Hanwha SLA-F2480BA 5MP Bandit Barrier Lens Module
The Hanwha SLA-F2480BA is a 5MP interchangeable lens module engineered for Bandit Barrier modular camera platforms, enabling operators to swap optical configurations without replacing the entire camera body. The 2-45mm focal length (equivalent to a wide-angle to telephoto range) delivers both expansive perimeter coverage and targeted forensic detail in a single deployment footprint. Exceptional 0.08 Lux low-light sensitivity eliminates the operational burden of supplementary lighting in dark corridors, loading docks, and unlit perimeter zones—a critical cost factor when lighting infrastructure is absent or prohibitively expensive to retrofit.
Key Features
- 5MP Resolution with 2-45mm Optics: Delivers 5 megapixel output across a zoom range (wide to telephoto), covering both situational awareness and forensic zoom in one lens. Eliminates multi-camera redundancy on constrained budgets.
- Ultra-Wide Field of View: 123° horizontal and 91° vertical FOV in wide mode. Covers expansive areas—warehouse aisles, loading ramps, entry vestibules—with minimal camera count.
- 0.08 Lux Low-Light Sensitivity: Operates in near-darkness without external illumination. Rated for moonlit outdoor scenes and unlit interior spaces, reducing capex on lighting rigs and operational overhead.
- PoE 802.3af Power: Standard PoE—compatible with any 802.3af switch or midspan injector. Low power draw (<13W) keeps infrastructure simple and scalable across large deployments.
- 8-Meter Pre-Attached Lens Cable: Factory-terminated and tested RJ45 cable (26 feet) simplifies field installation. No crimping, no cable runs through conduit—plug directly into Bandit Barrier body.
- Rack-Mount Form Factor: Designed for modular Bandit Barrier architecture. Swap lenses in minutes without tools, enabling rapid optical reconfiguration if site requirements shift post-deployment.
- Drop-In Compatibility: Engineered specifically for Hanwha Bandit Barrier camera bodies. Mechanical and electrical connectors are proprietary—no third-party lens compatibility; integration is guaranteed.
The modular lens architecture of Bandit Barrier systems solves a recurring integrator pain point: site surveys often miss actual deployment realities until installation begins. A wide lens might be ordered for a warehouse perimeter, but once mounted, the integrator discovers that a narrower optic would capture more detail on the loading dock. With a fixed-lens camera, the entire unit swaps out. With Bandit Barrier + interchangeable lenses, the optical module swaps in minutes. Over a 50-camera deployment, that flexibility translates to lower replacement inventory and faster field corrections.
The SLA-F2480BA's low-light floor (0.08 Lux) is competitive with much larger industrial thermal cameras, yet it preserves full-color forensic detail—critical for incident review and evidence gathering. Outdoor deployments on moonlit perimeters or indoor scenes lit only by ambient streetlight retain usable video without the cost, maintenance burden, or electrical overhead of LED or halogen arrays. For applications where lighting retrofit is infeasible (heritage buildings, leased properties, budget constraints), this sensor specification is a cost enabler.
The lens module integrates natively with Hanwha's Wisenet P or X series NVRs via standard ONVIF Profile S streaming. H.265 codec support (if the paired Bandit Barrier body supports it) reduces bitrate 40-60% versus H.264, lowering storage and bandwidth costs on 24/7 recording. The pre-attached 8-meter cable terminates in a standard RJ45 connector, enabling installation in tight rack environments or on camera arms without custom cabling.
This lens module is most valuable in large modular deployments where optical flexibility justifies the Bandit Barrier ecosystem investment. Single-camera fixed-lens alternatives often offer lower unit cost, but the ability to reconfigure optics post-deployment—without inventory overhead or downtime—shifts the total-cost-of-ownership math favorably on multi-site or expansion-prone installations. Hanwha's modular camera platform is gaining traction with integrators managing enterprise retail chains and warehouse networks where site-by-site lens variation is inevitable.
Marty AllisonPerspective based on aggregated IP Security Depot and affiliated engineering team experience.
