Middle Atlantic 8 Space 16IN. Deep RK Series Rack Black Wood Grain Melamine Finish - RK8

Middle Atlantic RK8 8U Knockdown Open-Frame Wood Rack

Overview

The Middle Atlantic RK8 is an 8-space (8U), 15.91-inch-deep open-frame rack finished in black wood grain melamine — purpose-built for A/V equipment rooms, security head-end closets, and light IT deployments where a fully welded steel enclosure would be overkill. With 14 inches of usable rack height and 15.41 inches of usable depth, the RK8 accommodates standard 1U–4U gear including NVRs, patch panels, and power distribution units without crowding. Its knockdown construction ships flat, reducing freight damage risk and making solo installation practical — no lift equipment required. At 200 lb rated capacity, it handles dense head-end builds with room to spare. Standard 10-32 threaded rail hardware ensures compatibility with the widest range of rackmount equipment. Internal links to rack accessories and the broader Middle Atlantic product line are worth reviewing when speccing a full head-end build.

Compatibility

The RK8 accepts any 19-inch EIA-310 standard rackmount equipment using 10-32 fasteners — the same threading used across Middle Atlantic's RK and ERK series accessories, including their rack shelves, blanks, and power strips. Compatible gear includes standard 1U–4U NVRs, network switches, UPS units, and patch panels. The 15.41-inch usable depth accommodates most 1U managed network switches and shallow NVRs; verify front-to-back clearance for deeper chassis (1U servers often run 17–20 inches). The black wood grain melamine finish integrates cleanly in network video recorder installations housed in finished media rooms or security offices where bare steel racks are aesthetically out of place. For builds requiring more than 8U, Middle Atlantic's RK12 and RK16 variants in the same RK series maintain identical rail spacing and accessory compatibility.

Installation Notes

Knockdown assembly requires standard hand tools — no power tools needed. Rack dimensions: 20.4 inches wide × 15.48 inches high × 15.91 inches deep overall; plan floor or desk space accordingly. The 20.4-inch external width is wider than the standard 19-inch rack opening, consistent with side-panel clearance. Shipping weight is 25 lbs; factor this into freight planning for multi-unit orders. For rack power management accessories, Middle Atlantic's rack-mount PDUs mount directly to the 10-32 rails without adapters.
