ACTi 75IN 4K UHD Interactive Panel - TVULTRA75-G5

ACTi TVULTRA75-G5 75IN 4K UHD Interactive Panel

Overview

The TVULTRA75-G5 is a 75-inch 4K UHD interactive display built for surveillance operations centers and command-and-control rooms where dense multi-camera feeds demand high resolution and touch-responsive interaction. Unlike passive monitors, the interactive panel lets operators pinch-zoom into live streams, annotate video during incident response, and manage multiple camera grids without keyboard/mouse overhead. The 4K resolution (3840×2160) delivers pixel density sufficient to display 16 HD camera tiles simultaneously while maintaining readable detail on each tile — a real operational advantage when you're watching dozens of feeds but need to pivot to forensic zoom without breaking the control flow.

Compatibility

The TVULTRA75-G5 integrates with standard enterprise surveillance VMS platforms via HDMI, DisplayPort, or network-connected control protocols. It works with any IP camera system capable of streaming to a web-based or desktop client (Milestone, Genetec, Axis Camera Station, Hanwha wisenet, and open ONVIF-compliant systems). Pair it with a dedicated control PC, DVI/HDMI splitter, or network encoder to aggregate multiple camera feeds. Touch input supports standard USB HID protocols, compatible with Windows, Linux, and surveillance appliance OS environments. Confirm HDMI 2.0 or DisplayPort 1.4 availability on your control system to saturate the 4K bandwidth — older single-channel HDMI may limit refresh rates.

Installation Notes

Mount the TVULTRA75-G5 on a commercial-grade articulating arm or fixed wall bracket rated for 150+ lbs. Verify your wall structure (wood studs, concrete, or steel) can support the panel weight plus bracket hardware. Position the display at 30–40 degrees downward tilt from operator eye level to reduce glare and neck strain during extended 8–12 hour shifts. Provide adequate ventilation on the rear panel (minimum 6 inches clearance) for active cooling; heat buildup degrades touch-sensor responsiveness. Connect power via a dedicated 120V/15A circuit — do not daisy-chain through desktop power strips. USB touch cable requires a shielded run if placed near high-current equipment (power supplies, UPS units) to prevent capacitive noise.

What's in the Box

• 1x TVULTRA75-G5 75-inch panel assembly
• 1x power cable (120V, US standard)
• 1x USB touch interface cable
• 1x HDMI cable (6 feet)
• Wall mount bracket (hardware for stud/concrete mounting)
• Quick-start guide
