Vertiv 29072VH Metered Surge Rack PDU, 20A, 10-Outlet, 0U Horizontal

Overview

The Vertiv 29072VH is a single-phase, metered surge rack PDU engineered for equipment rooms, IT closets, and distributed infrastructure deployments where you need consolidated power delivery with basic consumption visibility — without the cost of full remote management. Running at 120V/20A on a NEMA L5-20P input plug, the 29072VH feeds up to 10 NEMA 5-20R outlets, making it a practical fit for network switch stacks, NVR bays, or security appliance shelves where you want per-unit power monitoring and surge protection in a single horizontal form factor.

This unit mounts in 0U horizontal rack space — meaning it installs along the rack's vertical rail channel rather than consuming any of the rack's standard 1U slots. That's worth noting early: if you're budgeting rack space for equipment, the 29072VH doesn't eat into it. The 3.05m (10-foot) input cord provides enough reach to a dedicated 20A circuit without a cord extension in most two-post or four-post installations.

Key Features

• Metered Power Monitoring with LED Display: The onboard LED display shows real-time power consumption for the PDU circuit — useful for load balancing across multiple PDUs and catching overloads before they trip a breaker. You don't get per-outlet metering at this tier, but circuit-level visibility is significantly better than a blind strip.
• Surge Protection Built In: Surge suppression is integrated at the unit level, protecting connected equipment from voltage spikes on the upstream circuit. In environments using shared electrical infrastructure — common in network video recorders and surveillance head-end rooms — this matters more than it looks on a spec sheet.
• 10x NEMA 5-20R Outlets: Ten standard 20A outlets handle the full range of rackmount equipment that ships with typical NEMA 5-15P or 5-20P cords. The 5-20R receptacle accepts both plug types, so you're not forced to rewire or adapt anything in a mixed-equipment rack.
• NEMA L5-20P Locking Input Plug: The twist-lock L5-20P input plug seats securely into a matching 20A locking receptacle — it won't pull free from vibration or an accidental cord tug. If your facility panels use standard NEMA 5-20R circuits, you'll need a short L5-20P-to-5-20R adapter or a matching outlet on the UPS output.
• On/Off Master Switch: A master on/off switch lets you cut power to all outlets simultaneously without reaching behind equipment or killing the upstream breaker. Useful during maintenance windows, equipment swaps, or emergency shutdowns.
• 0U Horizontal Mounting: The horizontal 0U form factor installs in the vertical channel space of a standard rack enclosure. Combined with the 3.05m cord, this gives you flexibility in routing power without occupying usable rack units — a real advantage in dense PoE switch and appliance deployments where every rack unit counts.
• 100–120V / 50–60Hz Input Compatibility: Accepts both 50Hz and 60Hz input, so the unit works across North American grid standards without modification. The 100–120V range accommodates minor line voltage variation without performance impact.
• Power LED Indicator: A dedicated power LED provides instant visual confirmation that the PDU is energized — a small but meaningful detail during rack walkthroughs and post-installation verification in rack enclosure environments.

Integration and Compatibility

The 29072VH is designed for standard North American 20A single-phase circuits. The NEMA L5-20P plug is the critical compatibility check: your upstream UPS, PDU, or panel must have a matching L5-20P (twist-lock) receptacle or you'll need an appropriate adapter. The unit does not support remote network monitoring or outlet-level switching — this is a locally metered device only. If your deployment requires SNMP-managed outlet control or remote load monitoring, review Vertiv's managed power distribution units in the same product family before specifying this unit.

The 29072VH's 10 NEMA 5-20R outlets make it compatible with virtually any rackmount equipment shipping standard North American power cords. The 20A circuit rating supports mixed loads including switches, NVRs, servers, and storage appliances, though you should verify total load stays below 16A sustained (80% of 20A breaker rating) per NEC guidelines.

Frequently Asked Questions

Q: What input plug type does the Vertiv 29072VH use, and do I need an adapter for a standard wall outlet?

A: The 29072VH uses a NEMA L5-20P twist-lock plug. Standard wall outlets in North America are typically NEMA 5-15R or 5-20R straight-blade receptacles, which will not accept the L5-20P directly. You'll need a matching L5-20P receptacle — typically found on a UPS or dedicated 20A circuit panel — or a rated L5-20P-to-5-20P adapter.

Q: Does the 29072VH provide per-outlet metering or just circuit-level metering?

A: The 29072VH provides circuit-level metering via its LED display, showing total load for the entire PDU. It does not offer individual per-outlet power monitoring. If per-outlet metering is required, you'll need to step up to a higher-tier managed PDU in the Vertiv lineup.

Q: Can the 29072VH be remotely monitored over the network?

A: No. The 29072VH is a locally metered unit with no network port or SNMP management capability. Monitoring is limited to the onboard LED display at the rack. For remote power visibility, consider Vertiv's network-managed PDU options.

Q: How many outlets does the Vertiv 29072VH have, and what outlet type?

A: The 29072VH provides 10 NEMA 5-20R outlets. These accept both NEMA 5-15P and NEMA 5-20P plugs, covering the majority of standard rackmount equipment sold for North American markets.

Q: Does the 29072VH include surge protection?

A: Yes, surge protection is built into the unit. This provides a baseline level of protection against voltage transients on the upstream circuit, complementing any upstream UPS protection already in place.

Q: What is the maximum sustained load I should run on the 29072VH?

A: The unit is rated at 20A maximum input current. Per NEC guidelines, sustained load should not exceed 80% of the circuit breaker rating — so plan for no more than 16A of continuous load across all 10 outlets combined.

Ted Perry

The 29072VH is a solid fit when you need circuit-level power visibility without the overhead of a fully managed PDU — the onboard LED metering gives you real load data at the rack, and the integrated surge protection means you're not relying entirely on an upstream UPS for transient suppression. I typically specify this unit for secondary equipment rooms where budget is tighter but the installer still needs honest load feedback during commissioning.

Technical Highlights:

• 20A / NEMA L5-20P Input: The twist-lock L5-20P input is a deliberate design choice — it prevents accidental disconnection in vibration-prone environments like equipment rooms with HVAC or adjacent mechanical systems. Pair it with a UPS that has an L5-20R output and you avoid the adapter question entirely.
• 10x NEMA 5-20R Outlets on a Single 20A Circuit: Ten outlets gives you enough feeds for a moderately loaded rack — a mix of switches, NVR appliances, and access control panels — while the 20A circuit ceiling keeps the load manageable. Watch your sustained draw: 16A is the practical ceiling per NEC 80% rule.
• 3.05m (10-foot) Input Cord: The 10-foot cord reaches most UPS and panel configurations without an extension, which keeps the installation clean and avoids daisy-chaining risks. In a two-post open-frame rack, this is usually more than enough vertical drop.

Deployment Considerations:

• The L5-20P plug is the first thing to verify in your facility walk. If your panels or UPS outputs are straight-blade NEMA 5-20R, you'll need to source a rated adapter or specify a UPS with L5-20R output before the PDU can go in.
• Circuit-level metering only — there is no per-outlet load visibility. If you need to isolate which device is drawing heavy load during a troubleshoot, you'll be doing it with a clamp meter, not this display. Know that limitation before you spec it.

The 29072VH earns its place in secondary IDF closets and distributed NVR rooms where the integrator needs honest power feedback during commissioning and baseline surge protection without paying for managed outlet switching that will never get used.
