Frame Rate:
30fps
Zoom Speed:
Approx.4.4 s (optical lens, wide-tele)
Working Distance:
10 mm to 1500 mm (wide-tele)
Aperture Range:
F1.5 to F4.5
Focal Length:
5.7 mm to 205.2 mm, 36× Optical
Field of View:
51.1-1.7° horizontal, 31.3-1.0° vertical
Network Storage:
Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB; NAS (NFS, SMB/ CIFS), ANR
Protocols:
IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, DHCP, PPPoE, UDP, IGMP, ICMP, Bonjour
API:
ONVIF (Profile S, Profile G, Profile T), ISAPI, SDK
Simultaneous Live View:
Up to 20 channels
User/Host:
Up to 32 users. 3 levels: Administrator, Operator and User
Security Measures:
User/host auth, HTTPS, IEEE 802.1x, IP filtering
Alarm Linkage:
Preset, Patrol, Pattern, Recording, Notifications, FTP/Email
Max. Resolution:
1920 × 1080
Main Stream:
60fps 1920×1080
Sub-Stream:
25-30fps, 352×288 to 704×576
Third Stream:
25fps@1920×1080 (50Hz) / 30fps@1920×1080 (60Hz)
SVC:
Yes
IR Distance:
200 m
Smart IR:
Yes
3D DNR:
Yes
Regional Exposure:
Yes
Regional Focus:
Yes
Sensor Type:
1/1.8" progressive scan CMOS
Min. Illumination:
Color: 0.002 Lux / B/W: 0.0002 Lux / 0 Lux IR
White Balance:
Auto/Manual/ATW/Indoor/Outdoor/Fluorescent/Sodium
Gain:
Auto/Manual
Shutter Time:
50Hz: 1/1 s to 1/30,000 s, 60Hz: 1/1 s to 1/30,000 s
Day & Night:
IR Cut Filter
Digital Zoom:
16×
Privacy Mask:
24 programmable polygon masks
Focus Mode:
Auto/Semi-automatic/Manual
Features:
120 dB
BLC:
Yes
HLC:
Yes
Optical Defog:
Yes
Image Stabilization:
PoE
Rapid Focus:
Yes
Movement Range (Pan:
360° endless
Pan Speed:
Configurable, from 0.1°/s to 210°/s, Preset Speed: 280°/s
Movement Range (Tilt:
From -20° to 90°
Tilt Speed:
Configurable, from 0.1°/s to 150°/s, Preset Speed: 250°/s
Proportional Zoom:
Yes
Presets:
300
Patrol Scan:
8 patrols, up to 32 presets for each patrol
Pattern Scan:
4 pattern scans, record time over 10 minutes for each scan
Power-Off Memory:
Yes
Park Action:
Preset/Pattern/Patrol/Auto/Tilt/Random/Frame/Panorama
3D Positioning:
Yes
PTZ Status Display:
Yes
Preset Freezing:
Yes
Scheduled Task:
Preset/Pattern/Patrol/Auto/Tilt/Random/Frame/Panorama Scan
Smart Tracking:
Auto Tracking (human/vehicle)
Smart Record:
ANR (Automatic Network Replenishment), Dual-VCA
ROI:
Eight fixed region for each stream
Perimeter Protection:
Intrusion, Line Crossing, Region Entrance, Region Exiting, Support alarm triggering by specified target types (human and vehicle), Filtering out mistaken alarm caused by target types such as leaf, light, animal, and flag, etc.
Event Detection:
Unattended Baggage, Object Removal, Audio Detection
Video Compression:
H.265+/H.265/H.264+/H.264/MJPEG
H.264 Type:
Baseline Profile/Main Profile/High Profile
H.264:
Yes
H.265 Type:
Main Profile
H.265:
Yes
Audio Compression:
G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/PCM
Client:
iVMS-4200, iVMS-4500, iVMS-5200, Hik-Connect
Web Browser:
IE 8-11, Chrome 31+, Firefox 30+, Edge 16+, Safari 11+
Alarm:
7-ch alarm input/2-ch alarm output
Audio Support:
1-ch audio input, 2.0 to 2.4Vp-p, 1k Ohm±10%, 1-ch audio output line level, impedance: 600Ω
Network Interface:
1 RJ45 10 M/100 M Ethernet Interface, Hi-PoE
CVBS:
Yes
RS-485:
HIKVISION, Pelco-P, Pelco-D, self-adaptive
Dimensions:
Φ 266.6 mm × 410 mm (Φ 10.50" × 16.14")
Weight:
Approx. 8 kg (17.64 lb)
Protection Level:
IP67, IK10, 6kV surge protection
Power Type:
24 VAC or Hi-PoE
Language (Web Browser Access:
32 languages
Working Environment:
-40°C to 70°C, ≤90% humidity
Housing Color:
White
