Sensor Type:
1/2.5" Progressive Scan CMOS
Min. Illumination:
0.01 Lux (Color, F1.2, AGC ON)
Shutter Speed:
1/3 s to 1/100,000 s
Slow Shutter:
Yes
Wide Dynamic Range:
120dB
Day & Night:
IR Cut Filter
Angle Adjustment:
Pan: 0° to 355°, tilt: 0° to 90°, rotate: 0° to 355°
Focus:
Auto
Lens Type:
2.8 to 12 mm,Motorized
Field of View:
105° to 34.5° (H), 55° to 19° (V)
Aperture:
F1.6
Lens Mount:
Φ14
Aperture Type:
Fixed
IR Distance:
Up to 50 m
Wavelength:
850nm
Max. Resolution:
3840 × 2160
Main Stream:
12.5-30 fps, up to 4K
Sub Stream:
25-30fps @ 320-640p
Third Stream:
25fps@1280×720 (50Hz) / 30fps@1280×720 (60Hz)
Video Compression:
H.265/H.264, H.265/H.264/MJPEG, H.265/H.264
Video Bit Rate:
32 Kbps to 16 Mbps
H.264 Type:
Main Profile/High Profile
H.265 Type:
Main Profile
H.264:
Main stream supports
H.265:
Main stream supports
Scalable Video Coding (SVC:
H.264 and H.265 encoding support
Environment Noise Filtering:
Yes
Audio Sampling Rate:
8kHz/16kHz/32kHz/44.1kHz/48kHz
Audio Compression:
G.711/G.722.1/G.726/MP2L2/PCM
Audio Bit Rate:
64-192 Kbps
Simultaneous Live View:
Up to 6 channels
API:
ONVIF (PROFILE S, PROFILE G), ISAPI
Protocols:
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour, WebSocket, WebSockets
User/Host:
Up to 32 users,3 levels: Administrator, Operator and User
Network Storage:
Support Micro SD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR
Client:
iVMS-4200, Hik-Connect, iVMS-5200, iVMS-4500
Web Browser:
Chrome 45+, Firefox 52+, IE8+, Safari 8+
Alarm Trigger:
Motion detection, tampering, disconnection, IP conflict
Day/Night Switch:
Day/Night/Auto/Schedule/Triggered by Alarm In (-S)
Target Cropping:
No
DNR:
3D DNR
Image Enhancement:
BLC/3D DNR/HLC
Image Settings:
Saturation, brightness, contrast, sharpness, AGC, and white balance are adjustable by client software or web browser
Audio Support:
1 input (line in), 1 output (line out), mono sound, terminal block
Alarm:
1 input;1 output (max. 12 VDC, 30 mA), terminal block
Video Outputs:
1Vp-p composite output (75 Ω) (For adjustment only)
On-Board Storage:
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB
Hardware Reset:
Yes
Communication Interface:
1 RJ45 10M/100M self-adaptive Ethernet port
Face Detection:
Yes
General Function:
One-key reset, anti-flicker, three streams, heartbeat, password protection, privacy mask, watermark, IP address filter
Startup And Operating Conditions:
-30°C to +60°C, 95% humidity non-condensing
Power Type:
12 VDC, PoE+
Power Consumption And Current:
12V/1.2A or PoE+ (max 18W)
Camera Dimension:
Φ 105.1 × 297.5 mm (Φ 4.1" × 11.7")
Camera Weight:
1335 g (2.9 lb)
Protection:
IP67
Housing Color:
White
