Middle Atlantic 25SP 27DEEP Plexi Door & KEN Maple TOP - BGR-25SA27MDK-E1

Middle Atlantic BGR-25SA27MDK-E1 25RU Mobile AV Rack with Plexi Doors and Kensington Maple Top

The Middle Atlantic BGR-25SA27MDK-E1 is a 25-rack-unit mobile AV rack engineered for deployments where physical access control, equipment protection, and premium presentation all matter in the same enclosure. Built from steel with a black wrinkle powder-coat finish, it ships with front and rear plexi doors, a Kensington Maple wood laminate top panel, and a 25mm × 150mm swing handle — making it a practical choice for command centers, broadcast environments, and security operations rooms where the rack is visible to clients or leadership. TAA-compliant and manufactured in the USA, it fits procurement channels with domestic-origin requirements.

Overview

At 50 inches tall and 24.5 inches wide, the BGR-25SA27MDK-E1 occupies a deliberate footprint — wide enough for standard 19-inch panel-width equipment across 25 usable rack units, but sized to roll through standard commercial doorways. The 31.35-inch total depth (24.4 inches usable) comfortably handles deep 2-post and 4-post gear: full-depth NVRs, UPS units, patch panels, and managed switches fit without forcing cable routing compromises. The forward rackrail design keeps the mounting plane consistent with standard EIA-310 gear, so no adapter plates are needed for typical rack-mount equipment.

Key Features

• 25 Rack Units / 43.75-inch Usable Height: Enough vertical space for a complete mid-scale AV or security integration — a 16-channel NVR, a managed PoE switch, a UPS, patch panel, and a KVM console without a single blanking-panel compromise. If you're speccing a standalone head-end for a retail or hospitality deployment, 25RU typically lands the build without going to a 42U floor-standing unit.
• 1,100 lb UL-Listed Load Capacity: UL Load Capacity of 1,100 lbs isn't a marketing claim — it's a UL-listed figure. Full-depth UPS units, dense patch configurations, and blade-style video servers combined rarely approach 400–500 lbs, so this rack has headroom to spare. Relevant when a facilities team asks for load documentation before approving a raised-floor installation.
• 24.4-inch Usable Depth: Most enterprise NVRs and UPS units run 20–24 inches deep. The 24.4-inch usable figure means you're not shimming or half-racking gear because the chassis won't close. Full-depth equipment installs cleanly without rear-door interference.
• Front and Rear Plexi Doors: Plexi (clear acrylic) doors give you visual status checks — LED indicators, drive activity lights, port link states — without opening the enclosure. In security operations or NOC environments where the rack is in a shared space, this reduces unnecessary access while keeping operators informed.
• Kensington Maple Wood Laminate Top: The maple laminate top isn't just aesthetic. It provides a stable, finished surface for monitors, control panels, or temporary workspace directly on the rack — relevant in broadcast trucks, hospitality AV installs, and executive briefing centers where the equipment room doubles as a working surface.
• 25mm × 150mm Swing Handle: The swing handle folds flat for tight aisle clearance and deploys for controlled movement. At 189 lbs product weight (207 lbs shipping), this rack moves with a two-person crew — the handle geometry matters for maneuvering through doorways and around existing infrastructure.
• Forward Rackrail Design: Forward-compatible rackrail positioning allows rail-depth adjustment as equipment profiles change over the installation's life. You're not locked into a single depth configuration at install time.
• Monitor Mounting Support: Integrated monitor-mounting capability means a display can be added directly to the rack structure without a separate wall arm or floor stand — practical for security monitoring stations where screen real estate is managed within the rack footprint.
• TAA Compliant, USA Origin: Federal Ops Country of Origin is USA. TAA compliance is verified (UL Listed). This matters for government, DoD, and GSA-schedule procurements where domestic-origin documentation is required at the line-item level.
• Steel Construction, Black Wrinkle Powder Coat: Steel frame with wrinkle powder coat resists minor abrasion and contact damage in active installation environments. The finish holds up through repeated moves across a project lifecycle without the cosmetic degradation you'd see on cheaper painted finishes.

