Frame Rate:
30fps
Sensor Type:
1/2.8" Progressive Scan CMOS
Min. Illumination:
Color: 0.009 Lux @ (F1.6, AGC ON), 0 Lux with IR
Shutter Speed:
1/3 s to 1/100,000 s
Slow Shutter:
Yes
Wide Dynamic Range:
120dB
Day & Night:
IR Cut Filter
Angle Adjustment:
Pan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 355°
Lens Type:
2.8/4/6 mm
Field of View:
108°-52° horizontal FOV (2.8-6mm)
Aperture:
F1.6
Lens Mount:
Φ12
IR Distance:
Up to 30 m
Wavelength:
850nm
Max. Resolution:
1920 × 1080
Main Stream:
1920×1080 60fps, 1280×720 60fps
Sub Stream:
25-30fps, up to 640×480
Video Compression:
H.265/H.264/MJPEG
Video Bit Rate:
32 Kbps to 16 Mbps
H.264 Type:
Main Profile/High Profile
H.265 Type:
Main Profile
H.264:
No
H.265:
No
Scalable Video Coding (SVC:
H.264 and H.265 encoding support
Region Of Interest (ROI:
Support 1 fixed region for main stream and sub-stream
Environment Noise Filtering:
Yes
Audio Sampling Rate:
8kHz/16kHz/32kHz/44.1kHZ/48kHz
Audio Compression:
G.711/G.722.1/G.726/MP2L2/PCM
Audio Bit Rate:
64Kbps (G.711), 16Kbps (G.722.1), 32-192Kbps (MP2L2)
Simultaneous Live View:
Up to 6 channels
API:
ONVIF (PROFILE S, PROFILE G), ISAPI
Protocols:
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour, WebSocket, WebSockets
User/Host:
Up to 32 users ,3 levels: Administrator, Operator and User
Network Storage:
microSD/SDHC/SDXC card (128 GB), local storage and NAS (NFS,SMB/CIFS), ANR; Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
Client:
iVMS-4200, Hik-Connect, iVMS-5200, iVMS-4500
Web Browser:
Chrome 45+, Firefox 52+, Safari 8+, IE 8+
Alarm Trigger:
Motion detection, tampering, network, login
Day/Night Switch:
Day/Night/Auto/Schedule/Triggered by Alarm In
DNR:
3D DNR
Image Enhancement:
BLC/3D DNR/HLC
Image Settings:
Saturation, brightness, contrast, sharpness, AGC, and white balance are adjustable by client software or web browser
Audio Support:
1 input (line in/mic in, terminal block), 1 output ( two-core terminal block), mono sound
Alarm:
1 input, 1 output (max. 12 VDC, 30 mA), terminal block
Video Outputs:
1 HDMI™, type D, female plug (-M)
On-Board Storage:
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB
Hardware Reset:
Yes
Communication Interface:
1 RJ45 10M/100M self-adaptive Ethernet port
Smart Event:
Line crossing detection, intrusion detection
Face Detection:
Yes
General Function:
Anti-flicke, heartbeat, mirror, privacy masks, password reset via e-mail, pixel counter, HTTP listening
Startup And Operating Conditions:
-10°C to 50°C, ≤95% humidity non-condensing
Power Type:
12 VDC / PoE 802.3af
Power Consumption And Current:
12 VDC 0.6A max 7W or PoE 802.3af max 8.5W
Camera Dimension:
Camera: Φ 119 × 90 mm (Φ 4.7" × 3.5")
Camera Weight:
520g (1.1 lb)
Protection:
IK10
Housing Color:
White
