Frame Rate:
20fps
Sensor Type:
1/2" Progressive Scan CMOS
Min. Illumination:
0.008 Lux (F1.2, AGC ON)
Shutter Speed:
1/3 s to 1/100,000 s
Slow Shutter:
Yes
Wide Dynamic Range:
120dB
Day & Night:
IR Cut Filter
Angle Adjustment:
Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°
Focus:
Auto
Lens Type:
2.8 to 12 mm;Motorized
Field of View:
112° to 46° horizontal, 60° to 26° vertical
Aperture:
F1.4
Lens Mount:
Φ14
IR Distance:
Up to 50 m
Wavelength:
850nm
Max. Resolution:
3840 × 2160
Main Stream:
20 fps 4K, 30 fps 1080p
Sub Stream:
25-30fps, up to 640×480
Third Stream:
25-30fps, 1280×720 to 352×240
Video Compression:
H.265/H.264/MJPEG
Video Bit Rate:
32 Kbps to 16 Mbps
H.264 Type:
Main Profile/High Profile
H.265 Type:
Main Profile
H.264:
Main stream supports
H.265:
Main stream supports
Region Of Interest (ROI:
1 fixed region per stream
Environment Noise Filtering:
Yes
Audio Sampling Rate:
8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Audio Compression:
G.711/G.722.1/G.726/MP2L2/PCM
Audio Bit Rate:
64-192 Kbps
Simultaneous Live View:
Up to 6 channels
API:
ONVIF (PROFILE S, PROFILE G), ISAPI
Protocols:
TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, WebSocket, WebSockets
User/Host:
Up to 32 users,3 levels: Administrator, Operator and User
Security:
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS 1.2, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, TLS1.2
Network Storage:
Support Micro SD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR
Client:
iVMS-4200, Hik-Connect, iVMS-5200, iVMS-4500
Web Browser:
Chrome 45+, Firefox 52+, Safari 8+, IE 8+
Alarm Trigger:
Motion detection, video tampering, network disconnect
Day/Night Switch:
Day/Night/Auto/Schedule/Triggered by Alarm In (-S)
DNR:
3D DNR
Image Enhancement:
BLC/3D DNR/HLC
Image Settings:
Rotate mode, saturation, brightness, contrast, sharpness and white balance adjustable by client software or web browser
Audio Support:
1 input (line in), 1 output, mono sound, terminal block
Alarm:
1 alarm input, 1 output (12 VDC, 30 mA)
Video Outputs:
1Vp-p composite output (75 Ω) (For adjustment only)
On-Board Storage:
Built-in micro SD/SDHC/SDXC slot, up to 128 GB
Hardware Reset:
Yes
Communication Interface:
1 RJ45 10M/100M self-adaptive Ethernet port, terminal block
Basic Event:
Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)
Smart Event:
Line crossing detection, intrusion detection, unattended baggage detection, object removal detection
Face Detection:
Yes
Exception Detection:
Scene change detection
Linkage Method:
Trigger recording: memory card, network storage, pre-record and post-record Trigger captured pictures uploading: FTP, HTTP, NAS, Email Trigger notification: HTTP, ISAPI, alarm output , Email
Firmware Version:
V5.5.80
Web Client Language:
32 languages
General Function:
Anti-flicker, three streams, heartbeat, mirror, privacy masks, password reset via e-mail, pixel counter, HTTP listening
Startup And Operating Conditions:
-30 to +60°C, 95% humidity non-condensing
Power Type:
12 VDC ± 25%,PoE (802.3at, class 4)
Power Consumption And Current:
12V 1.2A / PoE+ 18W
Camera Dimension:
Camera: Φ105 × 297.5 mm (Φ4.1"× 11.7")
Camera Weight:
Camera: 1300 g (2.9 lb.),With package: 2000 g (4.4 lb.)
Protection:
IK10，IP67
Housing Color:
White