Integration and Compatibility

The BGR-25SA27MDK-E1 (often searched as BGR 25SA27MDK E1) accepts standard 19-inch panel-width equipment across all 25 rack units. The forward rackrail configuration is compatible with Middle Atlantic's accessory ecosystem — including rack shelves, cable management panels, and power distribution units designed for the BGR series. The 24.4-inch usable depth accommodates the majority of commercial-grade NVRs, managed switches, UPS units, and AV processors without modification. If you're integrating a network video recorder or a PoE network switch stack, verify individual unit depths against the 24.4-inch usable figure — most enterprise-class units fall within this range, but high-density battery backup units occasionally run longer. For a complete Middle Atlantic rack and enclosure lineup including shallow-depth and wall-mount options, the full catalog covers most integration scenarios. Buyers speccing physical security infrastructure for command centers should also evaluate cable management accessories to keep the plexi doors unobstructed for visual monitoring.

Frequently Asked Questions

Q: Is the BGR-25SA27MDK-E1 TAA compliant?

A: Yes. The BGR-25SA27MDK-E1 is TAA compliant and UL Listed, with a Federal Ops Country of Origin of USA — making it eligible for GSA schedule and government procurement channels that require domestic-origin documentation.

Q: What is the usable rack depth on the BGR-25SA27MDK-E1?

A: Usable depth is 24.4 inches (62 cm). Total rack depth is 31.35 inches — the difference accounts for the door clearance and structural frame. Most enterprise NVRs, UPS units, and managed switches fit within the 24.4-inch usable figure without modification.

Q: How many rack units does this rack provide?

A: The BGR-25SA27MDK-E1 provides 25 rack units (RU) of usable mounting space, with a usable height of 43.75 inches. It accepts standard 19-inch panel-width equipment.

Q: What is the UL-listed load capacity?

A: UL Load Capacity is 1,100 lbs (499 kg). This is a UL-listed figure, not a nominal rating — relevant for procurement documentation and facilities sign-off on raised-floor or mobile deployments.

Q: Does the BGR-25SA27MDK-E1 include front and rear doors?

A: Yes. Both a front and rear door are included. The front door is a plexi (clear acrylic) panel allowing visual equipment status checks without opening the enclosure. A rear door is also included for rear cable access control.

Q: What does the Kensington Maple top provide?

A: The Kensington Maple wood laminate top panel provides a finished working surface on top of the rack enclosure — useful for monitors, control interfaces, or temporary workspace in broadcast, hospitality AV, or executive AV environments where the rack is client-visible.

Karl Wilson

The BGR-25SA27MDK-E1 hits a specific sweet spot I see regularly on hospitality and corporate AV jobs: 25RU gives you enough vertical real estate for a complete head-end build — NVR, switching, power distribution, and patch — while the mobile base and maple laminate top mean you can roll it into a finished space without it looking like a data center leftover. The 1,100 lb UL-listed load rating and USA origin make it a clean line item for government and education procurement without any additional compliance paperwork.

Technical Highlights:

• 24.4-inch Usable Depth: Enough clearance for full-depth enterprise gear — most commercial NVRs and UPS units run 20–24 inches, so this rack accommodates them without shimming or door-interference issues that plague shallower enclosures.
• 1,100 lb UL Load Capacity: This is a UL-listed figure, not a nominal spec. On a 25RU build with a full UPS, dense NVR, and switching stack, you're typically well under 400 lbs of actual load — the rating is there for facilities and structural sign-off, not because you'll approach it.
• Plexi Front Door + Monitor Mounting: Visual status checks without breaking the door seal, combined with integrated monitor-mounting support, reduce the need for separate display infrastructure in security ops and NOC environments where vertical space and aisle clearance are managed tightly.

Deployment Considerations:

• At 189 lbs product weight, this is a two-person move minimum. Plan the installation sequence before the rack is populated — moving a loaded BGR-25SA27MDK-E1 through a standard commercial doorway requires the 24.5-inch width to clear door frames with minimal margin.
• The forward rackrail design is standard EIA-310, but verify accessory rail positions if you're adding Middle Atlantic shelves or blanking panels post-install — the BGR series uses specific rail spacing that differs from generic aftermarket accessories.

This rack is the right call for a corporate boardroom AV build, a hospitality property head-end, or a government facility equipment room where TAA documentation is non-negotiable and the rack will be visible to non-technical stakeholders who notice finish quality.
