Hanwha XNB-H6241A 2MP Mini Dome ATM IP Camera

Hanwha XNB-H6241A 2MP Mini Dome ATM IP Camera Kit

The Hanwha XNB-H6241A is a purpose-built 2MP fixed mini dome camera designed for high-security ATM and financial institution environments. This compact wired IP camera delivers 1080p video at 60fps with advanced Wide Dynamic Range (WDR) technology, ensuring clear footage in challenging lighting conditions typical of ATM installations. The kit combines reliability, analytical intelligence, and ease of integration into existing security infrastructure.

Key Features

• 2MP 1/2.8" CMOS sensor with 1080p 60fps video capture
• 120dB Wide Dynamic Range (WDR) for optimal performance in high-contrast environments
• Day/Night IR capability with automatic electrical switching
• Compact mini dome form factor (131.1 x 28 x 86mm) for discreet installation
• PoE powered (IEEE 802.3af) with minimal 6W consumption
• Wide 138° horizontal field of view with 2.4mm fixed lens
• Advanced video analytics: tampering detection, loitering, defocus, fog/dust detection, face detection, people counting, heatmap, and queue management
• Motion detection with 8 polygonal zones and alarm triggers
• 32-zone privacy masking with color and mosaic options
• Multiple video compression formats: H.265, H.264 (Main/Baseline/High), and MJPEG
• WiseStreamII bandwidth optimization support
• Up to 10 simultaneous streaming profiles for multi-user access
• Bi-directional audio with G.711 and G.726 codec support
• Edge storage via SD/SDHC/SDXC cards (up to 256GB) and NAS integration
• ONVIF Profile S/G compliant with SUNAPI HTTP API support
• Advanced security: HTTPS/SSL encryption, 802.1X authentication, IP filtering

Technical Highlights

Built on Hanwha's proven platform, the XNB-H6241A combines optical and digital technologies for superior image quality. The F2.0 aperture and 0.45Lux minimum illumination enable operation in low-light conditions, while electronic shutter speeds up to 1/12,000 second accommodate bright environments. Lens distortion correction (5 levels) and digital image stabilization ensure clean footage even in vibration-prone ATM settings. The camera supports 24x digital PTZ with preset and group functionality, allowing flexible monitoring without mechanical components.

The integrated Smart Codec engine includes manual area-based optimization (5 zones), allowing administrators to prioritize bitrate to critical regions like card reader slots or PIN pads. Contrast enhancement (SSDR), 2D+3D noise reduction (SSNRV), and selectable white balance (ATW/AWC/Manual/Indoor/Outdoor) maintain image fidelity across shifts in ambient lighting.

Applications

• ATM surveillance and transaction monitoring
• Bank branch entrance and interior security
• Financial institution cash handling areas
• High-security retail POS environments
• Secure facility access points

Marty Allison

Perspective based on aggregated IP Security Depot and affiliated engineering team experience.

The XNB-H6241A is purpose-engineered for financial sector deployments where image quality consistency and forensic clarity are non-negotiable. Its 120dB WDR is particularly effective in ATM surrounds with mixed backlighting (storefront windows, interior spotlights). The combination of 60fps at 1080p with H.265 support allows frame-accurate transaction documentation without overwhelming network bandwidth—critical for institutions with multiple camera deployments.

Analytics like tampering detection and loitering generate immediate alerts, supporting compliance requirements and loss prevention. The compact form factor and PoE simplicity reduce installation complexity, while ONVIF compliance ensures vendor flexibility in VMS selection. Support for 20 concurrent unicast users and edge storage to SD card provides resilience if network connectivity fails, a priority in mission-critical financial environments.
