ATEN 2L7DX2U KVM Cable
Overview
The ATEN 2L7DX2U is a 1.8-meter (6 ft) KVM cable designed to connect USB, VGA, and 3.5mm audio devices from a computer to a compatible DVI-I KVM switch. This cable facilitates the consolidation of multiple peripheral connections, streamlining setups in environments where console management is critical. The 2L7DX2U model supports audio pass-through, ensuring full multimedia functionality. It's suited for IT environments requiring a single cable to manage video, USB peripherals, and audio from a workstation to a KVM switch.
Compatibility
This cable is engineered for use with KVM switches that feature DVI-I (digital/analog) video input, USB Type-B peripheral input, and 3.5mm audio input ports. The computer-side connectors include VGA (D-Sub) for video, USB Type-A for keyboard and mouse, and a 3.5mm audio jack. It is designed to interface with ATEN's DVI KVM switch series and other compatible DVI-I KVM solutions that require this specific connector configuration.
Installation Notes
Ensure the VGA, USB Type-A, and 3.5mm audio ports on the computer are functional and the DVI-I, USB Type-B, and 3.5mm audio ports on the KVM switch are free of obstructions. The cable's male-to-male connectors require direct insertion into the respective ports. The cable's black, green, and pink color coding on the DVI-I end aids in correct audio and video signal assignment.
