Zoom Speed:
Approx. 3.6 s (optical lens, wide-tele)
Working Distance:
10 mm to 1500 mm (wide-tele)
Aperture Range:
F1.6 to F3.5
Focal Length:
4.8 mm to 120 mm, 25× optical zoom
Field Of View:
Horizontal field of view: 57.6° to 2.5° (Wide-Tele); Vertical field of view: 34.4° to 1.4° (Wide-Tele); Diagonal field of view: 64.5° to 2.9° (Wide-Tele)
Sub-Stream:
50Hz: 25fps (704 × 576, 640 × 480, 352 × 288), 60Hz: 30fps (704 × 480, 640 × 480, 352 × 240)
Main Stream:
50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720); 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)
Third Stream:
50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288); 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
Network Storage:
Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB; NAS (NFS, SMB/ CIFS), ANR
Protocols:
IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, DHCP, PPPoE, UDP, IGMP, ICMP, Bonjour
API:
ONVIF (Profile S, Profile G, Profile T), ISAPI, SDK
Simultaneous Live View:
Up to 20 channels
User/Host:
Up to 32 users. 3 levels: Administrator, Operator and User
Client:
iVMS-4200, iVMS-4500, iVMS-5200, Hik-Connect
Web Browser:
IE 8 to 11, Chrome 31.0+, Firefox 30.0+, Edge 16.16299+
Security Measures:
User authentication (ID and PW), Host authentication (MAC address); HTTPS encryption; IEEE 802.1x port-based network access control; IP address filtering
Alarm Linkage:
Alarm actions, such as Notify Surveillance Center, Upload to FTP, Send Email, Trigger Recording, Recording Linkage, and Alarm Input, and Audio Visual Alarm etc.
Alarm:
1-ch alarm input and 1-ch alarm output
Audio:
1-ch audio input, 1-ch audio output
H.264:
Yes
H.265:
Yes
H.264 Type:
Baseline Profile/Main Profile/High Profile
Video Compression:
Main Stream: H.265+/H.265/H.264+/H.264, Sub-Stream: H.265/H.264/MJPEG, Third Stream: H.265/H.264/MJPEG,
H.265 Type:
Main Profile
Video Bitrate:
32 Kbps to 16384 Kbps
Audio Compression:
G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/PCM
Basic Event:
Motion Detection, Alarm Input, Alarm Output, Video Tampering Detection, Exception
Smart Event:
Intrusion Detection, Line Crossing Detection, Region Entrance Detection, Region Exiting Detection, Object Removal Detection, Unattended Baggage Detection, Audio Exception Detection
Smart Record:
ANR (Automatic Network Replenishment), Dual-VCA
ROI:
Main stream, sub-stream, and third stream respectively support four fixed areas.
3D DNR:
Yes
Image Sensor:
1/2.8" progressive scan CMOS
Min. Illumination:
Color: 0.005 Lux @(F1.6, AGC ON); B/W: 0.001 Lux @(F1.6, AGC ON)
White Balance:
Auto/Manual/ATW (Auto-tracking White Balance)/Indoor/Outdoor/Fluorescent Lamp/Sodium Lamp
Gain:
Auto/Manual
Shutter Time:
1/1 s to 1/30,000 s
Day & Night:
IR Cut Filter
Digital Zoom:
16×
Privacy Mask:
24 programmable privacy masks
Focus Mode:
Auto/Semi-automatic/Manual
WDR:
120 dB
BLC:
Yes
HLC:
Yes
Movement Range (Pan:
360° endless
Pan Speed:
Configurable, from 0.1°/s to 160°/s, Preset speed: 160°/s
Movement Range (Tilt:
From 0° to 90° (auto-flip)
Tilt Speed:
Configurable, from 0.1°/s to 120°/s, Preset Speed: 120°/s
Proportional Zoom:
Yes
Presets:
300
Patrol Scan:
8 patrols, up to 32 presets for each patrol
Pattern Scan:
4 pattern scans, record time over 10 minutes for each scan
Power-Off Memory:
Yes
Park Action:
Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan
3D Positioning:
Yes
Preset Freezing:
Yes
Scheduled Task:
Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan/Dome Reboot/Dome Adjust/Aux Output
Dimensions:
Φ 180 mm × 239.5 mm (Φ 7.09" × 9.43")
Weight:
Approx. 2 kg (4.41 lb)
Protection Level:
IP66 Standard, 4000 V Lightning Protection, Surge Protection and Voltage Transient Protection
Power:
12 VDC, 2.0 A and PoE (802.3 at), 42.5 to 57 VDC, 0.6 A, class4;Max.: 18 W
Working Environment:
-30°C to 65°C (-22°F to 149°F)