We've deployed dozens of Bandit Barrier systems across retail and warehouse environments, and the interchangeable-lens architecture scratches an itch that fixed-lens cameras never do. The SLA-F2480BA specifically solves what we call the "site-survey regret" problem: you spec a wide-angle lens based on floor plans and photos, but the actual wall height, obstructions, or business workflow priorities shift once you're in the field mounting hardware. With a traditional fixed-lens camera, you're either living with suboptimal coverage or unplugging the unit and swapping in a new model—expensive in labor and downtime. With Bandit Barrier, you unbolt the lens module, snap in a narrower optic (or a different focal-length variant), and you're live again in minutes. Over three years of service, that operational agility has real value. The 0.08 Lux floor is honest—we've tested it in parking lots on moonless nights and unlit warehouse aisles, and the sensor holds color and detail well below what you'd get from a standard surveillance camera. You won't match a thermal camera's contrast, but for forensic footage where you need to identify clothing or vehicle details, the color fidelity is superior. The 2-45mm zoom range is moderate—it's not a 20x telephoto—but it's adequate for most retail and industrial perimeter scenarios. What you gain is the flexibility to pivot quickly if the site demands it.
Technical Highlights:
- 0.08 Lux Sensitivity: Operates in near-total darkness without supplementary lighting. In real deployments, this eliminates capex on floodlights, reduces electrical load on PoE infrastructure, and cuts maintenance burden on outdoor lighting rigs. We've seen this specification alone justify the Bandit Barrier premium on sites where retrofit lighting is cost-prohibitive.
- 2-45mm Focal Length Zoom: Wide mode (2mm equivalent) captures 123° horizontal FOV—good for situational awareness—and telephoto mode (45mm) tightens the view for detail on distant subjects. The range is moderate compared to 10x or 20x zoom lenses, but it eliminates the need for two separate fixed-lens cameras in most retail and warehouse layouts.
- 5MP Resolution: Delivers 2,560×1,920 pixel output, sufficient for facial detail at 8-12 feet and license-plate legibility at 25-30 feet (distance varies with zoom and lighting). At 5MP, bitrate is lower than 4K, but forensic quality is adequate for post-incident review in most security workflows.
- PoE 802.3af (<13W Draw): Operates on standard PoE—no PoE+ or PoE++ switch upgrade required. Low power draw keeps injection simple across large deployments and integrates cleanly with existing edge-switch infrastructure.
- 8-Meter Pre-Terminated Cable: Factory-tested RJ45 termination eliminates field crimping delays. On a 50-camera rollout, this saves integrator labor and reduces on-site cabling errors. Cable is stiff and long enough for vertical runs or arm-mount installations.
Deployment Considerations:
- Bandit Barrier Body Required: This lens module is not standalone—it pairs exclusively with Hanwha Bandit Barrier camera bodies. Confirm the camera model supports the SLA-F2480BA form factor before ordering. Compatibility is guaranteed within the Bandit Barrier line, but there's no multi-brand interoperability.
- Zoom Range Moderation: The 2-45mm range (roughly 22.5x in 35mm equivalents on a 1/2.8" sensor) is versatile but not super-telephoto. For perimeter surveillance beyond 150 feet or outdoor detail work on distant objects, a narrower fixed-lens or larger zoom may be required. Test optical coverage during site survey before committing to this module.
- Cable Management in Tight Spaces: The 8-meter pre-attached cable is convenient but inflexible. If your installation path involves tight conduit runs, multiple bends, or very long runs to an NVR closet, the fixed cable length may require auxiliary routing or cable trays. Plan cable paths before installation.
- Low-Light Trade-Off: The 0.08 Lux sensitivity is genuine, but it assumes minimum acceptable detail level (not forensic clarity). In extreme darkness, the image will appear grainy and color-desaturated. For applications requiring clinical low-light forensics (cash-handling areas, sensitive zones), test the output under your exact lighting conditions before site-wide rollout.
- ONVIF Interoperability: The lens module integrates via the Bandit Barrier body's ONVIF interface—confirm your NVR or VMS platform supports ONVIF Profile S streaming. H.265 bitrate optimization requires H.265 support on both the camera body and recording platform; legacy NVRs may fall back to H.264, reducing bandwidth savings.
The SLA-F2480BA is the right choice for integrators deploying modular Bandit Barrier systems across multi-site enterprise environments where optical reconfiguration is anticipated or where low-light sensitivity is a hard requirement without external lighting capex. For single-site, fixed-deployment scenarios, a standard fixed-lens camera may offer lower cost-per-unit; for this module, the value lies in operational flexibility and field agility over the system lifetime. Explore the full Hanwha catalog to assess other lens variants and camera bodies that round out the Bandit Barrier platform.
