Frame Rate:
30fps
Sensor Type:
1/2.5" Progressive Scan CMOS
Max. Resolution:
2560 × 1920
Min. Illumination:
0.01 Lux (Color, F1.2, AGC)
Shutter Time:
1/3 s to 1/100,000 s
Day & Night:
IR cut filter with auto switch
Focal Length & FOV:
1.05mm, 180° H/V FOV
Aperture:
F2.2
Lens Mount:
M12
Supplement Light Type:
IR
Supplement Light Range:
Up to 8 m
Main Stream:
25fps@2560×1920 (50Hz), 30fps@2560×1920 (60Hz)
Sub-Stream:
25–30fps (352×288 to 704×576)
Video Compression:
H.265+/H.265/H.264+/H.264, Sub: H.265/H.264/MJPEG
Video Bit Rate:
32 Kbps to 16 Mbps
H.264 Type:
Main Profile/High Profile
H.265 Type:
Main Profile
Region Of Interest (ROI:
Support 1 fixed region for main stream and sub-stream
Mount Type:
Support table, wall, and ceiling
Display Mode:
Support 14 display modes in total (including display modes of different mount types): Fisheye View, 180 Panorama View, 4PTZ, Fisheye + 3PTZ, 360 Panorama View, 360 Panorama + PTZ, 360 Panorama + 3PTZ, 360 Panorama + 6PTZ, 360 Panorama + 8PTZ, 2PTZ, F
Audio Sampling Rate:
-S: Support
Environment Noise Filtering:
-S: 8kHz/16kHz/32kHz/44.1kHZ/48kHz
Audio Compression:
G.711/G.722.1/G.726/MP2L2/PCM, 8-48kHz
Audio Bit Rate:
64 Kbps G.711, 16 Kbps G.722.1, 16 Kbps G.726, 32-192
Network Storage:
NAS (Support NFS,SMB/CIFS), built-in microSD/SDHC/SDXC card slot, up to 128 G, ANR
API:
ONVIF (PROFILE S, PROFILE G), ISAPI
Protocols:
TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, WebSocket, WebSockets
Security:
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS 1.2, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, TLS1.2
Wide Dynamic Range (WDR:
120 dB
Day/Night Switch:
Auto/Schedule/Triggered by Alarm In (-S model supports)
Image Enhancement:
WDR, 3D DNR, Backlight Comp, Defog, Distortion Correction
Image Settings:
Saturation, brightness, contrast, and sharpness are adjustable via client software or web browser
Audio Support:
-S: 1 audio input (line in), 1 audio output interface
Alarm:
-S: 1 alarm input, 1 alarm output (12 VDC, max. 30 mA)
On-Board Storage:
Built-in microSD/SDHC/SDXC slot, up to 128 G
Ethernet Interface:
1 RJ45 10M/100M self-adaptive Ethernet port
Basic Event:
Motion detection, dynamic analysis, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)
Smart Event:
Line crossing detection, intrusion detection, unattended baggage, object removal, face detection, scene change detection
Linkage:
Trigger: Memory card, network, FTP, HTTP, NAS, Email
Power Type:
PoE
Dimension:
Φ 119.9 × 41.2 mm (Φ 4.72" × 1.62")
Startup And Operating Conditions:
-10°C to +50°C, ≤95% RH non-condensing
Web Client Language:
32 languages
General Function:
Anti-flicker, three streams, heartbeat, mirror, privacy masks, password reset via e-mail, pixel counter, HTTP listening
Weight:
600 g (1.32 lbs.)
Housing Color:
White
