Frame Rate:
30fps
Sensor Type:
1/2.8" progressive scan CMOS
Min. Illumination:
0.001 Lux (B/W, F1.6, AGC ON)
Shutter Speed:
50 Hz: 1/25 s to 1/30,000 s;60 Hz: 1/30 s to 1/30,000 s
Focus:
auto;manual;semi-auto
Day & Night:
ICR
BLC:
yes
Features:
digital WDR
HLC:
yes
3D DNR:
yes
Defog:
yes
Regional Exposure:
yes
Regional Focus:
yes
White Balance:
auto;ATW;sodium lamp;fluorescent lamp;indoor;outdoor;MWB
Digital Zoom:
8x
Optical Zoom:
[PTZ channel] 10x
Privacy Mask:
up to 8 masks
General Function:
IP address filter;video tampering alarm;privacy mask
Optical Defog:
no
Focal Length:
4mm panoramic, 4.7-47mm PTZ 10x zoom
Zoom Speed:
approx. 2.5 s
Field of View:
80.7° × 3 panoramic, 58.6°-6.4° PTZ
Aperture:
[panoramic channel] F1.6, [PTZ channel] F1.6 to F3.0
IR Distance:
50 m
Movement Range (Pan:
[PTZ channel] 0° to 350°
Movement Range (Tilt:
[PTZ channel] 0° to 90°
Pan Speed:
0.1-60°/s
Tilt Speed:
Configurable 0.1-60°/s, preset 60°/s
Proportional Zoom:
[panoramic channel]: no; [PTZ channel]: yes
Presets:
300
Patrol Scan:
no
Pattern Scan:
no
Power-Off Memory:
[panoramic channel]: no; [PTZ channel]: yes
Park Action:
preset
3D Positioning:
[panoramic channel]: no; [PTZ channel]: yes
PTZ Status Display:
[panoramic channel]: no; [PTZ channel]: yes
Preset Freezing:
[panoramic channel]: no; [PTZ channel]: yes
Scheduled Task:
preset;dome adjust;dome reboot
Shake Detection:
no
Max. Resolution:
1920 × 1080
Stream Type:
main stream;sub-stream
Main Stream:
25/30 fps, 1920×1080
Sub-Stream:
20 fps (704×576, 640×480, 352×288)
Video Compression:
H.265;H.264;MJPEG
Video Bit Rate:
256 Kbps to 8192 Kbps
H.264 Type:
main profile;high profile
H.265 Type:
main profile
SVC:
yes
ROI:
yes
Audio Compression:
G.711alaw;G.711ulaw;G.722.1;G.726;MP2L2
Audio Bit Rate:
64 Kbps (G.711) / 16 Kbps (G.722.1) / 16 Kbps (G.726)
Face Capture:
no
Face Comparison:
no
Basic Event:
video tampering alarm;motion detection;exception
Smart Event:
intrusion detection;line crossing detection;audio exception detection
Smart Tracking:
no
Smart Record:
ANR
Protocols:
IPv4/IPv6;HTTP;HTTPS;802.1x;Qos;FTP;SMTP;UPnP;SNMP;DNS;DDNS;NTP;RTSP;RTCP;RTP;TCP/IP;DHCP;PPPoE;Bonjour
API:
Open API, ISAPI, Hikvision SDK
Simultaneous Live View:
Up to 4 × 4 channels
User/Host:
Up to 32 users. 3 levels: Administrator, Operator and User
Security Measures:
User & host authentication, HTTPS, 802.1x, IP filtering
Client:
iVMS-4200, iVMS-4500, iVMS-5200, Hik-Connect
Web Browser:
IE8 to 11, Chrome 31.0 to 44, Firefox 30.0 to 51
On-Board Storage:
up to 256 GB
Alarm Input:
1 alarm input
Alarm Output:
1 alarm output
Audio Input:
1 audio input, 2.0 to 2.4Vp-p, 1k Ohm±10%
Audio Output:
1 audio output
Power Type:
12 VDC; Hi-PoE
Power Consumption And Current:
12V 3.33A, Hi-PoE 42.5-57V 1.41A, 27W max
Operating Temperature:
-30℃ to 65℃ (-22°F to 149°F)
Material:
PC & Aluminum alloy
Dimensions:
Φ 271.3 mm ×243.1 mm (Φ 10.68" × 9.57")
Weight:
Approx. 3.2 kg (7.05 lb)
Protection:
IP66
Housing Color:
White
