ACTi TT-7523C 75-Inch 4K LED Multi-touch Display
Overview
The ACTi TT-7523C is a 75-inch 4K LED multi-touch display designed for surveillance command and control environments. This is a wall-mount or console-integrated display panel meant to aggregate live camera feeds, recorded playback, and alarm data across networked VMS systems. The 4K native resolution (3840×2160) delivers crisp detail when scaling multiple simultaneous video streams on a single screen — critical when monitoring dozens of cameras from a central station. The multi-touch surface enables direct gesture interaction (pinch-zoom, swipe, tap) with your VMS interface without requiring a separate keyboard or mouse, streamlining operator workflows in high-frequency alert environments.
Compatibility
The TT-7523C integrates with surveillance management platforms that support HDMI or DisplayPort input and standard multi-touch USB HID protocols. Verify your VMS software (Milestone XProtect, Genetec Security Center, Axis Camera Station, or third-party ONVIF-compliant systems) explicitly supports 75-inch multi-touch output before commissioning. Some legacy systems may require an intermediate converter or KVM switch. Confirm resolution scaling and touch driver availability with your VMS vendor for your specific OS version.
Installation Notes
Mount height, viewing distance, and cable routing must account for the 75-inch footprint and weight. A dedicated power circuit (110–240V AC) and HDMI/DisplayPort shielded cabling run from your control room workstation or server should be planned during site survey. Anti-glare protective tempered glass is optional but recommended in high-ambient-light environments to reduce reflections and minimize touch accuracy drift. Calibrate the multi-touch surface after initial power-up and after any physical relocation.
