Type:
Dome
Imaging Device:
1/2.8" 2MP CMOS
Resolution:
1920×1080
Max. Framerate:
60fps
Min. Illumination:
0.015 Lux color / 0 Lux IR
Video Out:
CVBS: 1.0 Vp-p / 75Ω composite, 720x480(N), 720x576(P) for installation; USB: Micro USB Type B, 1280x720 for installation
Focal Length (Zoom Ratio:
2.8~12mm(4.3x) motorized varifocal
Max. Aperture Ratio:
F1.4(Wide)~F3.6(Tele)
Min. Object Distance:
0.5m(1.64ft)
Focus Control:
Simple focus
Lens Type:
DC auto iris, P iris
Pan / Tilt / Rotate Range:
0°~360° / -45°~85° / 0°~355°
Camera Title:
Displayed up to 85 characters
Day & Night:
Auto(ICR)
Backlight Compensation:
BLC, HLC, WDR, SSDR
Wide Dynamic Range:
150dB
Digital Noise Reduction:
SSNRⅤ
Digital Image Stabilization:
Support(built-in gyro sensor)
Defog:
Support
Motion Detection:
8ea, 8point polygonal zones
Privacy Masking:
32ea, polygonal zones; - Color: Grey/Green/Red/Blue/Black/White; - Mosaic
Gain Control:
Low / Middle / High
White Balance:
ATW / AWC / Manual / Indoor / Outdoor
LDC:
Support
Electronic Shutter Speed:
Minimum / Maximum / Anti flicker (2~1/12,000sec)
Video Rotation:
Flip, Mirror, Hallway view(90°/270°)
Analytics:
Defocus detection, Directional detection, Fog detection, Face detection, Motion detection, Digital auto tracking, Appear/Disappear, Enter/Exit, Loitering, Tampering, Virtual line, Audio detection, Sound classification, Shock detection
Business Intelligence:
People counting, Queue management, Heatmap
Alarm Inputs/Outputs:
Input 1ea / Output 1ea
Alarm Triggers:
Analytics, Network disconnect, Alarm input
Alarm Events:
File upload via FTP and e-mail; Notification via e-mail; SD/SDHC/SDXC or NAS recording at event triggers; Alarm output; Handover; Audio playback
Audio In:
Selectable(mic in/line in); Supply voltage: 2.5VDC(4mA), Input impedance: 2K Ohm
Audio Out:
Line out, Max. output level: 1Vrms
IR Viewable Length:
50m(164.04ft)
Ethernet:
RJ-45(10/100BASE-T)
Video Compression:
H.265/H.264: Main/Baseline/High, MJPEG
Audio Compression:
G.711 u-law /G.726 Selectable, G.726(ADPCM) 8KHz, +more
Smart Codec:
Manual(5ea area), WiseStreamⅡ
Bitrate Control:
H.264/H.265: CBR or VBR; MJPEG: VBR
Streaming:
Unicast(20 users) / Multicast; Multiple streaming(Up to 10 profiles)
Protocol:
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour, LLDP, SRTP
Security:
HTTPS(SSL) Login Authentication; Digest Login Authentication; IP Address Filtering; User access Log; 802.1X Authentication(EAP-TLS, EAP-LEAP)
Application Programming Interface:
ONVIF Profile S/G/T; SUNAPI(HTTP API); Wisenet open platform
Web Viewer:
Supported OS: Windows 7, 8.1, 10, Mac OS X 10.10, 10.11, 10.12; Recommended Browser: Google Chrome; Supported Browser: MS Explore11, MS Edge, Mozilla Firefox(Window 64bit only), Apple Safari(Mac OS X only)
Edge Storage:
Micro SD/SDHC/SDXC 2slot 512GB
RAM:
1024MB RAM, 256MB Flash
Operating Temperature / Humidity:
-25°C~+60°C (-13°F~+140°F) / Less than 90% RH
Storage Temperature / Humidity:
-50°C~+60°C (-58°F~+140°F) / Less than 90% RH
Certification:
IP52, IK10
Input Voltage:
PoE(IEEE802.3af, Class3), 12VDC
Power (Max:
12.95W
Color / Material:
White / Aluminum(Plenum)
RAL Code:
RAL9003
Product Dimensions / Weight:
Ø205x155mm(8.07x6.10"), 1.80kg(3.97 lb)
Product Type:
Dome
Connectivity:
Wired
Features:
WDR
Night Vision:
IR
Power Type:
PoE
PoE Class:
3
Form Factor:
Dome
IP Rating:
IP52
Vandal Rating:
IK10
Compatibility:
ONVIF
IR Distance:
0.5m
Built-in IR:
Yes
Day/Night:
Yes
Storage Support:
microSD
HTTPS Encryption:
Yes
WDR:
WDR
Housing Color:
White
Environment Rating:
Indoor
Warranty:
3-year warranty
