Panduit CUWBPS24ST02W1 Net-Contain™ 2400mm Wall Beam, White

Overview

The CUWBPS24ST02W1 is a 2400mm (94.49-inch) steel wall beam designed as a structural component of Panduit's Panduit Net-Contain™ universal aisle containment system. If you're building or extending a hot aisle or cold aisle containment enclosure in a data center or server room, this beam provides the wall-anchored horizontal span that closes the gap between the end of your row and a solid wall — the structural element that makes full containment geometry possible rather than leaving an open end that bleeds conditioned air into the room.

Aisle containment works only as well as its weakest boundary. A poorly fitted or improvised end piece at the wall lets hot exhaust recirculate into cold intake, undermining the entire thermal strategy. The CUWBPS24ST02W1 addresses that with a purpose-built, same-system component that aligns with Net-Contain™ geometry, so you're not improvising with off-spec metal or foam blocking.

Key Features

• 2400mm (94.49 in) Span: At just under 8 feet, this beam covers a full standard row-end gap in most two-post and four-post rack deployments. Measure your wall-to-rack distance before ordering — this is a fixed-length component, not adjustable, so getting the right length upfront avoids a return trip.
• Steel Construction: The beam is fabricated from steel, not aluminum extrusion or plastic. That matters in environments where containment panels carry incidental load from cable management or where technicians lean against the structure during maintenance. Steel holds shape over the long term without creep.
• White Finish (Weiß): Color-matched to white Net-Contain™ deployments. Most data center containment installs in white or gray — if your containment panels are white, this beam integrates cleanly without mismatched aesthetics on a customer-facing or visibility-critical floor.
• Net-Contain™ System Compatibility: This component is part of the universal Net-Contain™ aisle containment line from Panduit, meaning it's designed to interface with the same attachment geometry, panel widths, and accessory hardware as other system components. Mixing containment hardware from different vendors risks fit issues at junctions — using a same-system beam eliminates that variable.
• RoHS-Compliant: Meets RoHS (Restriction of Hazardous Substances) requirements, which matters for facilities operating under EU WEEE regulations or corporate sustainability mandates. If your data center procurement team requires RoHS documentation for capital equipment, this component qualifies.
• Compact Cross-Section (104.8mm H × 133.3mm W): At roughly 4.1 inches tall and 5.25 inches wide, the beam profile doesn't consume significant overhead clearance. In rooms with constrained ceiling height or dense cable trays above the rows, a low-profile structural member preserves your working clearance.
• Single-Unit Packaging: Ships as an individual beam — not a case-pack that forces you to buy in bulk. If you're extending one row end or completing a partial containment install, you can order exactly what you need without overstocking long structural components that are awkward to store.

Integration & Compatibility

The CUWBPS24ST02W1 is built for the Panduit Net-Contain™ universal aisle containment ecosystem. Pair it with matching Net-Contain™ end panels, top panels, and door assemblies to complete the enclosure geometry. Wall anchor hardware requirements will depend on your wall construction (concrete, drywall over stud, raised-floor plenum walls) — confirm anchor type and load rating with your facilities team before installation, as the beam itself does not include wall fasteners.

For thermal management planning, consult your CRAC/CRAH unit capacity alongside your containment layout. A wall beam closes the structural gap, but airflow balance — supply versus return CFM by row — still needs to be validated against your cooling infrastructure once containment is complete.

Frequently Asked Questions

Q: What is the exact length of the CUWBPS24ST02W1 wall beam?

A: The beam is 2400mm long, which converts to 94.49 inches (approximately 7 feet 10.5 inches). Verify your wall-to-rack gap measurement before ordering — this is a fixed-length component.

Q: What containment system does the CUWBPS24ST02W1 belong to?

A: It is a structural component of Panduit's Net-Contain™ universal aisle containment system, designed to mount at the wall end of a contained aisle row.

Q: What material is the CUWBPS24ST02W1 constructed from?

A: The beam is fabricated from steel. It is finished in white to match white Net-Contain™ deployments.

Q: Is the CUWBPS24ST02W1 RoHS compliant?

A: Yes, the CUWBPS24ST02W1 meets RoHS (Restriction of Hazardous Substances) requirements as listed in its product specifications.

Q: How many beams are included per order?

A: The package quantity is 1 — a single wall beam per unit ordered. Order according to the number of wall-end spans in your containment layout.

Q: Does the CUWBPS24ST02W1 include wall mounting hardware?

A: Wall fasteners are not listed as included. Anchor type and load rating should be confirmed with your facilities team based on your wall construction (concrete, drywall, raised-floor partition, etc.).

Marty Allison

The CUWBPS24ST02W1 is the piece most containment projects forget to spec until they're standing at the end of the row with an open gap. At 2400mm — 94.49 inches — this steel wall beam is the structural span that closes a full-row wall terminus in a Net-Contain™ enclosure, and getting the right length and system match here determines whether your containment geometry actually seals or just approximates it.

Technical Highlights:

• Fixed 2400mm length: Covers the most common full-row wall gap in standard 600mm and 800mm rack-pitch deployments. No adjustability — measure twice, order once. At 94.49 inches this won't work for a 2000mm row or a partial gap; you need the right-length SKU from the Net-Contain™ beam family.
• Steel construction, 104.8mm × 133.3mm cross-section: The 4.1 × 5.25 inch profile is rigid enough to resist racking under panel load without significant overhead clearance penalty. Aluminum extrusions in competing systems can deflect over time in high-humidity or high-temp ambient conditions — steel holds.
• RoHS-compliant finish: White powder coat is RoHS-documented, which satisfies procurement checklists for EU-market facilities and sustainability-reporting environments without extra paperwork.

Deployment Considerations:

• Wall anchor hardware is not included — in concrete or CMU walls you'll need appropriate anchors rated for the beam's weight plus panel loading; in drywall-over-stud you must locate studs or use a backing plate. Don't assume the mounting detail is handled.
• This is a single-beam SKU (package quantity: 1). For a two-beam pair configuration (top and bottom wall mounting), order accordingly — a common spec error is ordering one beam for a two-point wall attachment detail.

The CUWBPS24ST02W1 is the right call for completing a Net-Contain™ cold aisle enclosure in a colocation or enterprise data center where the row terminates directly at a perimeter wall — the scenario where improvised blocking fails compliance review and a same-system beam is the only clean solution.
