Middle Atlantic 25SP 27DEEP Plexi Door & BIT Cherry TOP - BGR-25SA27MDK-E0

Middle Atlantic BGR-25SA27MDK-E0 25RU Mobile AV Rack with Plexi Door and Biltmore Cherry Top

The Middle Atlantic BGR-25SA27MDK-E0 is a 25-rack-unit steel mobile enclosure built for AV and security equipment deployments that demand both structural integrity and a professional finish. At 1,100 lbs UL-rated load capacity in a 50-inch-tall, 27-inch-deep frame, it handles dense NVR, switch, and AV processing stacks without flex or rattle — and the Biltmore Cherry wood laminate top with integrated plexi front door makes it a credible choice for boardrooms, executive briefing centers, and lobby installations where the rack is visible. Manufactured in the USA and TAA-compliant, the BGR-25SA27MDK-E0 (often searched as BGR 25SA27MDK E0) routes cleanly into federal and government procurement channels without exception paperwork.

Key Features

• 25 RU / 43.75 in usable height: Fits a full NVR, PoE switch stack, patch panel, and power distribution unit in a single enclosure — enough vertical space for a complete 16- or 32-channel IP video system without a second cabinet.
• 1,100 lb UL-rated load capacity: That rating covers the heaviest enterprise NVR chassis, multi-drive storage arrays, and UPS units you're likely to stack. The UL listing means it's not a marketing number — it's a tested structural rating.
• 27-inch depth (24.4 in usable) with Forward Rackrail: The forward rackrail positions equipment toward the front of the 24.4-inch usable depth, leaving rear space for cable management and airflow. Works with standard 19-inch panel-width gear without adapter rails.
• Steel construction with black wrinkle powder coat: The wrinkle finish hides minor contact marks in high-traffic installs and holds up to repeated equipment swaps better than smooth paint. The steel frame won't rack or twist under uneven loading the way aluminum budget enclosures can.
• Biltmore Cherry wood laminate top: Sets this unit apart from utilitarian server-room racks — appropriate for corporate AV installs, conference rooms, and any site where facilities or ownership will object to an exposed metal rack top. The laminate is a fixed aesthetic, not a field-add.
• Plexi front door with 25mm × 150mm swing handle: Equipment is visible through the door for status-light monitoring without opening the rack. The swing handle provides positive latching without a key mechanism — factor that into your physical security plan if access control matters.
• Rear door included: Cable access and rear-panel work don't require tilting or moving the rack. Important for deployments where the rack sits against a wall but cabling still needs to route from the rear.
• Monitor mounting support: Accommodates a rack-mount monitor or KVM arm for local console access — relevant for NVR/DVR systems that need periodic direct display.
• Forward Compatible design: Middle Atlantic's forward-compatible architecture means rack accessories and upgrades from the current product line can be integrated without replacing the enclosure shell.
• Mobile configuration: The BGR mobile series ships on casters, enabling repositioning during installation and ongoing maintenance access without disconnecting the entire rack — a meaningful time-saver on dense builds.
• TAA Compliant / USA-manufactured: Federal Ops Country of Origin is USA. Qualifies for GSA schedules and agency procurement under the Trade Agreements Act without requiring a waiver.

Integration and Compatibility

The BGR-25SA27MDK-E0 accepts standard 19-inch (48.3 cm) panel-width equipment across all 25 rack units. The forward rackrail configuration is compatible with rack enclosure accessories including Middle Atlantic's own blanking panels, cable managers, and PDU options. At 24.5 inches wide overall and 31.35 inches deep, verify floor plan clearance before ordering — the mobile base adds rolling footprint that fixed-post racks don't have. The 207-lb shipping weight requires freight delivery; confirm loading dock access or lift-gate service at the destination site. Pair with a rack-mount PDU and structured cable management to keep the interior presentable through the plexi door. For the security integration side, review the NVR selection guide to match rack unit consumption to available RU before configuring the build. Middle Atlantic's full rack and enclosure line includes companion wall-mount and fixed-post options for installations where mobility is not required.

Frequently Asked Questions

Q: Is the BGR-25SA27MDK-E0 TAA compliant and manufactured in the USA?

A: Yes. The BGR-25SA27MDK-E0 is TAA compliant with Federal Ops Country of Origin listed as USA, making it eligible for federal and government procurement under the Trade Agreements Act.

Q: What is the UL-rated load capacity of the BGR-25SA27MDK-E0?

A: The UL-rated load capacity is 1,100 lbs (499 kg). This is a UL-tested structural rating, not a manufacturer estimate.

Q: How many rack units does the BGR-25SA27MDK-E0 provide, and what is the usable height?

A: The BGR-25SA27MDK-E0 provides 25 rack units with 43.75 inches (111.1 cm) of usable height — enough for a complete NVR, PoE switch, patch panel, and power distribution stack.

Q: Does the BGR-25SA27MDK-E0 ship with both a front and rear door?

A: Yes. Both a plexi front door (with 25mm × 150mm swing handle) and a rear door are included, providing equipment visibility from the front and rear cable access without moving the rack.

Q: What is the overall depth and usable depth of the BGR-25SA27MDK-E0?

A: Overall depth is 31.35 inches (79.6 cm); usable depth is 24.4 inches (62 cm). The forward rackrail positions equipment toward the front, preserving the rear for cable routing and airflow.

Q: Is the Biltmore Cherry top a field-installed option or does it ship installed?

A: The Biltmore Cherry wood laminate top is a configured feature of this specific SKU — it ships as part of the enclosure, not as a separate field-add kit.
