Type:
Dome
Frame Rate:
60fps
Imaging Device:
1/2.8" 2MP CMOS
Resolution:
2MP
Max. Framerate:
60fps
Min. Illumination:
0.015 Lux color
Video Out:
CVBS: 1.0 Vp-p / 75Ω composite, 720x480(N), 720x576(P), for installation; USB: Micro USB Type B, 1280x720, for installation
Focal Length (Zoom Ratio:
2.8~12mm(4.3x) motorized varifocal
Max. Aperture Ratio:
F1.4(Wide) ~ F3.6(Tele)
Angular Field of View:
H: 119.5°, V: 62.8°
Min. Object Distance:
0.5m(1.64ft)
Focus Control:
Simple remote control focus via network
Lens Type:
DC auto iris, P iris
Pan / Tilt / Rotate Range:
0°~354° / 0°~67° / 0°~355°
Camera Title:
Displayed up to 85 characters
Day & Night:
Auto(ICR)
Backlight Compensation:
BLC, HLC, WDR, DWDR, SSDR
Wide Dynamic Range:
150dB
Digital Noise Reduction:
SSNRⅤ
Digital Image Stabilization:
Support
Defog:
Support
Motion Detection:
8ea, 8point polygonal zones
Privacy Masking:
32ea, polygonal zones; - Color: Grey/Green/Red/Blue/Black/White; - Mosaic
Gain Control:
Low / Middle / High
White Balance:
ATW / AWC / Manual / Indoor / Outdoor
LDC:
Support
Electronic Shutter Speed:
Minimum / Maximum / Anti flicker (2~1/12,000sec)
Video Rotation:
Flip, Mirror, Hallway view(90°/270°)
Analytics:
Defocus detection, Directional detection, Fog detection, Face detection, Motion detection, Digital auto tracking, Appear/Disappear, Enter/Exit, Loitering, Tampering, Virtual line, Audio detection, Sound classification
Business Intelligence:
Not support
Serial Interface:
Not support
Alarm Inputs/Outputs:
Input 1ea / Output 1ea
Alarm Triggers:
Analytics, Network disconnect, Alarm input
Alarm Events:
File upload via FTP and E-Mail; Notification via E-Mail; SD/SDHC/SDXC or NAS recording at Event Triggers; Alarm output; Handover
Audio In:
Selectable(Mic in/Line in), Supply voltage: 2.5VDC(4mA), Input impedance: 2K Ohm
Audio Out:
Line out, Max. output level: 1Vrms
Ethernet:
RJ-45(10/100BASE-T)
Video Compression:
H.265/H.264: Main/Baseline/High, MJPEG
Audio Compression:
G.711 u-law /G.726 Selectable, G.726(ADPCM) 8KHz, +more
Smart Codec:
Manual(5ea area); WiseStreamⅡ
Bitrate Control:
H.264/H.265: CBR or VBR; MJPEG: VBR
Streaming:
Unicast(20 users) / Multicast; Multiple streaming(Up to 10 profiles)
Protocol:
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour, LLDP, SRTP(Unicast)
Security:
HTTPS(SSL) Login Authentication; Digest Login Authentication; IP Address Filtering; User access Log; 802.1X Authentication(EAP-TLS, EAP-LEAP)
Application Programming Interface:
ONVIF Profile S/G/T; SUNAPI(HTTP API); Wisenet open platform
Webpage Language:
English, Korean, Chinese, French, Italian, +more
Web Viewer:
Windows 7/8.1/10, macOS 10.10+, Chrome/Firefox/Safari/Edge
Edge Storage:
Micro SD/SDHC/SDXC 2slot 512GB
RAM:
1024MB RAM, 256MB Flash
Operating Temperature / Humidity:
-40°C ~ +55°C(-40°F ~ +131°F) / Less than 90% RH
Storage Temperature / Humidity:
-50°C ~ +60°C(-58°F ~ +140°F) / Less than 90% RH
Certification:
IP67/IP66/NEMA4X, IK10
Input Voltage:
PoE(IEEE802.3af, Class3), 12VDC, 24VAC
Power (Max:
7.8W
Color / Material:
Ivory / Aluminum
Product Type:
Dome
Connectivity:
Wired
IP Rating:
IK10
Features:
WDR (150dB)
Night Vision:
IR
Power Type:
PoE
PoE Class:
3
Form Factor:
Dome
Vandal Rating:
IK10
Compatibility:
ONVIF
IR Distance:
0.5m
Built-in IR:
Yes
Day/Night:
Yes
Storage Support:
microSD
Outdoor Ready:
Yes
HTTPS Encryption:
Yes
WDR:
WDR (150dB)
Housing Color:
White
Environment Rating:
Outdoor
Warranty:
3-year warranty
Poe Power:
PoE (802.3af)
Wdr:
WDR
Ir Lowlight:
IR
Compression:
H.265; H.264; MJPEG
Onvif:
Yes
Audio:
Audio input
Lens Focal Length:
Varifocal
Mount Type:
Rack
Lens:
/ Mount Type DC auto iris, P-Iris / Board-in type
Ethernet Rate:
RJ-45 (10/100BASE-T)
Application:
Programming Interface ONVIF profile S/G, SUNAPI (HTTP API), Wisenet Open Platform
Operating Temp:
/ Humidity -40°C ~ +55°C (-40°F ~ +131°F) / Less than 90% RH
Storage:
Temperature / Humidity -50°C ~ +60°C (-58°F ~ +140°F) / Less than 90% RH
Dimensions:
(WxH) Ø160.0 x 118.5mm (Ø6.3" x 4.67")
Weight:
995g (2.19 lb)
Compatible Accessories:
(Optional)
