2N 01350-001 IP Force/Safety Additional Switch + Tamper Module
Overview
The 2N 01350-001 is a dedicated expansion module that adds dual switching and tamper monitoring to 2N IP Force and Safety intercom systems. If your deployment requires secondary device control—door strikes, gate operators, alert relays—this accessory eliminates the need for external relay modules and centralizes both switching and security sensing into one compact unit. The integrated tamper switch detects front panel opening attempts, which matters when your intercom sits in public spaces where physical tampering is a real risk.
Key Features
- Dual Switching Modes: Passive switching up to 48V / 2A handles low-power devices like door strike magnets and gate motor relays without requiring additional power. Active switching at 12V / 700mA works for powered devices that draw modest current, eliminating the need for separate relay drivers in many installations.
- Tamper Switch Integration: Detects unauthorized opening of the front panel and sends an alert to the intercom system. In lobbies, building entrances, and public outdoor installations, this prevents silent vandalism or tampering that might otherwise go unnoticed until someone tries to use the system.
- Compact Modular Design: Purpose-built for the 2N IP Force and Safety line, so installation is straightforward—no custom wiring looms or complex integration needed. The module mounts directly alongside the parent intercom unit.
- Flexible Device Support: The 48V/2A passive rating is sufficient for standard electric door strikes (typically 12–24V, <1A), while the 12V active output serves auxiliary alerting devices, solenoid valves, and light loads. This dual-mode design eliminates the need to source and install separate relays for mixed voltage environments.
Integration & Compatibility
The 01350-001 pairs directly with 2N IP Force and Safety intercom platforms via the intercom's integrated switch connector. Verify compatibility with your specific 2N model before purchase—2N IP intercoms are modular by design, but not all firmware revisions support the same accessory range. Coordinate with your IP intercom system integrator during the design phase to confirm switch capacity and GPIO routing in your target device.
When to Choose This Module
Deploy the 01350-001 when you need to integrate access control or auxiliary alerting into an intercom-centric installation. Common scenarios: building entrance intercoms that unlock doors, office lobby systems that trigger occupancy notifications, warehouse checkpoints that activate warning lights. If you're adding more than one secondary device, confirm that the 2A passive or 700mA active capacity meets your total load—multiple door strikes in parallel, for example, may exceed passive limits and require a secondary relay.
For large-scale access control deployments with dozens of doors, a dedicated access control panel paired with the intercom is often cleaner than stacking multiple switch modules. The 01350-001 shines in smaller, focused integrations where one or two auxiliary actions suffice.
Deployment Considerations
Ensure adequate power budget on the parent 2N IP Force or Safety device—the 01350-001 itself draws negligible power, but passive switching at 2A assumes the parent unit can source that current without voltage sag. Consult the parent device datasheet for total available switch current. Tamper alerts must be configured in the intercom's event log or sent to a monitoring station; they are not automatic lockdowns, so plan your alerting workflow upfront.
Frequently Asked Questions
Q: Can I use the 01350-001 with any 2N intercom?
A: The 01350-001 is designed for 2N IP Force and Safety systems. Compatibility varies by model and firmware. Always verify with your intercom documentation or contact your 2N integrator before ordering.
Q: What's the difference between passive and active switching on this module?
A: Passive switching (48V/2A) passes voltage supplied by an external device through the relay contacts. Active switching (12V/700mA) sources power from the module itself, useful for low-power devices like solenoids or indicator lights. Passive mode is typically more flexible for mixed-voltage environments; active mode is simpler for 12V-only deployments.
Q: Will the tamper alert trigger an automatic alarm?
A: The 01350-001 sends a tamper event to the parent intercom, which logs it and can forward the alert via email or SNMP to a monitoring platform. It does not trigger a local siren or automatic lockdown—your VMS or security system must be configured to act on that event.
Q: Is the 01350-001 rated for outdoor mounting?
A: The module inherits the environmental rating of its parent 2N IP Force or Safety intercom. Consult your parent device's IP/IK rating; typical IP Force units are rated IP66 for weather resistance, but always verify your specific model's datasheet.
Q: What's the maximum number of additional switches I can add to one intercom?
A: This depends on the parent 2N device's GPIO and relay output capacity. Most IP Force and Safety systems support one or two switch modules. Review your intercom's technical documentation or contact your system architect to confirm.
Ted PerryPerspective based on aggregated IP Security Depot and affiliated engineering team experience.
The 2N 01350-001 is a straightforward way to add switching and tamper sensing to IP Force and Safety intercoms without spinning up a separate access control layer. If you're building a single-door or two-door lobby installation and need the intercom itself to unlock the door and report tampering, this module does both jobs cleanly. The dual switching modes—48V/2A passive and 12V/700mA active—cover most common auxiliary loads, and the integrated tamper sensor catches physical attacks that would otherwise be invisible until someone notices the intercom is broken.
Technical Highlights:
- Passive Switching (48V / 2A): Sufficient for standard electromagnetic door strikes (typically <1A at 12–24V) and relay-based gate operators. No separate power supply required—the module simply closes the loop and lets your external voltage source do the work. This is the most common mode for access control.
- Active Switching (12V / 700mA): Useful for indicator lights, 12V solenoid valves, and other low-current signaling devices. The module sources its own 12V, so installation is simpler than sourcing external power for each auxiliary device.
- Tamper Detection: Monitors front panel integrity and generates an alert event that feeds into the parent intercom's logging and alert routing. This prevents silent vandalism—a tamperer can't simply rip the faceplate off without the system knowing. Alerts can be forwarded to email, SNMP traps, or a security platform.
Deployment Considerations:
- Confirm that your parent 2N IP Force or Safety device supports the 01350-001 and that its firmware revision permits it. Older models or firmware revisions may not recognize this accessory.
- Verify your intercom's total available relay current before ordering. If you're controlling a door strike and a gate operator in parallel, 2A passive capacity is tight—each device's inrush current matters. A single 1A door strike is fine; two simultaneous door strikes may exceed limits.
- Tamper alerts require event configuration in the parent device's settings. Out of the box, tampering is detected and logged, but no action occurs unless you explicitly route the alert to a monitoring platform or SMS gateway. Plan that workflow during system design, not deployment.
The 01350-001 is the right choice for small-footprint access control where the intercom is your front-end interface and a couple of auxiliary actions suffice. In larger multi-door facilities or where you need dozens of independently controlled devices, a standalone access control panel paired with the intercom (via SIP or HTTP callbacks) is cleaner and more maintainable. For a single-door entrance or a warehouse checkpoint that unlocks one gate and logs tampering, this module saves you the cost and complexity of external relays.
