baseline Profile/Main Profile/High Profile
H.265 Type:
Main Profile
Scalable Video Coding (SVC:
H.264 and H.265 encoding
Region Of Interest (ROI:
5 fixed regions for each stream
Protocols:
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour
Simultaneous Live View:
Up to 6 channels
API:
Open Network Video Interface, ISAPI, ISUP 5.0
User/Host:
Up to 32 users;3 levels: Administrator, Operator and User
Network Storage:
NAS (NFS, SMB/CIFS), ANR
Client:
iVMS-4200, Hik-Connect
Web Browser:
Plug-in required live view: IE10, IE11, +more
Image Parameters Switch:
Yes
Image Settings:
Rotate mode, saturation, brightness, contrast, sharpness, AGC, and white balance adjustable by client software or web browser
Day/Night Switch:
Day, Night, Auto, Schedule
Wide Dynamic Range (WDR:
120 dB
Image Enhancement:
BLC, HLC, 3D DNR, defog
Ethernet Interface:
1 RJ45 10 M/100 M self-adaptive Ethernet port
On-Board Storage:
microSD/SDHC/SDXC, up to 128GB
Alarm:
1 alarm input, 1 alarm output
Basic Event:
Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)
Smart Event:
Line crossing detection, intrusion detection, region entrance detection, region exiting detection;Scene change detection, unattended baggage detection, object removal detection
Power Type:
PoE
Material:
316L and anti-corrosion coating
Dimension:
Ø113 mm × 77.3 mm (4.45" × 3.04")
Package Dimension:
257 mm × 167 mm × 145 mm (10.12" × 6.57" × 5.71")
Weight:
Approx. 1500 g (3.3 lb.)
With Package Weight:
Approx. 1900 g (4.2 lb.)
Startup And Operating Conditions:
-30°C to +60°C,
Language:
33 languages: English, Russian, Estonian, Bulgarian, +more
General Function:
Heartbeat, password protection, privacy mask, watermark, IP address filter, mirror
EMC:
FCC: FCC-SDoC (ANSI C63.4, FCC Part15 sub B);CE: CE-EMC (EN 50130-4:2011+A1:2014, EN 55032:2015, EN 61000-3-2:2014, EN 61000-3-3:2013);RCM: AS/NZS 60950.1:2003 + Am1, Am2 and Am3, AS/NZS CISPR 32:2015;IC: IC-VoC (ICES-003 Issue 7:2020);KC: KN 301489-
Safety:
UL: UL 62368-1: 2014, CAN/CSA C22.2 No. 62368:2014;CB: IEC 62368-1:2014;BIS: IS 13252 (Part 1) 2010+A1:2013+A2:2015;LOA: SANS IEC60950-1
Environment Rating:
CE: CE-RoHS (RoHS Directive 2011/65/EU+2015/863)
Protection:
IP67 (IEC 60529-2013)
Anti-Corrosion Protection:
316L stainless steel, NEMA 4X, C5-M rated
Product Type:
Dome
Connectivity:
Wired
Resolution:
4MP
Night Vision:
IR
Housing Color:
White
Warranty:
5-year warranty
Package Contents:
Hikvision DS-2XC6142FWD-IS-4mm Camera. Mounting Accessories. Installation Guide. Warranty Information
eol:
true
